TAO 1mini All In One Live Streaming Codec Video Switcher
Product Information:
This product is called TAO 1mini-HN. It is a versatile device
that supports HDMI&UVC and FULL NDI gigabit Ethernet video
stream codecs for encoding and decoding. It has a round appearance,
simple and elegant design, and is easy to carry. The device comes
with standard camera screw holes for easy installation on camera
brackets. It features a 2.1-inch TFT touch screen for real-time
signal monitoring and menu operations. It also supports tally
lights, U disk recording, and Power over Ethernet (PoE)
functionality.
The TAO 1mini-HN offers low latency live previews and recording
with support for RTMP and RTMPS protocols. It can be powered via
PoE or USB-C PD, and it allows streaming to at least 4 platforms
using the TAO APP. The device has LED TALLY indicators and supports
up to 2K FHD video resolution. It is compatible with MJPEG/YUV and
H.264 codecs for high-quality video transmission.
Product Usage Instructions:
To use the TAO 1mini-HN, follow these steps:
- Connect your phone or other devices to the UVC IN port to
receive video signals. - Use the Reset button to recharge the device if needed.
- Connect your AI tracking camera to the HDMI IN port to receive
video signals. - Use the LAN|PoE port for up streaming.
- Connect an external display or recording device to the HDMI OUT
port for video signal transmission. - Use the MIC port for audio signal transmission.
- Connect your webcam to the USB 3.0 port for video signal
transmission. - Make use of the 2.1-inch TFT touch screen for real-time signal
monitoring and menu operations. - Utilize the tally lights feature for visual indication.
- Take advantage of the U disk recording capability if
desired. - If using PoE, connect the device to a PoE-enabled network for
power supply and network transmission. - Install the device using the double-rack screw holes according
to your specific installation scenario.
For more information and support, visit the rgblink website or contact
[email protected] or +86 592 5771197.
Interface
Input
Output Audio Communication
Power
Power
Mode Input voltage Maximum power
HDMI 1.3 UVC HDMI 1.3 Input LAN(PoE) USB 3.0 Type-C LAN(PoE)
1×HDMI-A 1×USB-C 1×HDMI-A 1×3.5mm audio socket 1×RJ45 1×USB-A 1×PD Type-C 1×RJ45
PoE, PD 5~12V 10W
Working Environment
Temperature Humidity
0~55 5%~85%
Physical
Product Weight Package Weight Product Dimension Package Dimension
180g 780g 91mm(diameter)×40.8mm(height) 215mm x 145mm x 80mm
In the Box
TAO 1mini-HN Welcome Card USB-C Cable International Socket Adapters
Performance
HDMI 1.3 input Input resolution
Format Bit depth Pixel format Image delay
720p@50/60, 1080i@50/60, 1080p@30/50/60, 1280×720@50/60, 1280×768@60, 1280×1024@60, 1360×768@60, 1366×768@60 , 1600×900@60, 1920×1080@50/60
RGB/YUV 4:2:0/4:2:2 8 bit/10 bit BT.601 | BT.709 3 frames
UVC/Type C input Input resolution
Decoding performance
1024×768@60, 1280×720@50/60, 1280×768@60, 1280×1024@60, 1360×768@60, 1920×1080@24/25/30/50/60 MJPEG/YUV | H.264 | H.265
Audio Input Audio delay setting Analog audio input Maximum input level
0~160ms MIC/LINE +6dBV
LAN Coding performance Speed mode NDI coding NDI decoding RTMP/SRT coding Maximum output speed
Support MJPEGYUV,H.264,H.265 CBR,VBR,FIXQP,AVBR,QPMAP FULL NDI, 2K@60 FULL NDI, 2K@60 Support streaming software 125Mbps
HDMI 1.3 output Output resolution
Audio
720×480@30, 1280×720@30, 1920×1080@30/60 Embedded audio output
Order Codes
410-5513-05-3
TAO 1mini-HN
WEB: www.rgblink.com EMAIL: [email protected] PHONE: +86 592 5771197 Proudly designed and manufactured in Xiamen Hi Technology Zone, China
090-0230-01-0 2022 | TAO 1mini
www.rgblink.com
UVC IN : For receiving video signal from your phone or others
Reset : For recharging USB-C : Charge
HDMI IN : For receiving
video signal from your AI tracking camera
LAN|PoE : For up streaming
HDMI OUT :For video signal transimission
MIC : For Audio signal transmission
USB 3.0 : For video signal transmission from your webcam
2K streaming node
NDI is the abbreviation of Network Device Interface, which is a broadcast-quality, low-latency open IP network interface protocol launched by NewTek. As the world’s leading network audio and video codec technology, NDI is favored by more and more professional audio and video technicians.
TAO 1mini-HN supports HDMI&UVC and FULL NDI gigabit Ethernet video stream codecs for encoding and decoding. Round appearance, simple and elegant, easy to carry, with standard camera screw holes, can be easily installed to the camera bracket. The device has a 2.1-inch TFT touch screen for real-time monitoring of signals and menu operations. Support tally lights, support U disk recording, support PoE and other functions.
Compact in form NDI codec support Dual ¼in mounts
low latency live previews & recording RTMPRTMPS protocols
Why choose NDI?
NDI is a broadcast-quality, low-latency video streaming protocol over Gigabit networks. With low loss, low latency, more stable
Low loss
Low latency
More stable
power via PoE power from USB-C PD Stream to at least 4 platforms via TAO APP
LED TALLY indicators Up to 2K FHD
Professional IP production equipment
Both encoding and decoding support up to 2K (FHD) video resolution, and are backward compatible with resolutions such as HD/SD. Adopt MJPEGYUV, H.264 to ensure high quality video transmission
Power via PoE Ethernet
At the same time, it supports Power over Ethernet (PoE), PD input, and can use a mobile power supply to power the device. Only one network cable can realize power supply and network transmission.
Easy to install
TAO 1mini-HN has double-rack screw holes, allowing you to enjoy a variety of installation experiences according to different scenarios.
Portable and stable
Exquisite and portable, it has a built-in ultra-thin large-diameter cooling fan to help cool the device.
&
Codec integration
TAO 1mini-HN not only supports 2K Full NDI but also NDI|HX, it is an all-in-one codec machine
Multi-platform live streaming
TAO 1mini-HN can not only convert 2K HDMIUVC signals into NDIRTMPSRT, but also a network push streaming device that can realize simultaneous live broadcast of 4 platforms.
HDMI/UVC
RTMP/SRT
One-click recording
The USB 3.0 interface supports up to 64G U disk or 2T SSD solid state drive, and realizes high-quality audio and video recording function with one key.
Monitor and touch
The 2.1-inch full-color touch monitoring screen can not only monitor the signal in real time, but also control it quickly.
