Rgblink 1mini-hn Usb-hdmi Streaming Node Owner's Manual (+ PDF)

HDMI 1.3 input:
- Input resolution
- Format: RGB/YUV 4:2:0/4:2:2
- Bit depth: 8 bit/10 bit
- Pixel format: BT.601 | BT.709
- Image delay: 3 frames
UVC/Type C input:
- Input resolution
- Decoding performance
Audio Input:
- Audio delay setting: 0~160ms
- Analog audio input
- Maximum input level: MIC/LINE +6dBV
LAN Coding performance:
- Speed mode
- NDI coding
- NDI decoding
- RTMP/SRT coding
- Maximum output speed: Support streaming software 125Mbps
HDMI 1.3 output:
- Output resolution

Order Codes:

410-5513-05-3
TAO 1mini-HN
090-0230-01-0
2022 | TAO 1mini

Contact Information:

WEB: www.rgblink.com
EMAIL: [email protected]
PHONE: +86 592 5771197
Proudly designed and manufactured in Xiamen Hi Technology Zone,
China

Product Usage Instructions:

UVC IN: Connect this port to receive video
signal from your phone or other devices.

Reset: Use this button to recharge the
device.

USB-C: Connect a USB-C cable to charge the
device.

HDMI IN: Connect this port to receive video
signal from your AI tracking camera.

LAN|PoE: Use this port for up streaming.

HDMI OUT: Use this port for video signal
transmission.

MIC: Use this port for audio signal
transmission.

USB 3.0: Use this port for video signal
transmission from your webcam.

2K streaming node: The device supports
HDMI&UVC and FULL NDI gigabit Ethernet video stream codecs for
encoding and decoding. It has a round appearance, is simple and
elegant, and easy to carry. It also has standard camera screw holes
for easy installation on camera brackets. The device features a
2.1-inch TFT touch screen for real-time monitoring of signals and
menu operations. It supports tally lights, U disk recording, PoE,
and other functions.

Why choose NDI?

NDI is a broadcast-quality, low-latency video streaming protocol
over Gigabit networks. It offers low loss, low latency, and more
stable power via PoE. The device can stream to at least 4 platforms
via the TAO APP. It also features LED TALLY indicators and supports
up to 2K FHD resolution. NDI is widely used in professional IP
production equipment. The encoding and decoding support up to 2K
(FHD) video resolution and are backward compatible with resolutions
such as HD/SD. The device adopts MJPEGYUV and H.264 for
high-quality video transmission.

Power via PoE Ethernet: The device supports
Power over Ethernet (PoE) and PD input. It can be powered by a
mobile power supply, and only one network cable is needed for both
power supply and network transmission.

Easy to install: The TAO 1mini-HN has
double-rack screw holes, allowing for various installation
experiences according to different scenarios.

View Fullscreen

Interface
Input
Output Audio Communication
Power
Power
Mode Input voltage Maximum power

HDMI 1.3 UVC HDMI 1.3 Input LAN(PoE) USB 3.0 Type-C LAN(PoE)

1×HDMI-A 1×USB-C 1×HDMI-A 1×3.5mm audio socket 1×RJ45 1×USB-A 1×PD Type-C 1×RJ45

PoE, PD 5~12V 10W

Working Environment

Temperature Humidity

0~55 5%~85%

Physical
Product Weight Package Weight Product Dimension Package Dimension

180g 780g 91mm(diameter)×40.8mm(height) 215mm x 145mm x 80mm

In the Box
TAO 1mini-HN Welcome Card USB-C Cable International Socket Adapters

Performance
HDMI 1.3 input Input resolution
Format Bit depth Pixel format Image delay

720p@50/60, 1080i@50/60, 1080p@30/50/60, 1280×720@50/60, 1280×768@60, 1280×1024@60, 1360×768@60, 1366×768@60 , 1600×900@60, 1920×1080@50/60
RGB/YUV 4:2:0/4:2:2 8 bit/10 bit BT.601 | BT.709 3 frames

UVC/Type C input Input resolution
Decoding performance

1024×768@60, 1280×720@50/60, 1280×768@60, 1280×1024@60, 1360×768@60, 1920×1080@24/25/30/50/60 MJPEG/YUV | H.264 | H.265

Audio Input Audio delay setting Analog audio input Maximum input level

0~160ms MIC/LINE +6dBV

LAN Coding performance Speed mode NDI coding NDI decoding RTMP/SRT coding Maximum output speed

Support MJPEGYUV,H.264,H.265 CBR,VBR,FIXQP,AVBR,QPMAP FULL NDI, 2K@60 FULL NDI, 2K@60 Support streaming software 125Mbps

HDMI 1.3 output Output resolution
Audio

720×480@30, 1280×720@30, 1920×1080@30/60 Embedded audio output

Order Codes
410-5513-05-3

TAO 1mini-HN

WEB: www.rgblink.com EMAIL: [email protected] PHONE: +86 592 5771197 Proudly designed and manufactured in Xiamen Hi Technology Zone, China
090-0230-01-0 2022 | TAO 1mini

www.rgblink.com

UVC IN : For receiving video signal from your phone or others
Reset : For recharging USB-C : Charge

HDMI IN : For receiving
video signal from your AI tracking camera

LAN|PoE : For up streaming
HDMI OUT :For video signal transimission

MIC : For Audio signal transmission
USB 3.0 : For video signal transmission from your webcam

2K streaming node

NDI is the abbreviation of Network Device Interface, which is a broadcast-quality, low-latency open IP network interface protocol launched by NewTek. As the world’s leading network audio and video codec technology, NDI is favored by more and more professional audio and video technicians.
TAO 1mini-HN supports HDMI&UVC and FULL NDI gigabit Ethernet video stream codecs for encoding and decoding. Round appearance, simple and elegant, easy to carry, with standard camera screw holes, can be easily installed to the camera bracket. The device has a 2.1-inch TFT touch screen for real-time monitoring of signals and menu operations. Support tally lights, support U disk recording, support PoE and other functions.

Compact in form NDI codec support Dual ¼in mounts

low latency live previews & recording RTMPRTMPS protocols

Why choose NDI?
NDI is a broadcast-quality, low-latency video streaming protocol over Gigabit networks. With low loss, low latency, more stable

Low loss

Low latency

More stable

power via PoE power from USB-C PD Stream to at least 4 platforms via TAO APP

LED TALLY indicators Up to 2K FHD

Professional IP production equipment
Both encoding and decoding support up to 2K (FHD) video resolution, and are backward compatible with resolutions such as HD/SD. Adopt MJPEGYUV, H.264 to ensure high quality video transmission

Power via PoE Ethernet
At the same time, it supports Power over Ethernet (PoE), PD input, and can use a mobile power supply to power the device. Only one network cable can realize power supply and network transmission.

Easy to install
TAO 1mini-HN has double-rack screw holes, allowing you to enjoy a variety of installation experiences according to different scenarios.

Portable and stable
Exquisite and portable, it has a built-in ultra-thin large-diameter cooling fan to help cool the device.

Codec integration

TAO 1mini-HN not only supports 2K Full NDI but also NDI|HX, it is an all-in-one codec machine

Multi-platform live streaming
TAO 1mini-HN can not only convert 2K HDMIUVC signals into NDIRTMPSRT, but also a network push streaming device that can realize simultaneous live broadcast of 4 platforms.

HDMI/UVC

RTMP/SRT

One-click recording
The USB 3.0 interface supports up to 64G U disk or 2T SSD solid state drive, and realizes high-quality audio and video recording function with one key.

Monitor and touch
The 2.1-inch full-color touch monitoring screen can not only monitor the signal in real time, but also control it quickly.
