SAFE INSTALLATION
SAFE INSTALLATIONRead these instructions before beginning the installation and hand them over to the user of the system. Only persons with the requisite knowledge are to perform the installation or maintenance. If you lack this knowledge, contact a qualified electrician.
Make sure that the mains power is switched off before installation or maintenance. Install as described below. Position the LED luminaire and driver unit far from heat sources and in a well-ventilated area.
We reserve the right to change specifications at any time.
| Rated supply voltage | 220-240V |
| Frequency | 50/60 Hz |
| Input current | 0,41A |
| Lamp wattage | 12W – 75W |
| Operating temperature ta | 50°C |
| Max casing temperature tc | Max. 80°C |
| Lifetime | 50 000 h |
Elektro Elco AB, Tallvägen 5, SE-564 35 Bankeryd, Sweden | www.ecolite.se
