GWD6821 90 AM Fuse and Switch Disconnector
Product Information:
The product is the GWD6821 with a power supply operating voltage
of 230 V~ +/- 20%. It features an LAN-TCP/IP interface for
communication and is compliant with various standards such as IEC
62368-1, IEC 60127-2, EN 55032 CISPR 32, and EN 61000-4. It has a
DIN-rail mounting design and meets EMC disturbance and immunity
requirements. The product has a working voltage of 300 V and a
flammability rating of class V0. It also has reinforced insulation
between the mains supply circuit and communication circuit.
Product Usage Instructions:
- Before performing any installation or maintenance tasks, ensure
that the power is switched off to avoid electrical hazards. - For installation and verification, it is recommended to seek
the assistance of an expert specialist. - Ensure that the fuse and switch disconnector used comply with
the standard IEC 62368-1. Use a certified cartridge fuse (5×20 mm)
with a rated current of 125 mA and a maximum voltage of 250 Vac
(e.g., Littelfuse 0218.125). - The DIN rail on which the contactor is fitted must be
earthed. - For LAN connectivity, connect the product’s LAN-TCP/IP
interface using an RJ-45 connector. It supports 10/100 BASE-T
Ethernet. - Follow the hardware connection instructions provided to
establish the LAN connection. - The product operates using TCP/IP protocol and supports
application level protocols such as HTTP and Modbus/TCP. It also
utilizes SNTP, DHCP, and DNS protocols. - Mount the product on a DIN rail according to the DIN 43380 and
EN60715 standards. - Ensure proper power supply by connecting the appropriate wires
(0.5 mm2, acc. to IEC 60332-2-2 for smaller sections) to the
specified operating voltage. - Take into account the EMC disturbances and immunities
requirements specified in the manual. - Consider the environmental conditions, such as storage
temperature and relative humidity, to maintain optimal performance
and longevity of the product.
90 AM
GWD6821
L’installazione deve essere effettuata e verificata da uno specialista esperto. Togliere tensione prima di intervenire
sull’apparecchio. The installation must be performed and checked by an expert specialist. When working on the instrument, switch off the
mains voltage! L’installation doit être exécutée et vérifiée par un spécialiste expert. Couper la tension avant d’intervenir sur l’appareil.
La instalación debe ser efectuada y comprobada por un especialista experto. Antes de intervenir en el equipo hay que
cortar la tensión. Der Einbau muss von einem erfahrenen Spezialisten durchgeführt und überprüft werden. Bei Arbeiten am Meßgerät,
Netzspannung abschalten!
Fusibile e sezionatore in accordo alla norma IEC 62368-1. Fusibile a cartuccia 5×20 mm, Certificato secondo la norma IEC 60127-2. Corrente nominale 125 mA. Tensione massima 250 Vac. Per esempio: Littelfuse 0218.125 La barra DIN sulla quale il contatore è montato deve essere collegato a terra.
Fuse and switch disconnector in compliance with standard IEC 62368-1. Cartridge fuse 5×20 mm, certified according to standard IEC 60127-2. Rated current 125 mA. Maximum voltage 250 Vac. For example: Littelfuse 0218.125 The DIN rail on which the contactor is fit must be earthed.
Fusible et sectionneur conformément à la norme CEI 62368-1. Fusible à cartouche 5×20 mm, certificat selon la norme CEI 60127-2. Courant nominal 125 mA. Tension maximale 250 Vac. Par exemple : Littelfuse 0218.125 La barre DIN sur laquelle est monté le contacteur doit être raccordée à la terre.
Fusible y seccionador conformes con la norma CEI 62368-1.
Fusible de cartucho de 5×20 mm, certificado según la norma CEI 60127-2.
Intensidad nominal 125 mA.
Tensión máxima 250 Vca.
Por ejemplo: Littelfuse 0218.125
N
La barra DIN en la que está montado el contador debe estar conectada a tierra.
L
Sicherung und Lasttrennschalter entsprechen der Norm IEC 62368-1. Patronensicherung 5×20 mm, Zertifiziert gemäß der Norm IEC 60127-2. Bemessungsstrom 125 mA. Höchstspannung 250 VAC. Zum Beispiel: Littelfuse 0218.125. Die DIN-Schiene, auf der der Zähler montiert wird, muss geerdet sein.
PZ0
1
Un possibile schema del sistema è descritto sotto. In figura il LAN-Gateway è connesso al PC. Il LAN-Gateway può essere connesso anche ad una rete LAN esistente. One possible scheme of the system is described below. In the picture the LAN-Gateway is connect to a PC. Instead, LAN-Gateway can be connected to LAN network. Un possible schéma du système est décrit ci-dessous. Sur la figure, le LAN-Gateway est connecté à l’ordinateur. Le LAN-Gateway peut également être connecté à un réseau LAN existant. A continuación se describe un posible esquema. En la figura el LAN-Gateway está conectado al PC. El LAN-Gateway también se puede conectar a una red LAN existente. Die nachfolgende Skizze zeigt eine mögliche Systemkonfiguration. In dieser Konfiguration kommuniziert der LAN-Gateway mit einem PC. Der LAN-Gateway kann auch in vorhandene LAN-Netze eingebunden werden.
Interfaccia LAN-TCP/IP, LAN-TCP/IP interface, Interface LAN-TCP/IP, Interfaz LAN-TCP/IP,
LAN-TCP/IP Kommunikationsmodul
Strumento di misura, Measuring instrument, Instrument de mesure, Instrumento de medición,
Messgerät
· Indirizzo IP, IP address, Adresse IP, Dirección IP, IP Addresse: 192.168.1.253 · Subnet Mask: 255.255.255.0 · Gateway: 192.168.1.1 · DHCP OFF · DNS primario, Primary DNS, DNS primaire, DNS principal, Primäre DNS: 8.8.8.8 · DNS secondario, Secondary DNS, DNS secondaire, DNS secundario, Sekundäre DNS: 156.154.70.1 · Credenziali di accesso, Access credentials, Identifiants de connexion, Credenciales de acceso, Zugangsdaten:
– Nome utente, Username, Nom utilisateur, Nombre del usuario, Anwender: admin – Password, Password, Mot de passe, Contraseña, Passwort: admin
· ACT LED (giallo): Lampeggia quando c’è attività su LAN. – ACT LED (yellow): Blinking means LAN activity. – VOYANT ACT (jaune): Clignote lorsqu’il y a de l’activité sur le LAN. – LED ACT (amarillo): Parpadea cuando hay actividad en la LAN. – ACT LED (gelb): Blinkt bei Aktivität auf LAN.
· SPEED LED (verde): Il LED è ON se la LAN opera a 100 Mbit/s, è OFF se opera a 10 Mbit/s. – SPEED LED (green): The LED is ON if the LAN is 100 Mbit/s, it’s OFF if the LAN is 10 Mbit/s. – VOYANT SPEED (vert) : Le voyant est ON si le LAN fonctionne à 100 Mbit/s, il est OFF s’il fonctionne à 10 Mbit/s. – LED SPEED (verde): El LED está ON si la LAN está comunicando a 100 Mbit/s, está OFF si la LAN está comunicando a 10 Mbit/s. – SPEED LED (grün): Die LED ist ON, wenn das LAN mit 100 Mbit/s arbeitet, und OFF, wenn es mit 10 Mbit/s arbeitet.
· FDX LED (giallo): Il LED è ON se la LAN opera full-duplex, è OFF se opera half-duplex. – FDX LED (yellow): The LED is ON if the LAN is fullduplex, it’s OFF if the LAN is half-duplex. – VOYANT FDX (jaune) : Le voyant est ON si le LAN fonctionne en full-duplex, il est OFF s’il fonctionne en half-duplex. – LED FDX (amarillo): El LED está ON si la LAN está comunicando en dúplex completo, está OFF si la LAN está comunicando en dúplex medio. – FDX LED (gelb): Die LED ist ON, wenn das LAN in Vollduplex arbeitet, und OFF, wenn es in Halbduplex arbeitet.
· ON LED (verde): Il LED è ON quando il modulo è alimentato. – ON LED (green): Power supply on. – VOYANT ON (vert) : Le voyant est ON lorsque le module est alimenté. – LED ON (verde): El LED está ON cuando el módulo está alimentado. – ON LED (grün): Die LED ist ON, wenn das Modul versorgt wird.
2
RESET
RESET
· Pressione breve, meno di 3 secondi –> Reboot del dispositivo. · Pressione di almeno 3 secondi –> I LED SPEED (verde) e FDX (giallo) iniziano a lampeggiare alternativamente. In questa fase, rilasciando il pulsantino, I valori di default della connessione vengono ripristinato e avviene un reboot. · A short pushing, shorter than 3 seconds –> Device reboot. · A push longer than 3 seconds –> SPEED (green) and FDX (yellow) LEDs start blinking alternatively. In this phase, by releasing the Reset button, the default network parameters are restored and the device reboots. · Pression courte, moins de 3 secondes –> Reboot du dispositif. · Pression de 3 secondes au moins –> le voyant SPEED (vert) et le voyant FDX (jaune) commencent à clignoter alternativement. Lors de cette phase, si petit bouton est relâché, les paramètres par défaut de la connexion sont restaurés et le dispositif effectue un reboot. · Presión breve, menos de 3 segundos –> El dispositivo ejecuta un reinicio. · Presión durante al menos 3 segundos –> El led SPEED (verde) y el led FDX (amarillo) empiezan a parpadear alternadamente. En esta fase, si se suelta el pulsador pequeño, se restablecen los parámetros predeterminados de la conexión y el dispositivo ejecuta el reinicio. · Kurzer Druck, weniger als 3 Sekunden –> Reboot der Vorrichtung. · Druck von mindestens 3 Sekunden –> Die LED SPEED (grün) und FDX (gelb) beginnen abwechselnd zu blinken. Durch Loslassen der Taste in dieser Phase werden die Standardwerte der Verbindung rückgesetzt und es erfolgt ein Reboot.
(ref. IEEE 802.3 AS, EN 62368-1:2018, EN 55032 CISPR 32, EN 61000-4)
LAN Interface
Hardware connection
RJ-45
10/100 BASE-T Ethernet
SW protocol
TCP/IP
EU863-870
Application level protocols HTTP, Modbus/TCP
SNTP, DHCP, DNS
DIN-rail mounting (acc. to DIN 43380 and EN60715)
Housing DIN-rail Module depth
1 module (18 mm) 35 mm 70 mm
Power supply
Operating Voltage Power consumption Operating Frequency
230 V~ +/- 20% <=1.5 W 45-65 Hz
Wiring Connection
screw head Z +/-
POZIDRIV PZ0
Solid wire min (max) section 0.15 (2.5) mm2
Stranded wire min (max) section 0.15 (4) mm2
Wires acc. to IEC 60332-1-2 if section>= 0.5 mm2, acc. to IEC 60332-2-2 for smaller
sections
EMC Disturbances
Compliant with Conducted emissions and Radio interferences EN 55032 CISPR 32 Class B
EMC Immunity
EN 61000-4-2 – Electrostatic discharge immunity 8kV EN 61000-4-3 – Immunity to radiated RF electromagnetic field EN 61000-4-4 – Electrical fast transient/burst immunity 4 kV on mains circuit 2kV (capacitive clamped) on LAN connector EN 61000-4-5 Immunity to surges 4 kV surge pulses
Electric Safety (acc. to EN 62368-1:2018)
Pollution degree
2
Overvoltage category
III
Working Voltage
300 V
Flammability (acc. to UL 94) class V0
Insulation (acc. to IEC 61140)
II (symbol IEC 60417-5172 (2003-02)) Reinforced Insulation between Mains supply circuit (HLV circuit) and communication circuit (SELV circuit) – a.c. Required Transient Voltage = 4 kV peak – Impulse withstand voltage test (1.2/50 sec pulse) = 7.68 kV peak – AC withstand voltage test (for 5 seconds) =4.18 Vrms – routine AC withstand voltage test = 3,4 kV rms on each single equipment for 1 second
Environmental conditions
Operating Temperature -25°C +55°C
Storage Temperature
-25°C +70°C
Relative Humidity not condensing
yearly average
<= 75%
on 30 days per year
<= 95%
Installation
Indoor
Altitude
<=2000 m.
Degree of Protection
IP20 (*)
(*) The device must be installed inside a cabinet with IP rating IP51 or better. Any exposed parts (outside the cabinet) must have a minimum degree of protection IP51. Furthermore, the cabinet must have a Flammability degree V1 (according to UL-94) or better.
3
DEFAULT VALUES Protocol = Modbus TCP Address = 001 (To connect more than one modbus interface send a command to the 4115 address. Modbus address: #New Id Modbus#) Baud rate <= 100 Mbit/s
ADDRESS MODBUS TABLE
Register Definition
Energy meter
Notes
4099
Triphase Monoph.
Type of device
(0= no communication,
1= triphase,
x
Reading general registers x
3= monophase,)
4100 Interface FW version
x
x
4101
Overflow allarm (0= no overflow)
x
x
4102 Present tariff (0=Tariff1
activated, 1=Tariff2
x
x
activated)
4104 PID (device
identification) bytes 1 e x
x
2
4105 PID bytes 3 e 4
x
x
4106 PID bytes 5 e 6
x
x
4107 PID bytes 7 e 8
x
x
4108 PID bytes 9 e 10
x
x
4109 PID bytes 11 e 12
x
x
4110 PID bytes 13 e 14
x
4111 Type of protocoll
(0=ModbusRT U,
x
1=ModbusASCII)
x Writing registers
x
4112 Speed of transmittion
(1200, 2400, 4800,
x
x
9600, 19200, 38400)
4113
Parity (0= no, 1= even, 2= odd)
x
x
4114 Stop bits (1= 1Bit,
x
x
2=2Bits)
4115 Modbus address (from
x
x
1 to 247)
4116
Command for interface reset
(0= modification
memorized,
x
x
1= 4111- 4115 register
modification
memorized)
4117
Value format
(0= floating points 32bit,
x
x
1= entire)
4118
Command for the
energy meter reset (1=
reset of active energy
register, 2= reset of
x
x
reactive energy
register, 3= reset of all
the registers)
4
4119 Active energy L1, T1,
x
4122
imp (kWh)
4123 Active energy L2, T1,
x
4126
imp (kWh)
4127 Active energy L3, T1,
x
4130
imp (kWh)
4131 Active energy T1, imp
x
4134
(kWh)
4135 Active energy L1, T2,
4138
imp (kWh)
x
4139 Active energy L2, T2,
x
4142
imp (kWh)
x
Reading value register
Concerning register 4117
– if I had float value all the data are in
2 registers
– if I had entire value:
=> 2 registers: (Reg1 * 65536 + Reg2) / 10000
=> 4 registers: ((Reg1 * 65536 +
x
Reg2)* 1000000000) + Reg3 * 65536
+ Reg4) / 10000
4143 Active energy L3, T2,
x
4146
imp (kWh)
4147 Active energy T2, imp
x
4150
(kWh)
4151 Active power L1 (kW) 4152
x
x
4153 Active power L2 (kW)
x
4154
4155 Active power L3 (kW)
x
4156
4157 Active power (kW)
x
4160
4161 Active energy L1, T1,
x
x
4164 exp (kWh)
4165
Active energy L2, T1,
x
4168
exp (kWh)
4169 Active energy L3, T1,
4172
exp (kWh)
x
4173 Active energy T1,
x
4176
exp (kWh)
4177 Active energy L1, T2,
x
x
4180
exp (kWh)
4181 Active energy L2, T2,
x
4184
exp (kWh)
4185 Active energy L3, T2,
x
4188 exp (kWh)
4189 Active energy T2,
x
4192
exp (kWh)
4189 Active energy T2,
x
4192
exp (kWh)
4193 Reactive energy L1, T1,
x
x
4196
imp (kvarh)
4197 Reactive energy L2, T1,
x
4200 imp (kvarh)
4201 Reactive energy L3, T1,
x
4204
imp (kvarh)
4205 Reactive energy T1,
x
4208
imp (kvarh)
4209 Reactive energy L1, T2,
x
x
4212
imp (kvarh)
4213 Reactive energy L2, T2,
x
4216
imp (kvarh)
4217 Reactive energy L3, T2,
x
4220
imp (kvarh)
4221 Reactive energy T2,
x
4224
imp (kvarh)
5
4225 Reactive energy L1, T1,
x
x
4228
exp (kvarh)
4229 Reactive energy L2, T1,
x
4232 exp (kvarh)
4233 Reactive energy L3, T1,
x
4236
exp (kvarh)
4237 Reactive energy T1,
x
4240
exp (kvarh)
4241 Reactive energy L1, T2,
x
4244
exp (kvarh)
x
Reading value registers
4245 Reactive energy L2, T2,
x
4248
exp (kvarh)
4249 Reactive energy L2, T3,
x
4252 exp (kvarh)
4253 Reactive energy T2,
x
4256 exp (kvarh)
4257 Reactive power L1 4258 (kvar)
x
x
4259 Reactive power L2
x
4260 (kvar)
4261 Reactive power L3
x
4262
( kvar)
4263 Reactive power(kvar)
x
4266
4267 Voltage L1-N (V) 4268
x
x
4269 Voltage L2-N (V)
x
4270
4271 Voltage L3-N (V)
x
4272
4273 Voltage L1-L2(V)
x
4274
4275 Voltage L2-L3(V)
x
4276
4277 Voltage L3 – (V) L1
x
4278
4279 CurrentL1 (A) 4280
x
x
4281 Current L2 (A)
x
4282
4283 Current L4 (A)
x
4284
4285 Apparent power L1
x
x
4286
( kV A)
4287 Apparent power L2
x
4288 (kVA)
4289 Apparent power L3
x
4290 (kVA)
4291 Apparent power (kVA)
x
4294
4295 Power factor cos L1
x
x
4296
4297 Power factor cos L2
x
4298
4299 Power factorcos L3
x
4300
4301 Power factor cos
x
4302
4303 Frequency (Hz) 4304
x
x
6
7
74332438
ULTIMA REVISIONE 05/2023
