49086 Shadow-2LT Path Spike Light

SHADOW-2LT-PATH Installation Manual

Thank you for purchasing your new SHADOW-2LT Path Spike. Please
take the time to read and understand the instruction sheet below.
Failure to do so may void warranty.

Specifications

• Voltage: 12V DC
• Lamp: MR16 (not included)
• LED Driver: Required (wire in parallel)
• Power: 2x20W
• IP Rating: 65
• Dimensions:
  • Height: 180mm
  • Diameter: 60mm
  • Depth: 110mm
  • Cable Length: 1000mm
  • Spike Length: 600mm
  • Total Length: 400mm

Note: The lamp must be installed by a professional
electrician. Ensure the power supply is switched off before fitting
this product. Do not touch the lamp when in use. Keep away from hot
steam and corrosive gas.

Description and Item Numbers

• Variant Item No. 49086 – 2LT light, Path spike light. Black
  finish
• Variant Item No. 49180 – 2LT light, Path spike light. Black
  finish, GU10 3000K
• Variant Item No. 49182 – 2LT light, Path spike light. Black
  finish, GU10 5000K
• Variant Item No. 49087 – SHADOW-2LT-PATH 2LT light, Path spike
  light. 316 Stainless Steel finish
• Variant Item No. 49184 – SHADOW-2LT-PATH 2LT light, Path spike
  light. 316 Stainless Steel finish, GU10 3000K
• Variant Item No. 49186 – SHADOW-2LT-PATH 2LT light, Path spike
  light. 316 Stainless Steel finish, GU10 5000K

Product Usage Instructions

1. Ensure the power supply is switched off before fitting the
   product.
2. Insert the MR16 lamp into the fixture.
3. Wire in parallel the LED driver to the power source.
4. Attach the spike to the fixture.
5. Insert the spike into the ground in the desired location.
6. Turn on the power supply and enjoy your new SHADOW-2LT Path
   Spike!

Note: Do not touch the lamp when in use. Keep away from hot
steam and corrosive gas.

May 23, 2022 1:19 pm

29-31 Richland St. Kingsgrove. Sydney NSW 2208 Australia Phone: 02 9554 9600 | Fax: 02 9554 9433
[email protected] | www.domuslighting.com

Installation Manual

SHADOW-2LT-PATH

Variant Item No.

Description

49086

2LT light, Path spike light. Black finish

49180

2LT light, Path spike light. Black finish, GU10 3000K

49182 49087

2LT light, Path spike light. Black finish, GU10 5000K SHADOW-2LT-PATH
2LT light, Path spike light. 316 Stainless Steel finish

49184

2LT light, Path spike light. 316 Stainless Steel finish, GU10 3000K

49186

2LT light, Path spike light. 316 Stainless Steel finish, GU10 5000K

Thank you for purchasing your new SHADOW-2LT Path Spike, Please take the time to read and understand the instruction sheet below. Failure to do so may void warranty.

Specifications

Voltage:

12V DC

Lamp:

MR16 (not included)

LED Driver required (wire in parallel)

Power: IP Rating:

2x20W 65

180mm 60mm
110mm
90° Tilt 270° Swivel

1000mm 600mm

400mm

Note: -The lamp must be installed by professional electrician
-Ensure the power supply is switched off before fitting this product

-Do not touch the lamp when in use -Keep away from hot steam and corrosive gas
