VH-OBTR-01 Orbiter Pan and Tilt Video Tripod Head
Orbiter Pan & Tilt Video Tripod Head (VH-OBTR-01)
Product Information
The Proaim Orbiter Video Tripod Head is a high-grade CNC
Aluminum body that features roller bearings for extreme precision.
It has brakes on the pan and tilt axis for lock-off shots and
camera safety. The Orbiter Pan & Tilt Video Tripod Head can
securely mount to any large or medium camera plate or any large or
medium format camera equipped with 3/8-16 mounting holes. It also
comes with four non-stick rubber feet and marking points for
perfect tilt.
What’s In The Box
- Proaim Orbiter Video Tripod Head
- Flight Case
All rights reserved. No part of this document may be reproduced,
stored in a retrieval system, or transmitted by any form or by any
means, electronic, mechanical, photo-copying, recording, or
otherwise, except as may be expressly permitted by the applicable
copyright statutes or in writing by the Publisher.
Product Usage Instructions
- Inspect the contents of your shipped package to ensure you have
received everything that is listed in the “What’s In The Box”
section. - Attach the Orbiter Pan & Tilt Video Tripod Head to your
large or medium camera plate or any large or medium format camera
equipped with 3/8-16 mounting holes. Ensure that it is securely
mounted. - Use the brakes on the pan and tilt axis for lock-off shots and
camera safety. - Use the marking points for perfect tilt.
- Place the Orbiter Pan & Tilt Video Tripod Head on a flat
surface using the four non-stick rubber feet to prevent it from
slipping.
Note: The Orbiter Pan & Tilt Video Tripod Head is shown with
optional accessories in the image.
1
Orbiter Pan & Tilt Video Tripod Head (VH-OBTR-01)
Assembly Manual
What’s In The Box
Please inspect the contents of your shipped package to ensure you have received everything that is listed below.
Proaim Orbiter Video Tripod Head
Flight Case
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmitted by any form or by any means, electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permitted by the applicable copyright
statutes or in writing by the Publisher.
2
Orbiter Pan & Tilt Setup
· The Orbiter can be tilted to a 25° position by loosening its knob.
NOTE: The Orbit head offers a 360° panning and 25° tilt range with the privilege of precise marking points for perfect tilting.
NOTE: Pan and tilt axis have brakes for lock-off shots and camera safety. This High-grade CNC Aluminum body features roller bearings for extreme precision.
· Attach the camera (Not Included) using the Orbiter Camera Bolt and then tighten it properly, as shown in the image.
NOTE: It securely mounts to any large or medium camera plate or any large or medium format camera equipped with 3/8″-16 mounting holes.
· Mount the Fluid head (Not Included) to the top mounting part of the tripod (Not Included) .
· Match the bottom part of the tripod with the Castle Ring and then tighten it properly.
3
· Push the knob of the Fluid head (Not Included) and remove the plate.
· Attach the Fluid head (Not Included) by matching it to the thread of the Orbiter at the base and then properly tighten it using the screw driver.
· After attaching the Fluid head plate to the Orbiter, attach the Fluid head by sliding it onto the plate, as shown in the image.
Multiple Feature of Orbiter Pan & Tilt Video Tripod Head
Four Non stick Rubber feet
25° Penning 360° Tilting
Marking Points for Perfect Tilt
Lock off shorts & Camera safety
High-End Roller Bearings
4
YOUR PROAIM ORBITER PAN & TILT VIDEO TRIPOD HEAD ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)
Warranty: We offer one year warranty for our products from date of purchase. Within this period of time, we will repair it without charge for labor or parts. Warranty doesn’t cover transportation costs nor does it cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspection and evaluation by us. Liability: We are not liable for damage caused by products that we do not supply or from mishandling in transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company. Contact Us: In case of any kind of dissatisfaction, please Contact us immediately and we promise our utmost support and care until you use our product.
