RE700X Mesh WiFi 6 Extender

Product Information

The product is a Range Extender designed to enhance the Wi-Fi
coverage in your home or office. It helps eliminate Wi-Fi dead
zones by extending the range of your existing router’s signal. The
extender is compatible with most routers and can be set up using
various methods.

Product Usage Instructions

1. Power On

Plug the extender into a power outlet next to your router.
Wait until its Power LED turns solid on.
Note: For safety, only plug the extender in the direction as
shown in the manual.

2. Set Up

Method 1: Via the Tether App

Get the up-to-date Tether app from the Apple App Store or
Google Play, or scan the QR code provided in the manual.
Launch the Tether app and log in with your TP-Link ID. If you
don’t have an account, create one first.
Select “Range Extender” from the device options.
Follow the app instructions to complete the setup. The LED
should turn solid on, indicating a successful connection to your
router.

Method 2: Via a Web Browser

Connect your computer or smartphone to the extender’s network
named “TP-Link_Extender”.
In a web browser, visit either “http://tplinkrepeater.net” or
“http://192.168.0.254”. Create a password to log in.
Follow the web instructions to complete the setup.

Method 3: Via the WPS Button

Press the WPS button on your router.
Within 2 minutes, press the WPS button on the extender for 1
second. The LED should change from blinking to solid on, indicating
a successful connection.
If the extender connects to a dual band router, repeat steps 1
and 2 to connect to the other band.
Extended Network Names: Router’s network name with _EXT at the
end or same as your OneMesh router (See user guide for OneMesh
details)
Passwords: Same as your router

3. Relocate

Plug in the extender about halfway between your router and the
Wi-Fi dead zone. The location you choose must be within the range
of your router.
Wait for about 2 minutes until the LED turns solid blue. If it
doesn’t, relocate the extender closer to the router to achieve
better signal quality.
Tip: To place the extender for optimal Wi-Fi performance,
access extender settings via the Tether app and go to Tools >
Location Assistant, or visit the provided URL.

4. Connect Devices

Connect your devices to the extender wirelessly or via an
Ethernet cable to enjoy the extended internet coverage. The
password of your extended network is the same as your host
router.

Tip: You can also set up the extender in Access Point mode to
transform your existing wired network into a wireless one. Refer to
the user guide for more details.

Access Extender Settings

After setup, you can access extender settings using any of the
methods provided in the manual. This allows you to reselect the
host network, change extended network settings, and more.

View Fullscreen

Quick Installation Guide
Range Extender

1 Power On
Plug the extender into a power outlet next to your router. Wait until its Power LED turns solid on.
Note: For safety, only plug the extender in the direction as shown below.

Setup with videos
Scan the QR code, or visit https://www.tp-link.com/support/setup-video/#range-extenders and search for the setup video of your model.
* Images may differ from your actual product.

Next to

Solid On

2 Set Up
Via the Tether App
1. Get the up-to-date Tether app from the Apple App Store or Google Play, or simply scan the QR code.

3. Tap the button and select Range Extender.
Note: If you cannot find your device, please refer to FAQ > Q1.

or
Tether
Scan for Tether
2. Launch the Tether app and log in with your TP-Link ID. If you don’t have an account, create one first.

My Devices
No devices found.
Choose your device type Router Gaming Router Range Extender
4. Follow app instructions to complete the setup. The LED should turn solid on, indicating successful connection to your router.
Note: If the LED does not turn solid on, please refer to FAQ > Q2.

Welcome to Tether

TP-Link ID (Email)

Password

Solid On

More Setup Methods
Via a Web Browser
1. Connect your computer or smartphone to the extender’s network TP-Link_Extender.
2. Visit http://tplinkrepeater.net or http://192.168.0.254 in a web browser. Create a password to log in.
3. Follow web instructions to complete the setup.
Via the WPS Button
1. Press the WPS button on your router.
2. Within 2 minutes, press the WPS button on the extender for 1 second. The LED should change from blinking to solid on, indicating successful connection.
3. If the extender connects to a dual band router, repeat steps 1 and 2 to connect to the other band.
Extended Network Names: Router’s network name with _EXT at the end or Same as your OneMesh router (See back for OneMesh details) Passwords: Same as your router
For more details, please refer to the user guide at https://www.tp-link.com/support/download.

3 Relocate
1. Plug in the extender about halfway between your router and the Wi-Fi dead zone. The location you choose must be within the range of your router.
2. Wait for about 2 minutes until the LED turns solid blue. If it doesn’t, relocate the extender closer to the router to achieve better signal quality.
Tip: To place the extender for optimal Wi-Fi performance, access extender settings via the Tether app and go to Tools > Location Assistant, or simply scan the QR code to visit https://www.tp-link.com/support/faq/3103/.

Router

Halfway

Blue: Suitable location Red: Too far from router
Devices

Enjoy!
Connect your devices to the extender wirelessly or via an Ethernet cable, then enjoy the internet. The password of your extended network is the same as your host router.
Tip: You can also set up the extender in Access Point mode to transform your existing wired network to a wireless one. For details, refer to the user guide at https://www.tp-link.com/support.

Smartphone

Tablet

Laptop

Smart TV Game Console Desktop

Access Extender Settings
After setup, you can access extender settings via any of the methods below. You can reselect host network, change extended network settings and more.
Note: If your extender and router use the same network name, Method 1 is recommended.
Method 1: Via the Tether App
1. Connect your smartphone to the extender`s or router’s network. 2. Launch the Tether app, select your extender, and log in. 3. View or change extender settings as needed.
Method 2: Via a Web Browser
1. Connect your computer or smartphone to the extender’s network. If you are using a computer, unplug the Ethernet cable if any.
2. Launch a web browser, enter http://tplinkrepeater.net in the address bar, and log in.
3. View or change extender settings as needed.
LED Explanation

LED

Status Indication (For Range Extender Mode)

On/Off The extender is on or off. (Power) Blinking The system is starting up or firmware upgrade is in progress.

(Signal) 2.4GHz

Solid blue
Solid red Blinking
Off

The extender is connected to your router’s wireless network and is in a suitable location.
The extender is receiving a weak signal. Try relocating it closer to your router.
WPS connection is in progress.
No wireless connection is established.

On/Off

The extender is connected or not connected to the 2.4GHz wireless network of your router.

5GHz

On/Off

The extender is connected or not connected to the 5GHz wireless network of your router.

OneMeshTM with Seamless Roaming
TP-Link OneMesh router and extenders work together to form one unified Wi-Fi network. Walk through your home and stay connected with the fastest possible speeds thanks to OneMesh’s seamless coverage.

INTERNET

SAME
Network Name & Password for seamless roaming

Unified Wi-Fi Network
Router and extenders share the same wireless settings, including network name, password, access control settings and more.
Seamless Roaming
Devices automatically switch between your router and extenders as you move through your home for the fastest possible speeds.
Easy Setup and Management
Set up a OneMesh network with a push of WPS buttons. Manage all network devices on the Tether app or at your router’s web management page.
To check full list of TP-Link OneMesh devices, scan the QR code, or visit https://www.tp-link.com/onemesh/compatibility.

Q1. What should I do if the Tether app cannot find my device during setup?
Try another method by following the steps below: 1. Connect your smartphone to the extender’s network TP-Link_Extender.
< Settings Wi-Fi
Wi-Fi CHOOSE A NETWORK… TP-Link_Extender
2. Launch the Tether app, and select your extender.
Tip: If you have connected to the extender’s Wi-Fi but still cannot find your device, try turning off your cellular data.
My Devices
Local Device RExxx XX-XX-XX-XX-XX-XX
3. Follow app instructions to complete the setup. If you are still having problems, contact our technical support.
Q2. What should I do if the LED doesn’t turn solid on after completing setup via the Tether app or web browser?
You may have entered incorrect Wi-Fi password for your host router during the configuration. Check the password and try again. Make sure the extender is close to your router, preferably within 16 feet, and away from large electrical appliances. If you have enabled wireless MAC filtering, wireless access control, or access control list (ACL) on your router, disable them first, then follow any method on the front page to complete the configuration. Try setting it up via the WPS button. Reset the extender and go through the configuration again. If you are still having problems, contact our technical support.

Q3. How do I reset the extender?
With the extender powered on, use a pin to press the Reset button for 1 second. The extender will reboot.
Reset
If you need more setup help, please visit https://www.tp-link.com/support/faq/3074/, or simply scan the QR code.
Safety Information
· Keep the device away from water, fire, humidity or hot environments. · Do not attempt to disassemble, repair, or modify the device. If you need service, please contact us. · Do not use the device where wireless devices are not allowed. · The socket-outlet shall be installed near the equipment and shall be easily accessible. Please read and follow the above safety information when operating the device. We cannot guarantee that no accidents or damage will occur due to improper use of the device. Please use this product with care and operate at your own risk. TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of directives 2014/53/EU, 2009/125/EC, 2011 /65/EU and (EU) 2015/863. The original EU Declaration of Conformity may be found at https://www.tp-link.com/en/support/ce TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of the Radio Equipment Regulations 2017. The original UK Declaration of Conformity may be found at https://www.tp-link.com/support/ukca
To communicate with TP-Link users or engineers, please join the TP-Link Community at https://community.tp-link.com. If you have any suggestions or needs for our product guides, you are welcome to email [email protected]. For technical support, replacement services, user manuals and other information, please visit https://www.tp-link.com/support, or simply scan the QR code.
AX1500/AX1800/AX3000 Wi-Fi 6 Range Extender Model: RE500X/RE600X/RE700X
