Mycket B0brxtps5m Aroma Diffuser User Manual

Mycket B0BRXTPS5M Aroma Diffuser User Manual

This Aroma Diffuser uses Ultrasonic waves to instantly vaporize water and essential oil in the tank, to produce a cool, dry fragrant mist.

OPERATION

1. Please put the product upside, and remove the upper cover Fig 1


2. 2. Please connect the AC adaptor to the base of DC jack of the main body via cable guide. Fig 2


3. Please use the measure cup to supply water from the water pipe. Please take care, do not pour water out of the cup and fll water into the water tank with measuring cup Fig3

   • Water with high temperature and the mist may fly out, please never fill in water during operating
4. Drop essential oil into water tank vertically. The dosage is about 2-3 drops (about 0.1-0. 15ML) per 100ML water. Fig 3
5. . Install the cover of the main body with the original channel. BTW: You must cover the upper cover when you want to use the product.
6. Please connect the AC adaptor with family user power supply socket.
7. If you press the MIST switch on main body of the product. mist function is on. You can set up the timer. each time you press down this button; the timer will be changed between 60 minutes, 120 minutes.180 minutes, ON and OFF Fig 4

   • When the power supply is connected. the original state is OFF
   • lf there is few water in the waler tank. the power supply will turn off immediately even with power connected.
   • If the timing mode is off. LED light will be off at the same Time.
8. Press ‘HIGH/LOW’ to adjust the spray intensity. (Strong or Weak) Fig5


9. If you press the LIGHT on, you can chose ON/OFF state of the LED light. If you press this button for each time, the light color and lightness will be changed. Fig6


10. If you do not use it for a long time, please drain out the water from tank water, dry and then keep it well. If you want to user it again, please use the neutral detergent to clean the water tank again. then you can use it.

The functions of the remote control key correspond and steps:

TTENTION

• The amount and intensity of mist produced will vary, but this is not unusual and should not be considered as a fault.
• Factors that affect this include water type, humidity, temperature, air currents.
• If there is no water in the Tank, pressing the MIST will cause the unit to “beep” 3 times to remind you to add water. The unit will not work without water.
• Only 100% natural essential oil can be used in this product. Those containing chemical fragrance, spice or impurities will cause malfunction. Use 3-5 drops per 100ML water a time. Too much oil will clog the system and cause malfunction. Please clean the unit as per the maintenance instructions, before changing to use a new type of essential oil.

ACCIDENTAL LEAKAGE

In the event of the unit being knocked over or tipped during use. please follow the steps as below to avoid malfunction.

• Unplug the unit and remove cover.
• Pour out any remaining water out of the water tank from.

PRECAUTIONS

Please check below to avoid malfunction of the unit

• Do not fill over 500ML ‘MAX’ at any time
• Do not switch on power when the tank is empty
• Do not touch the Ultrasonic vibration plate
• Clean regularly as per Maintenance instructions to avoid malfunction
• Always unplug from power supply before maintenance
• For hygiene reasons, after use. pour away remaining water from ‘DRAIN SIDE’ of tank, and wipe with a clean dry cloth
• Essential oils can stain. In the event of spillage of contact. please wipe away with a soft cloth
• Only use the measuring cup provided to add water to the tank Never fill directly from the tap
• Do not let mist blow directly onto furniture, clothing, walls etc
• Keep away from directing sunshine heat sources and air conditioners or fans
• Always keep on stable flat surface do not place on carpet, duvet or unstable area
• Keep away from electronic equipment, such as TV and Audio equipment
• Do not tip the product this may cause water to enter the mechanism and cause malfunction
• Do not use for more than 10 hours any time Wait 60 minutes before restart to avoid damage to Ultrasonic plate
• Use tap water only, does not use mineral water, sparkling water elc
• The amount and intensity of mist produced will vary, but this is not unusual and should not be considered as a fault. Factors that affect this include water type, humidity, temperature. air currents
• Never move product in use.
• Do not touch any part of the product with wet hands
• Keep out of reach of children and pets AIso. children being supervised not to play with the produt. Appliance is not to be used by children or persons with reduced physica, sensory or mental capabilities, or lack of experience and knowledge. unless they have been given supervision or instruction
• Keep cord clear of patways, and do not pull forcefully at any point
• If smoke or burning smell is detected, unplug immediately

TROUBLESHOOTING

Please refer to the table below in the event of the product operating abnormally

SPECIFICATIONS

Dimensions; Approx 168 x 121MM
Weight (excluding adaptor): Approx 520g
Power Input / Output: AC100-240V 50 60HZ / DC 24V 650MA
Length of cord:Approx 170CM
Electric consumption:Approx 13W
Time Mode:60/120/180/ON minutes
Tank Capacity:500ML
LED light:9 Bulbs
Materials:Upper parts PP, lower base ABS
Accessories:AC Adapter and measuring jug
Method of mist production:Ultrasonic vibration at approx 24MH
