Exotronic B2 Pre Wired Victron Board User Manual (+ PDF)

Contents hide

1 B2 Pre Wired Victron Board

2 Product Information

3 Warning

4 Specifications

5 Documents / Resources

B2 Pre Wired Victron Board

Product Information

Pre-Wired Victron Boards: These boards are
pre-wired systems designed for efficient charging and power
management.
Mains Charger: Capable of mains charging at up
to 120A.
DC-DC Charging: Provides a charge rate of 30A
and is compatible with smart alternators. It can be configured via
Bluetooth.
Combined Charging: The combined charge rate is
200A. The charge rate can be limited through the Cerbo GX.
240V Inverter: Features a 3000VA / 16A
transfer switch with 5500W surge capacity.

Warning

To maximize the longevity and safety of your new Victron
Pre-Wired Board, please ensure you follow stay within the specified
parameters and connect to the appropriate terminals referring to
the wiring diagram. Failure to do so could result in shortened
lifespan and void your warranty.

Specifications

Board Input Voltage: N/A
Minimum Battery Capacity and Current: 250Ah,
250A Continuous Current
Inverter Constant Output Power @ 25C: 3000VA /
2400W
Inverter Constant Output Power @ 40C:
2200W
Inverter Peak Power: 5500W
Inverter Maximum Efficiency: 93%
Board Zero Load Power (Inverter On): 20W
Board AC Input Voltage Range: N/A
Maximum Charge Current – Mains: 120A
Maximum Charge Current – Solar: 50A
Maximum Charge Current – DC-DC: 30A
Maximum Total Charge Current: 200A
DC-DC Maximum Efficiency: 87%
Output Absorption Voltage: 14.2V –
Adjustable
Output Float Voltage: 13.5V – Adjustable
Battery Protect Trip Voltage: 11.5V for 30s –
Adjustable
Solar Maximum Voltage: 100V
Solar Array Size: 600-800W recommended
Solar Maximum Short Circuit Current: 60A
Solar Maximum Efficiency: 98%
Board Temperature Rating: N/A
Board A2 Dimensions: 780 x 530 x 170mm
Board B2 Dimensions: 1200 x 355 x 170mm
Board Weight: 33kg

More details available on individual component data sheets
if needed.

View Fullscreen

Pre-Wired Victron Boards

Mains Charger Capable of mains charging at up to 120A.
Solar Charging Capable of charging up to 50A. Recommended solar capacity 600 800W.
DC-DC Charging 30A charge rate and compatible with smart alternators and configurable via Bluetooth.
Combined Charging The combined charge rate is 200A. The charge rate can be limited through the Cerbo GX.
240V Inverter 3000VA / 16A transfer switch with 5500W surge capacity

Warning
To maximise the longevity and safety of your new Victron Pre-Wired Board, please ensure you follow stay within the specified parameters and connect to the appropriate terminals referring to the wiring diagram. Failure to do so could result in shortened lifespan and void your warranty.
This equipment contains 240V equipment serious injury and/or death can occur when working with these voltages. Only competent/licenced persons must connect to the 240V supply.
Risk of fire/explosion do not short circuit the equipment or exceed voltages. Always check polarity before powering equipment on. Do not expose to the weather or allow water ingress. Keep out of excess dust and do not exceed temperature ratings. Always select appropriate fuse sizes and ensure suitably tight connections.
© Exotronic 2022

Specifications

Board Input Voltage

11.2 17V

Minimum Battery Capacity and Current

250Ah

250A Continuous Current

Inverter Constant Output Power @ 25C

3000VA / 2400W

Inverter Constant Output Power @ 40C

2200W

Inverter Peak Power

5500W
