2023 Solace eRide Road Electric Bike
2023 SCOTT SOLACE eRIDE ROAD & GRAVEL MANUAL
The Scott Solace eRide is a high-performance electric bicycle
designed for road and gravel riding. It is important to adjust the
bike to the rider’s specifications for maximum safety and comfort.
For advice on adjusting the bike or any technical issues, please
consult your authorized Scott dealer.
Geometry & Technical Data
The Scott Solace eRide has the following geometry and technical
data:
| Road | Gravel | |
|---|---|---|
| A Head tube angle | 69.5 mm | 69.5 mm |
| B Head tube length | 85 mm | 110 mm |
| C Top tube horizontal | 518 mm | 534.2 mm |
| D Standover height | 759 mm | 785 mm |
| E BB offset | 76 mm | 76 mm |
| F BB height | 283 mm | 283 mm |
| G Wheelbase | 1021.5 mm | 1030.1 mm |
| H BB center to TST | 477 mm | 507 mm |
| I Seat angle | 74.5 mm | 74 mm |
| J Chainstay | 435 mm | 435 mm |
| K Reach | 374 mm | 378 mm |
| L Stack | 519.3 mm | 544.7 mm |
| Fork Length | 406 mm | 406 mm |
| Fork Rake | 50 mm | 50 mm |
The bike has a Syncros Duncan D-Shape SL Addict RC Seatpost,
IS52/31.8 IS52/40 mm Headset, and a max tire width of 50mm for both
road and gravel.
Product Usage Instructions
When removing and re-attaching the rear wheel to the frame, make
sure the non-drive side dropout has both the indicated parts
correctly positioned inside the dropout before inserting the rear
axle. The rear axle should be tightened to 10Nm of torque.
The bike comes with several spare parts, including an FD mount
and blank, internal cable guides, cable stay, headset top cap, seat
clamp, front axle, rear axle, dropout, motor cover, chainstay
protector and plate, fender set for road and gravel, TQ smart box,
lockring set, kickstand for road eRide TQ 2 bolt, range extender,
range extender cable for road/gravel, and range extender
holder.
To properly maintain the bike, refer to the TQ System manuals
provided and follow the cable routing instructions for the
mechanical TQ system. The bike’s manufacture’s guarantee is also
included for your reference.
2023 SCOTT SOLACE eRIDE ROAD & GRAVEL MANUAL
2023 SOLACE eRIDE | ENGLISH 1 |
SOLACE eRIDE
CONTENT
THE SOLACE eRIDE SHOULD BE ADJUSTED EXACTLY TO THE RIDER FOR MAXIMUM SAFETY AND RIDEABILITY. Please contact your authorized SCOTT dealer for advice in order to avoid technical problems or any harm.
GEOMETRY & TECHNICAL DATA
03
TQ SYSTEM MANUALS
04
CABLE ROUTING
05
SPARE PARTS
06
MANUFACTURE’S GUARANTEE
09
LEGEND
TORQUE REQUIRED NO GREASE REQUIRED GREASE REQUIRED CARBON GREASE REQUIRED THREADLOC REQUIRED BEARING FIT REQUIRED
T 2
TORX TOOL SIZE
10 Nm TORQUE AMOUNT TASK DIFFICULTY HEX TOOL SIZE
2023 SOLACE eRIDE | ENGLISH 2 |
SOLACE eRIDE
GEOMETRY & TECHNICAL DATA
SEATPOST SEATPOST CLAMP HEADSET REAR AXLE FRONT AXLE MAX TYRE WIDTH
Syncros Duncan D-Shape SL Addict RC Seatpost Clamp mm IS52/31.8 IS52/40 mm 142 mm 100 mm 50 Gravel/50 Road
FORK STEERER
in 1 1/4 – 1 1/2
MAX/MIN FRONT ROTOR mm 180/ 1 60
MAX/MIN REAR ROTOR mm 160/ 140
MY23 SOLACE eRIDE A Head tube angle B Head tube length C Top tube horizontal D standover height E BB offset F BB height Road
BB height Gravel G Wheelbase I BB center to TST J Seat angle K Chainstay L Reach M Stack
Fork Length Fork Rake
XS49
S52
M54
L56
XL58
°
69.5
70
71
71
71
mm
85
110
128
154
175
mm
518
534.2 554.5 578.4 592.5
mm
759
785
803
824
841
mm
76
76
76
76
76
mm
283
283
283
283
283
mm
294
294
294
294
294
mm
1021.5 1030.1 1036.8 1056.2 1071.1
mm
477
507
527
547
567
°
74.5
74
73.5
73
73
mm
435
435
435
435
435
mm
374
378
387
398
406
mm
519.3
544.7 565.6 590.2 610
mm
406
406
406
406
406
mm
50
50
50
50
50
2023 SOLACE eRIDE | ENGLISH 3 |
SOLACE eRIDE
GEOMETRY & TECHNICAL DATA
SOLACE eRIDE
When removing and re-attaching the rear wheel to the frame make sure the non drive side dropout has both the indicated parts correctly positioned inside the dropout before inserting the rear axle.
10 Nm
TQ SYSTEM MANUALS
Charger Manual
Battery Manual
Range Extender Manual
Motor Manual Display Manual
2023 SOLACE eRIDE | ENGLISH 4 |
SOLACE eRIDE
CABLE ROUTING
SOLACE eRIDE
Mechanical TQ System
2023 SOLACE eRIDE | ENGLISH 5 |
SOLACE eRIDE
SPARE PARTS
SOLACE eRIDE
297262 SCO eRIDE FD MOUNT & BLANK SOLACE 23
297135 SCO eRIDE TQ INTERNAL CABLE GUIDE 23
297667 SCO ERIDE CABLE GUIDES C-STAY SOLACE 23
297521 SCO HEADSET TOP CAP CRESTON 23 288249 SYN HEADSET IS52/31.8 – IS52/42
297516 SCO eRIDE INTERNAL CABLEGUIDE 23
2023 SOLACE eRIDE | ENGLISH 6 |
SOLACE eRIDE
SPARE PARTS CONT.
SOLACE eRIDE
277543 SCO SEATCLAMP ADDICT RC 20
277028 SCO AXLE FRONT ADDICT RC/PLASMA 6 TP 20 419858 SCO AXLE SOLACE R 23
10 Nm
286000 SCO DROPOUT SRAM UDH 21 297671 SCO DROPOUT SHIMANO UDH DM 23
25 Nm
Reverse Thread
297263 SCO eRIDE MOTOR COVER SOLACE 23
296623 SYN FRAME PROTECTION KIT SOLACE eRIDE 420008 SCO SOLACE eRIDE CHAINSTAY PROTECTOR 420009 SCO SOLACE eRIDE CHAINSTAY PROTECT.PLATE
2023 SOLACE eRIDE | ENGLISH 7 |
SOLACE eRIDE
SPARE PARTS CONT.
SOLACE eRIDE
292915 SYN FENDER SET SOLACE GRAVEL eRIDE 292914 SYN FENDER SET SOLACE ROAD eRIDE
296220 SCO eRIDE TQ SMART BOX 23
296217 SCO eRIDE TQ LOCKRING SET 23
294533 SYN KICKSTAND ROAD eRIDE TQ 2 BOLT
294537 SCO eRIDE TQ RANGE EXTENDER 294539 SCO eRIDE TQ RANGE EXT. CABLE ROAD/GR 294540 SCO eRIDE TQ RANGER EXTENDER HOLDER
2023 SOLACE eRIDE | ENGLISH 8 |
MANUFACTURER’S GUARANTEE,
When purchasing a new SCOTT bicycle from an authorized SCOTT dealer, SCOTT grants a manufacturer’s guarantee subject to the following provisions.
CONDITIONS The manufacturer’s guarantee is only granted to the first-time buyer of a SCOTT bicycle who has purchased it from an authorized SCOTT dealer. The manufacturer’s guarantee only applies if the bicycle is registered to the first buyer at www.scott-sports.com within ten days of purchase.
DURATION The manufacturer’s guarantee is granted from the date of purchase for a period of five years on bicycle frames and rear ends. The guarantee period is reduced to three years, if the SCOTT bicycle is not serviced at least once a year by an authorized SCOTT dealer. Maintenance services must be carried out in accordance with the maintenance instructions in the SCOTT manual and must be confirmed there by the stamp and signature of the authorized SCOTT dealer. For frames and rear ends of Category 5 bicycle models and for rigid forks manufactured by SCOTT, the duration of the manufacturer’s guarantee is limited to two years. If a defect on the SCOTT bicycle is remedied within the scope of a manufacturer’s guarantee or a warranty claim, the duration of the manufacturer’s guarantee is not extended. The manufacturer’s guarantee ends, when the first-time buyer transfers ownership of the SCOTT bicycle to a third person.
ASSERTION The manufacturer’s guarantee is provided by SCOTT Sports SA, Route du Crochet 11, 1762 Givisiez, Switzerland. The buyer must inspect the SCOTT bicycle immediately after purchase and notify his authorized SCOTT dealer at once in writing of any obvious defects. Hidden defects must be reported immediately after their discovery. In the event of a guarantee claim, the SCOTT bicycle must be handed over to an authorized SCOTT dealer. The latter will contact SCOTT to remedy the defect. The assertion of a guarantee claim always requires the presentation of the original proof of purchase as well as the proof of maintenance service in the SCOTT manual. Performance of SCOTT in the event of a guarantee claim In the event of a guarantee claim, SCOTT will, at its own discretion, repair the defect or replace the defective product with a product of similar quality, whereby colour and model deviations are possible. If a repair or replacement is not possible, a purchase price refund will be made taking into account previous use. SCOTT is entitled to commission third parties to remedy the defect.
LIMITATIONS The manufacturer’s guarantee applies exclusively to frames, swingarms and rigid forks of SCOTT bicycles. Bicycle components are excluded from this manufacturer’s guarantee. The manufacturer’s guarantee does not apply to normal wear and tear, damage caused by accidents or other excessive force on the SCOTT bicycle, corrosion, improper maintenance, incorrect assembly and assembly of unsuitable components or accessories as well as cosmetic defects, for example in the varnish. The manufacturer’s guarantee does not apply to SCOTT bicycles that have been used in a rental shop.
MISCELLANEOUS These manufacturer’s guarantee provisions apply to all SCOTT bicycles as of model year 2023. Statutory warranty rights of the buyer and guarantees of component manufacturers (Shimano, SRAM etc.) remain unaffected by this manufacturer’s guarantee. The place of jurisdiction for all disputes in connection with this manufacturer’s guarantee is Freiburg, Switzerland. This manufacturer’s guarantee is subject to Swiss law to the exclusion of all legislation that refers to foreign law.
2023 SOLACE eRIDE | ENGLISH 9 |
© SCOTT Sports SA 2023. All rights reserved. The information contained in this manual is in various languages but only the English version will be relevant in case of conflict.
P.E.D Zone C1, Rue Du Kiell 60 | 6790 Aubange | BelgiumDistribution: SSG (Europe) Distribution Center SA SCOTT Sports SA | 11 Route du Crochet | 1762 Givisiez | 2022 SCOTT Sports SA www.scott-sports.com Email: [email protected]
