STAIR CLIMBING CART 2125B

Product Information

The Stair Climbing Cart 2125B is a tool designed to help you
carry heavy loads up and down stairs. It has a maximum load
capacity of 150kg when climbing stairs and 250kg on flat ground.
The overall dimensions of the cart are 152.8cm x 45.8cm x
52.3cm.

Product Usage Instructions

Assembly:

Place the reinforcement (E) inside the frame (A) below the hole
and insert the tray (D).
Place the wheel frame (B) on the outside of the frame as shown
in the figure, align it with the hole, and finally fix it with the
outer hexagon bolt (L+N).
Insert the axle (F) into the wheel frame, insert the cotter pin
(K) inside the wheel frame and bend it, and put the gasket (J)
outside.
Install the wheel set (C), insert the cotter pin (K) and bend
it.
Put in handle 2 (H), handle 1 (G), and trim strip (I) in turn,
align them with the holes, and fix them with crosshead bolts
(M+N).

Usage:

Do not put the cart near flammable materials.
Do not carry people on the cart under any condition.
Pay attention to safety when going up and down stairs.
Overload is strictly prohibited.
Do not move too fast when passing potholes areas.

Troubleshooting:

Problem	Reasons	Solution
Wheel rolling is not smooth	Insufficient lubrication	Add oil to lubricate the rotating parts
Velcro is not sticky	The Velcro has sundries	Clean the hair, thread, and other sundries on the Velcro

Maintenance:

Avoid prolonged exposure to the sun to avoid aging.
Avoid children taking the stair climbing cart to play.

If you have any product questions or need technical support,
please contact us at [email protected]. Please read all
manual instructions carefully before operating the cart. VEVOR
reserves clear interpretation of our user manual. The appearance of
the product shall be subject to the product you received. Please
forgive us that we won’t inform you again if there is any
technology or software updates on our product.

View Fullscreen

STAIR CLIMBING CART 2125B
USR MANUAL
We continue to be committed to provide you tools with competitive price.
“Save Half”, “Half Price” or any other similar expressions used by us only represents an estimate of savings you might benefit from buying certain tools with us compared to the major top brands and doses not necessarily mean to cover all categories of tools offered by us. You are kindly reminded to verify carefully when you are placing an order with us if you are actually saving half in comparison with the
top major brands.

STAIR CLIMBING CART
NEED HELP? CONTACT US! Have product questions? Need technical support? Please feel free to
contact us: [email protected] This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appear- ance of the product shall be subject to the product you received. Please forgive us that we won’t inform you again if there are any technology or software updates on our product.
-1-

This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won’t inform you again if there is any technology or software updates on our product.
SAFETY INSTRUCTIONS
WARNING: 1. Please do not put it near flammable materials. 2. It is forbidden to carry people at any condition. 3. Please pay attention to safety when going up and down stairs. 4. Overload is strictly prohibited. 5. Don’t move too fast when passing potholes areas.
Model and Parameters

Model Maximum Load(Flat Ground) Maximum Load(Climb Stairs)
Overall Dimensions

2125B 250kg 150kg 152.8*45.8*52.3cm

Structure Diagram
1
2 4

1.Handle 1 2.Handle 2 3.Frame
4.Trim Strip 5.Climbing
Wheel 6.Wheel Frame
7.Tray

COMPONENTS

A.Frame(x1)

B.Wheel Frame(x2)

C.Wheel Sets(x2)

D.Tray(x1)

E.Reinforcement(x2)

F.Axle(x1)

G.Handle 1(x1)

H.Handle 2(x1)

I.Trim Strip (x1)

J.Washer(x2)

K.Cotter Pin(x4)

L.Outer Hexagon Bolt(x4)

N.Jam Nut(x8)

M.Crosshead Bolt(x4)

O.Installation Tools(x3)

Assembly and Use
1.Place the reinforcement(E) inside the frame(A) (below the hole), and then insert the tray(D).
2.Place the wheel frame(B) on the outside of the frame as shown in the figure, align it with the hole, and finally fix it with the outer hexagon bolt (L+N).
3.Insert the axle (F) into the wheel frame, insert the cotter pin (K) inside the wheel frame and bend it, and put the gasket (J) outside.
4.Install the wheel set (C), insert the cotter pin (K) and bend it.

Put in handle 2 (H), handle 1 (G) and trim strip (I) in turn, align them with the holes and fix them with crosshead bolts (M+N).

Troubleshooting Instruction

Problem Wheel rolling is not smooth
Velcro is not sticky

Reasons Insufficient lubrication
The Velcro has sundries

Solution Add oil to lubricate the rotating parts
Clean the hair, thread, and other sundries on the Velcro

Maintenance

1.Avoid prolonged exposure to the sun to avoid aging. 2.Avoid children taking the stair climbing cart to play.

Manufacturer:Jinhua Development Measuring Tools Co.,Ltd. ADDQiubin industrial park, Wucheng District, Jinhua, Zhejiang province MADE IN CHINA

E-mail: [email protected]
