Direction for use
- Long press the power button for 2 seconds to boot.
- In normal operation, the power indicator is long blue light.
- When the power is low, the indicator lights flash to remind you until the power runs out automatically shut down.
- When the charge is charged, the indicator is blue.
Detection interpretation
| Panel indicator light | PM2.5 value | Air quality |
| Green | 0-50pg/m3 | Excellent |
| yellow | 51-150pg/m3 | Moderate pollution |
| red | 151–999pg/m3 | Severe pollution |
Indicators
- This product adopts a medical-grade low current laser transmitter, with a small laser emission Angle and concentrated energy, Main Parameter which ensures the consistency, accuracy, and stability of product testing.
- This product adopts the temperature and humidity compensation algorithm, which ensures the accuracy of product testing.
- This product adopts a special and accurate air duct design, which ensures the air intake quantity every 30 seconds is 283 ml, ensuring the accuracy and stability of the test.
- The product adopts a heat dissipation design, which ensures the life of the laser transmitter (3000h).
- This product adopts a low noise fan, it is very quiet to use.
Parameters
| Main Parameter | Specifications |
| Battery category | Polymer lithium battery |
| Battery capacity | 1200mAh |
| Working Voltage | 3.7V |
| Working hours | 4-6h |
| Charge time | 3h |
| Charging parameters | 5V/lA |
| Product weight | About 93g |
| Packaging size | 75*75*46mm |
| work Environment | -20°C-50°C |
