Pentair 521910 Intellicenter I8p Single Body Personality Kit Instruction Manual

521910 IntelliCenter i8P Single Body Personality Kit

Product Information:

The product being described in the user manual is an automation
system for load and power centers. It includes various components
such as load centers, power centers, personality kits, accessories,
and expansion kits. The system is designed to provide control and
management of equipment in a body of water, such as a pool or
spa.

The load and power centers are available in different
configurations, with or without support for a salt chlorine
generator. The load center comes with five 3 HP relays, while the
power center does not include relays. The system also includes
IntelliChlor Transformer, which is included with the load center
but not with the power center.

The personality kits determine the type of equipment and
features supported by the system. There are different kits
available for single equipment, shared equipment, and dual
equipment setups. Each kit is identified by a specific code and
includes a motherboard and daughter card. Expansion kits are also
available for adding additional equipment to the system.

Various accessories are offered to enhance the functionality of
the system, including indoor control panels, wireless remote with
transceiver, valve expansion module, pool cover interface expansion
board, Wi-Fi antenna, and SpaCommand remotes with different cable
lengths. Some accessories are included in bundled systems but need
to be ordered separately for a la carte customization.
Additionally, a laptop trainer is available as a training aid for
using the IntelliCenter system.

Product Usage Instructions:

1. Step 1: Pick Your Load and Power Center:
   Choose between the Load Center (with or without Salt Chlorine
   Generator support) or the Power Center (with or without Salt
   Chlorine Generator support). Take note of the product codes: 522042
   for Load Center with support, 522043 for Power Center with support,
   522044 for Power Center without support, and 522041 for Load and
   Power Centers.
2. Step 2: Pick Your Personality Kit:
   Choose the appropriate personality kit based on your equipment
   setup. The available options are i5P, i8P, i10P, i5PS, i8PS, i10PS,
   and i10D. Take note of the product codes for each kit.
3. Step 3: Pick Your Accessories:
   Select the desired accessories to enhance the functionality of your
   IntelliCenter system. These include indoor control panels, wireless
   remote with transceiver, valve expansion module, pool cover
   interface expansion board, Wi-Fi antenna, SpaCommand remotes with
   different cable lengths, and a mudbox accessory for recessing the
   SpaCommand remote into the deck or tile. Refer to the product codes
   for each accessory.

Note: Some accessories may already be included in bundled
systems, but if you are customizing your system a la carte, make
sure to order the necessary accessories separately.

AUTOMATION

INTELLICENTER® CONTROL SYSTEM FOR POOLS AND SPAS

AL A CARTE ORDERING STEP 1: PICK YOUR LOAD AND POWER CENTER

Product 522041

Description LOAD AND POWER CENTERS
Load Center (with Salt Chlorine Generator support)

522042 Power Center (with Salt Chlorine Generator support)

522043 522044

Load Center (without Salt Chlorine Generator support) Power Center (without Salt Chlorine Generator support)

Ordering Information
IntelliChlor Transformer
Included Included Not Included Not Included

STEP 2: PICK YOUR PERSONALITY KIT

Product Description

Body of Water Style

Motherboard

521909 IntelliCenter Personality Kit i5P

INTELLICENTER PERSONALITY KITS

Single

i5P

521910 IntelliCenter Personality Kit i8P

Single

i5P

521911 IntelliCenter Personality Kit i10P

Single

i5P

521912 IntelliCenter Personality Kit i5PS

Shared Equipment

i5P

521913 IntelliCenter Personality Kit i8PS

Shared Equipment

i5P

521914 IntelliCenter Personality Kit i10PS

Shared Equipment

i5P

521915 IntelliCenter Personality Kit i10D

Dual Equipment

i5P

522033* IntelliCenter i5X Expansion Kit

—

i5X

522034* IntelliCenter i10X Expansion Kit

—

i5X

Daughter Card
N/A i8P i10P i5PS i8PS i10PS i10D N/A i10x

No. of Additional Relays**
0 3 5 0 3 5 5 0 5

*Expansion kits use an i5X motherboard. i5P motherboards cannot be used in expansion panels. ** Load center comes with five (5) 3 HP relays.

STEP 3: PICK YOUR ACCESSORIES

Product Description

Notes LOAD AND POWER CENTERS / SPACOMMAND REMOTES

522035 IntelliCenter Indoor Control Panel, White Faceplate

523058 IntelliCenter Indoor Control Panel, Tan Faceplate

523059 IntelliCenter Indoor Control Panel, Black Faceplate

522036 IntelliCenter Wireless Remote with Transceiver

522038Z IntelliCenter Valve Expansion Module

Adds six actuator ports to system (on main load center).

522039Z Pool Cover Interface Expansion Board 522475Z Wi-Fi Antenna (primary client bridge) 521176 SpaCommand Remote, Black with 150 ft. cable 521177 SpaCommand Remote, Black with 250 ft. cable

Supports two covers.
Included in the bundled systems above but must be ordered separately when building a system a la carte.

521178 521179 521180

SpaCommand Remote, White with 150 ft. cable SpaCommand Remote, White with 250 ft. cable Mudbox Accessory for recessing SpaCommand Remote into deck or tile. Includes cover plate and bezel.
INTELLICENTER TRAINING AID

523248 IntelliCenter Laptop Trainer

See page 362 for replacement parts.

31
