DW24T3IXT 24 Inch Built In Dishwasher
Product Information
| Product Dimensions | Side View | Front View | Top View |
|---|---|---|---|
| Width Range | 33 7/8-35 7/8 inches (860-910 mm) | N/A | 34-36 inches (864-914 mm) |
| Height | N/A | N/A | 24 inches (610 mm)* or 23 5/8 inches (600 mm)** |
| Depth | 21 5/8 inches (550 mm) | 23 9/16 inches (598 mm) | N/A |
* with vertical side trims installed
** without vertical side trims
Cutout Dimensions:
| Side View | Front View | Top View |
|---|---|---|
| Width | N/A | 23 9/16 inches (598 mm) |
| Height | N/A | 21 5/8 inches (550 mm) |
Water Drain Placement:
- Minimum: 3 1/8 inches (80 mm)
- Maximum: 5 1/8 inches (130 mm)
Electrical & Water Connection:
- A properly-grounded, horizontally-mounted electrical receptacle
should be installed according to the provided drawing. - To connect the water mains to the water inlet valve thread, use
a 3/8 water inlet hose and 3/4 metal adapter with a length of 60
inches (1524 mm) (not supplied).
Installation Requirements:
- Follow local codes & ordinances for drain
requirements. - Install a waste line with an air gap (not supplied) or,
alternatively, at least 30 inches (762 mm) high drain loop to
prevent backflow. - Drain hose is 74 inches (1880 mm) long. Drain hose must be
connected at a minimum of 20 inches (508 mm) from the floor.
Note: Dimensions in parentheses are millimeters unless otherwise
specified.
Product Usage Instructions
Door Tension Adjustment:
The door tension can be adjusted to accommodate custom panel
weights from 7 lb (3 kg) to 18 lb (8 kg). For custom panels
weighing between 18 lbs (8 kg) and 22 lbs (10 kg), it is necessary
to purchase the optional Heavy Duty Springs kit HS24DW. The
suggested panel thickness is 3/4 inches (20 mm).
33 7/8″-35 7/8″ 860-910
3 15/16″ (100) + 2″ (50) feet adjustment
27″ 687
PRODUCT DIMENSIONS
SIDE VIEW
21 5/8″ 550
1 3/16″- 3 1/8″ (30 – 80)*
FRONT VIEW
23 9/16″ 598
4 1/8″ (105)*
2″ (50)
47 1/4″ 1200
* including a 3/4″ (20) thick custom panel
CUTOUT DIMENSIONS
SIDE VIEW
FRONT VIEW
TOP VIEW
23 9/16″ 598
21 5/8″ 550
WATER DRAIN
POWER
WATER INLET
min 3 1/8″ (80) max 5 1/8″ (130)
Drain hose and toe kick are provided with the unit
TOP VIEW
34″-36″ 864-914
24″ (610)* or
23 5/8″ (600)**
25″ (635)***
* with vertical side trims installed ** without vertical side trims
ELECTRICAL & WATER CONNECTION
*** Cabinet depth shown includes kitchen cabinet front panel. For a flush installation, a minimum inset depth of 22 1/2″ (570) is required with a custom door panel thickness of 3/4″ (20).
CUSTOM PANEL
A properly-grounded,
E horizontally-mounted electrical receptacle should be installed according to this drawing.
To connect the water mains to
W the water inlet valve thread, use a 3/8″ water inlet hose and 3/4″ metal adapter with a length of 60″ (1524) (not supplied).
TOP VIEW
EW
EW
FRONT VIEW
EW
EW
2″ 50
3 15/16″ 100
27 1/16″ – 29 3/4″ 687-757
23 5/16″- 23 7/16″ 592-596
Connections placement must be located on either side of the cutout.
INSTALLATION REQUIREMENTS
Follow local codes & ordinances for drain requirements. Install a waste line with an air gap (not supplied) or, alternatively, at least 30″ (762) high drain loop to prevent backflow. Drain hose is 74″ (1880) long. Drain hose must be connected at minimum 20″ (508) from the floor.
Dimensions in parentheses are millimeters unless otherwise specified.
Door tension can be adjusted to
accommodate custom panel weights from 7 lb (3 kg) to 18 lb (8 kg). For custom panels from 18 lbs (8 kg) to 22 lbs (10 kg), it is necessary to purchase the optional Heavy Duty Springs kit
HS24DW. Suggested panel thickness
is 3/4″ (20).
