Bertazzoni Dw24s2ipb Dishwasher Instruction Manual

DW24S2IPB Dishwasher

Product Information

Product DimensionsValue
Width Range32 1/4 – 34 1/4 inches (820-870 mm)
Height Range3 15/16 inches (100 mm) + 2 inches (50 mm) adjustment
Depth25 1/2 inches (647 mm)

Product Usage Instructions

Cutout Dimensions:

ViewWidthHeight
Side View23 9/16 inches (598 mm)21 5/8 inches (550 mm)
Front View23 9/16 inches (598 mm)4 1/8 inches (105 mm)
Top View32 1/2 – 34 3/8 inches (824-874 mm)24 inches (610 mm) or 23 5/8 inches (600 mm) without side
trims

Electrical & Water Connection:

  • A properly-grounded, horizontally-mounted electrical receptacle
    should be installed according to the provided drawing.
  • To connect the water mains to the water inlet valve thread, use
    a 3/8 water inlet hose and a 3/4 metal adapter with a length of 60
    inches (1524 mm) (not supplied).

Installation Requirements:

  • Follow local codes and ordinances for drain requirements.
  • Install a waste line with an air gap (not supplied) or a
    minimum of 30 inches (762 mm) high drain loop to prevent
    backflow.
  • The drain hose provided is 74 inches (1880 mm) long and should
    be connected at a minimum of 20 inches (508 mm) from the
    floor.

Custom Panel:

  • Door tension can be adjusted to accommodate custom panel
    weights from 7 lb (3 kg) to 18 lb (8 kg).
  • For custom panels weighing from 18 lb (8 kg) to 22 lb (10 kg),
    it is necessary to purchase the optional Heavy Duty Springs kit
    HS24DW.
  • The suggested panel thickness is 3/4 inches (20 mm).

32 1/4 “- 34 1/4″ 820-870
3 15/16″ (100) + 2″ (50) feet adjustment
25 1/2 ” 647

PRODUCT DIMENSIONS
SIDE VIEW
21 5/8″ 550

1 3/16″- 3 1/8″ (30 – 80)*

FRONT VIEW
23 9/16″ 598

4 1/8″ (105)*

2″ (50)

45 2/3″ 1160

* including a 3/4″ (20) thick custom panel

CUTOUT DIMENSIONS

SIDE VIEW

FRONT VIEW

TOP VIEW
23 9/16″ 598

21 5/8″ 550

WATER DRAIN

POWER

WATER INLET

min 3 1/8″ (80) max 5 1/8″ (130)

Drain hose and toe kick are provided with the unit

TOP VIEW

32 1/2″-34 3/8″ 824-874

24″ (610)* or
23 5/8″ (600)**

25″ (635)***

* with vertical side trims installed ** without vertical side trims
ELECTRICAL & WATER CONNECTION

***Cabinet depth shown includes kitchen cabinet front panel. For a flush installation, a minimum inset depth of 22 1/2″ (570) is required with a custom door panel thickness of 3/4″ (20).
CUSTOM PANEL

A properly-grounded,
E horizontally-mounted electrical receptacle should be installed according to this drawing.
To connect the water mains to
W the water inlet valve thread, use a 3/8″ water inlet hose and 3/4″ metal adapter with a length of 60″ (1524) (not supplied).

TOP VIEW

EW

EW

FRONT VIEW

EW

EW

2″ 50
3 15/16″ 100

Connections placement must be located on either side of the cutout.
INSTALLATION REQUIREMENTS
Follow local codes & ordinances for drain requirements. Install a waste line with an air gap (not supplied) or, alternatively, at least 30″ (762) high drain loop to prevent backflow. Drain hose is 74″ (1880) long. Drain hose must be connected at minimum 20″ (508) from the floor.
Dimensions in parentheses are millimeters unless otherwise specified.

25 1/2″ – 28 1/4″ 647-717
23 5/16″- 23 7/16″ 592-596
Door tension can be adjusted to accommodate custom panel weights from 7 lb (3 kg) to 18 lb (8 kg). For custom panels from 18 lbs (8 kg) to 22 lbs (10 kg), it is necessary to purchase the optional Heavy Duty Springs kit HS24DW. Suggested panel thickness is 3/4″ (20).
