31985 Plastic Pipe Moulding Cutter
Product Information:
- Product Name: Plastic Hose and Pipe Cutter
- Model Number: 31985
- Scope: Designed for cutting thick- and thin-walled plastic
tubes and moulding up to 35mm (13/8) in diameter - Compatible Cutting Profiles: Refer to the example
cross-sections in the user manual - Health and Safety Instructions: Keep hands clear of the blade
and cutting area while in use. Use the tool out of direct
sunlight. - Manufacturer: Draper Tools Limited
- Address: Hursley Road, Chandler’s Ford, Eastleigh, Hampshire,
SO53 1YF - Website: drapertools.com
- Email: [email protected]
Product Usage Instructions:
- Place the material to be cut into the tool jaw, with the blade
(1) directed at the vertical center of the workpiece. - Squeeze the trigger (2) slowly and repeatedly to extend the
blade and cut the material. Do not turn the workpiece while
performing the cut. - To retract the blade, press the blade release button (3). Do
not squeeze the trigger while pushing the blade release
button. - To replace the blade, unscrew the retaining screw (4) and
remove the blade guard (5). Lift the blade (1) out of the cutter
body. - Fully extend the blade by squeezing the trigger at least eight
times before replacing it.
Additional Information:
- Do not use the tool to cut reinforced materials.
- If the blade does not penetrate the workpiece, do not continue
to use the tool. - Read the instruction manual and follow all safety
warnings. - Wear suitable eye protection while using the tool.
- Refer to the cutting capacity indicated in the user
manual.
EN
Original Instructions Version 2 February 2023
PLASTIC
HOSE AND PIPE CUTTER
31985
1. Scope
This product is designed for cutting thick- and thin-walled plastic tubes and moulding of up to 35mm (13/8″) in diameter.
Any other application beyond the conditions established for use will be considered misuse. Draper Tools accepts no responsibility for improper use of this product.
Important: DO NOT use this tool to cut reinforced materials. If the blade does not penetrate the workpiece, do not continue to use the tool.
Example cross-sections of compatible cutting profiles.
2. Health and Safety Instructions
WARNING! Keep your hands clear of the blade and cutting area while in use.
·ALWAYS retract the blade when not in use. ·DO NOT allow untrained users to operate
this product. ·Keep this product out of reach of children. ·Store this product in a clean and dry environment,
out of direct sunlight.
Draper Tools Limited, Hursley Road, Chandler’s Ford, Eastleigh, Hampshire, SO53 1YF Website: drapertools.com E -mail: [email protected]
3. Operating Instructions
1. Place the material to be cut into the tool jaw, with the blade (1) directed at the vertical centre of the workpiece.
2. Squeeze the trigger (2) slowly and repeatedly to extend the blade and cut the material. Important: DO NOT turn the workpiece while performing the cut.
2. Unscrew the retaining screw (4) and remove the blade guard (5). (5)
(4)
(1)
(2)
Fig. 1
3. Press the blade release button (3) to retract the blade. Important: DO NOT squeeze the trigger while pushing the blade release button.
(3)
Fig. 4 3. Lift the blade (1) out the cutter body.
(1)
Fig. 2
4. Replacing the Blade
1. Fully extend the blade by squeezing the trigger at least eight times.
Fig. 5
5. Explanation of Symbols
Read the instruction manual
Warning!
Wear suitable eye protection
Fig. 3
Cutting capacity
