71266-66 Harbor View 4-Light Black Outdoor Wall Light
Product Information: Model# 71266-66
The product is a light fixture that can be installed in place of
an old fixture. The fixture comes with mounting hardware and parts
including a candle cover. The installation process involves
shutting off power at the fuse or circuit breaker, removing the old
fixture, and carefully unpacking and laying out the new fixture and
parts. The fixture wires are labeled black (hot), white (neutral),
and green or bare copper (ground).
CAUTION: To avoid the risk of fire, it is recommended to consult
a qualified electrician to ensure correct branch circuit
conductor.
Product Usage Instructions
- Before beginning installation, shut off power at the fuse box
or circuit breaker box. - Remove the old fixture including the mounting hardware.
- Unpack the new fixture and lay out all the parts in a clear
area. - Attach the mounting hardware to the outlet box and secure it in
place. - Connect the fixture wires to the house wires by matching the
colors:
- Fixture wires black (hot) to house wires black (hot)
- Fixture wires white (neutral) to house wires white
(neutral) - Fixture wires green or bare copper (ground) to house wires
green or bare copper (ground)
INSTALLATION INSTRUCTIONS
Model# 71266-66 READ AND SAVE THESE INSTRUCTIONS
W ARNING! SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER.
AVERTISSEMENT! COUPER LE COURANT AU NIVEAU DES FUSIBLES OU DU DISJONCTEUR.
PREPARING FOR INSTALLATION (Fig. 1) 1. Shut off power at the fuse box or circuit breaker box and remove the
old fixture including the mounting hardware. 2. Carefully unpack your new fixture and lay out all the parts in a clear
area. Take care not to misplace any small parts necessary for installation. 3. Separate the base cup (C) by loosening screws (D, 4pcs). 4. Connect electrical wires while supporting the lantern with connectors (E). If your post (A) (not supplied) has a ground wire (green or bare copper), connect the fixture ground wire to it. If not, consult your electrician for proper grounding. After wires are connected, tuck them carefully inside the base cup (C). Align the base cup (C) with post (A) and secure with mounting screws (B). (Fig.1&2) 5. Install (4) four candelabra base bulbs (I) up to 40 Watts, or CFL or LED equivalent (not included), in accordance with the fixture specification. (DO NOT EXCEED THE MAXIMUM WATTAGE RATING) (NE PAS DEPASSER LA ) 6. Attach the frame (F) onto the base cup (C) by using screws (D,4pcs). 7. To replace the glass, remove gaskets (M,8pcs) and loosening the screws (L,8pcs) to remove cover (K). Insert the new glass (J) into the fixture frame from the bottom. Secure the lower cover (K) by screwing screws (L,8pcs) until tight and reinstalling gaskets (M,8pcs) on the lower cover (K). 8. This fixture is ETL listed for wet location applications.
Fig. 1
M L K J
Candle cover:CCV21090PA-66
Your installation is now complete. Return power to the outlet box and test the fixture.
“CAUTION-RISK OF FIRE CONSULT A QUALIFIED ELECTRICIAN TO ENSURE CORRECT BRANCH CIRCUIT CONDUCTOR”
ATTENTION RISQUE D’INCENDIE, CONSULTER UN ÉLECTRICIEN QUALIFIÉ POUR VOUS ASSURER QUE LES CONDUCTEURS DE LA DÉRIVATION SONT ADÉQUATS.
Fig.2
FIXTURE WIRES BLACK
FIXTURE WIRES WHITE
HOUSE
WIRES BLACK (HOT)
FIXTURE WIRES GREEN OR BARE
COPPER (GROUND)
HOUSE
WIRES WHITE
(NEUTRAL)
HOUSE WIRES GREEN OR
BARE COPPER(GROUND)
