Edvivi Ew2525bk Arlo 5 Inch 1 Light Indoor Wall Sconce Instruction Manual

EW2525BK Arlo 5 Inch 1 Light Indoor Wall Sconce

Product Information

The product is a lighting fixture available in three models:
EW2525BK, EW2534BKAB, and EW2541BN. The product has a wire
connection diagram that needs to be followed for proper
installation. The installation process involves attaching the
crossbar to an existing electrical box, passing the main wire and
ground wire through the canopy and the crossbar, and connecting the
wires using electrician-approved junction caps. The product may
contain some pre-installed or pre-assembled parts.

Product Usage Instructions

1. Attach the crossbar (B) to the existing electrical box (A)
   using the two crossbar screws (C), which are not supplied and
   should already be in your box.
2. Pass the main wire (F) and ground wire (D) through the canopy
   (E) and the crossbar (B) until the end of the main wire (F) reaches
   the electrical box (A) where you can wire using electrician
   connections. Be sure to use electrician-approved junction caps (G)
   when connecting the wires. Stow the excess wire in the electrical
   box (A).
3. Raise the canopy (E), attach canopy (E) to ceiling, and hold
   the canopy (E).
4. Insert the light bulb (not included) into the E26 socket
   (2).

WARNING: Improper installation may cause
electrical shock, fire, or equipment damage. The person performing
the installation must be familiar with the construction and
operation of the product and associated hazards. This product can
expose you to chemicals including lead, which is known to the State
of California to cause cancer or birth defects or other
reproductive harm. For more information go to
www.P65Warnings.ca.gov

MOUNTING AND WIRING
WARNING:
Improper installation may cause electrical shock, fire, or equipment damage. The person performing the installation must be familiar with the construction and operation of the product and associated hazards
G

lnstallation lnstructions
Model: EW2525BK /EW2534BKAB /EW2541BN
Customer Service Number: (832) 478-8866 Customer Service Email: [email protected] Please include your name, contact methods, product name, and model number in the email.
IMPORTANT SAFETY INSTRUCTIONS: Please read through all the instructions carefully and completely before beginning assembly and installation This product must be installed in accordance with installation instructions and all safety and building codes. It is strongly suggested that all direct wired fixtures be installed by a licensed electrician Be sure the electricity to the wires you are working on is shut off; either the fuse is removed or the circuit breaker is turned off. Turning the power off using the light switch is not sufficient to prevent electrical shock

GND

BCD F A

Wire Connection Diagram:

Please proceed in an alphabetical order:
. A.Existing EIextricaI BOX B.Crossbar C.Crossbar Screws D.Ground Wire E.Canopy F.Wire G.Junction Caps
. attach the crossbar(B)to the existing eIectricaI box(A) using the two crossbar screws(C)which are not suppIied and shouId aIready in your box.
. Pass the main wire(F)and ground wire(D)through the canopy(E)and the crossbar(B)untiI the end of the main wire(F)reaches the eIectricaI box (A)where you can wire use eIectrician connections.Be sure when connecting the wire use eIectrician approved junction caps(G).stow the excess wire in the eIectricaI box(A).raise the canopy(E),attach canopy(E)to ceiIing,and hoId the canopy(E).

WARNING: This product can expose you
to chemicals including lead,which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more infomation go to www.P65Warnings.ca.gov

PART LIST AND ASSEMBLY ILLUSTRATION

ASSEMBLING, INSTALLATION, AND MOUNTING

Note: Some parts may be pre-installed or pre-assembled.

1

Light Bulb (Not included)

2

E26

(5)*1PC (4)*1PC (3)*2PC
(2)*1PC

1: Lock together
3

(1)*1PC
