QMY061AAA Elegant Beige Twin Size Upholstered Wood Daybed
Product Information
Item No: WF295782/81
Description: Trundle Bed
The Trundle Bed is a quality product that comes with pre-drilled
holes and pre-assembled threaded rods. It includes armrests, metal
rails, metal center, headboard panel, slat roll, trundle cushion,
inner face trundle back, and trundle side plate with mount wheels.
The product is shipped in a carton, and it is advised to check all
packing material carefully for small parts that may have come loose
during shipment.
Product Usage Instructions
Step 1:
Assemble the Bun Foot(B) with the Armrest L/R(A) into
pre-drilled holes on the bottom of Armrest. Use the Thread Bolt(L),
put onto pre-drilled holes nut and secure by hand. Avoid
overtightening.
Step 2:
Loosen the bolts of the Arm Control Panel L/R(A), intended to
hook metal Rail(D) and metal center(E) securely set to the bolt.
Bring the Headboard panel(C) which has pre-drilled holes at both
ends, to the L/R Arm(A) with two pre-assembled threaded rods, by
using the Flat Washer (M), Hex Nut(N). Finally, tighten them with
the Allen Key(P), Open Wrench(O) as guide.
Step 3:
Place the pre-assemble clusters Slat roll(F) in the side
rails(D). Check the direction of the arrow, place it straight out
ahead, and arrange it neatly. Then, tighten it by Screws(Q).
Step 4:
Assemble the Thread Bolt(L) put onto pre-drilled holes nut for
both Trundle Cushion(G) and the inner face Trundle back(I), and
secure by hand.
Step 5:
Place the Trundle side plate(H) with mount wheels to put the
back face Trundle Cushion(G) and the inner face Trundle back(I),
which has four pre-assembled threaded rods, by using the Washer
Semicircle(K), Hex Nut(N). Finally, tighten them with the Open
Wrench(O) as guide.
ASSEMBLY INSTRUCTIONS Item No : WF295782/81 Description : TRUNDLE BED
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small part that may have come loose inside the carton during shipment.
2#)’1(
/#&’+08+’60#/
ASSEMBLY INSTRUCTIONS Item No : WF295782/81 Description : TRUNDLE BED
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small part that may have come loose inside the carton during shipment.
C D
A
B
2#46.+56WF295781
0Q
&GUETKRVKQP
#
#TO2CPGN.4
$
$WP(QQV
2#46.+56WF295782
0Q
&GUETKRVKQP
% *GCFDQCTFRCPGN
&
5KFG4CKN
‘ %GPVGT5WRRQTV5NCV
(
5NCVU4QNNU
) 6TWPFNG%WUJKQP
*
6TWPFNG5KFG
+
6TWPFNG$CEM
, 6TWPFNG5WRRQTV5NCV
2#)’1(
F
E D
A
B I
F H
5MGVEJ 5MGVEJ
3WCPNKV[
2%5 2%5
3WCPNKV[
2% 2%5 2% 5’6 2%5
H
G J
*#4&9#4’.+56WF295781
0Q
&GUETKRVKQP
–
9CUJGT 5GOKEKTENG
. 6JTGCF$QNV
/ (NCV9CUJGT
0 *GZCIQPCN0WV
1 1RGP9TGPEJ
2 #NNGP-G[
3
5ETGY
5MGVEJ
5KG
3WCPNKV[
. 2%5
13mmL
Ä. 2%5
/ /Ä. Ä.
2%5 2%5 2% 2% 2%5
2%5
2%
611.54’37+4’&
0QVRTQXKFGF
2%
5ETGYFTKXGT
/#&’+08+’60#/
ASSEMBLY INSTRUCTIONS Item No : WF295782/81 Description : TRUNDLE BED
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small part that may have come loose inside the carton during shipment.
Step 1. Assemble the Bun Foot(B) with the Armrest L/R(A) into pre-drilled holes on the bottom of Armrest. Please avoid overtightening. Besides, use the Thread Bolt(L), put onto pre-drilled holes nut and secure by hand.
A
13mmL
L B
. 6JTGCF$QNV
13mmL
Ä. 2%5
Step 2. Before performing this step, please loosen the bolts of the Arm Control Panel L/R(A), intended to hook metal Rail(D) and metal center(E) securely set to the bolt. Besides, pay attention to also bring the Headboard panel(C) which has pre-drilled holes at both ends, to the L/R Arm(A) with two pre-assembled threaded rods, by using the Flat Washer (M), Hex Nut(N). Finally, tighten them with the Allen Key(P), the Open Wrench(O) as guide.
N
A
P
M O
D
A 2#)’1(
E
C
/ (NCV9CUJGT
0 *GZCIQPCN0WV
D
1 1RGP9TGPEJ
2 #NNGP-G[
/ /Ä.
2%5 2%5 2% 2%
/#&’+08+’60#/
aâ
ASSEMBLY INSTRUCTIONS
Item No : WF295782/81
Description : TRUNDLE BED
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small part that may have come loose inside the carton during shipment.
Step 3. Note: before placing the pre-assemble clusters Slat roll(F) in the side rails(D), it is advisable to check the direction of the arrow, place it straight out ahead and arrange it neatly. Then, tighten they are by Screws(Q).
F
Q
D
3
5ETGY
Step 4. Assemble the Thread Bolt(L) put onto pre-drilled holes nut for both Trundle Cushion(G) and the inner face Trundle back(I),and secure by hand.
Ä. 2%5
13mmL
L
13mmL
I
G
2#)’1(
. 6JTGCF$QNV 13mmL
Ä. 2%5 /#&’+08+’60#/
ASSEMBLY INSTRUCTIONS
aâ
Item No : WF295782/81
Description : TRUNDLE BED
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small part that may have come loose inside the carton during shipment.
Step 5. Place the Trundle side plate(H) with mount wheels to put the back face Trundle Cushion(G) and the inner face Trundle back(I), which has four pre-assembled threaded rods, by using the Washer Semicircle(K), Hex Nut(N). Finally, tighten them with the Open Wrench(O) as guide.
H
K
G
N
O
I
H
Step 6. Place put the Trundle support slat(J) with mount wheels the into the Trundle side(H). Then, put the Slat roll(F) and arrange it neatly. Finally, all togethertighten they are by Screws(Q) as guide.
F G
H 2#)’1(
J Q
I
3
5ETGY
Ä. 2%5 /#&’+08+’60#/
ASSEMBLY INSTRUCTIONS Item No : WF295782/81 Description : TRUNDLE BED
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small part that may have come loose inside the carton during shipment.
Step 7. Push drawers under the bottom of Bed.
