Jewenwills TLA-60-12DW WiFi Landscape Power Unit
Product Information
The Wi-Fi Landscape Power Unit (model TLA-60-12DW) is a low-voltage transformer designed to power landscape lighting fixtures. It has a maximum capacity of 60 watts and features Wi-Fi connectivity for remote control and automation via a smartphone app. The transformer has status and power indicators, as well as a power button for manual control. It supports 2.4GHz Wi-Fi networks and can be mounted on a wall.
Product Usage Instructions
- Calculate Lighting Capacity: Determine the total wattage of all the fixtures to be connected to the transformer. Ensure that the total wattage does not exceed the 60-watt capacity of the transformer.
- Installation Instructions: Before connecting to the Wi-Fi router, refer to the installation instructions provided. Install the Wi-Fi Low Voltage Transformer before proceeding with the Wi-Fi router connection.
- Status Indicator: The status indicator on the transformer has three states: the blinking light indicates readiness to connect to the Wi-Fi router, the continuously on light indicates a successful connection to the Wi-Fi router and light off indicates a possible internet connection issue or the need to review the app’s FAQ section.
- Power Button: The power button on the transformer allows manual override of the Wi-Fi control. Pressing this button turns the unit ON or OFF.
- Cable Preparation: Carefully split the landscape cable without exposing the copper wire. Remove 1/2 inch of insulation from both cable ends and twist the ends.
- Cable Connection: Lay the transformer on a flat and stable surface. Use a screwdriver to connect the stripped ends of the cable under the terminal clamping plate. Verify the strength of the connection by gently pulling on the landscape cable.
- Fixture Placement and Cable Routing: Position your fixtures in the desired locations, ensuring that they do not exceed the 60-watt rating of the transformer. After connecting the last fixture, coil the remaining cable.
- Fixture Attachment: Turn the transformer ON. Use cable connectors to attach your fixtures to the cable. The fixtures should light up once properly attached.
- Transformer Mounting: Use screws to mount the transformer directly on a wall. It is recommended to mount it between 12 to 48 inches (0.3m to 1.2m) high from the ground.
- Software Installation: Download and install the Dewenwils app from Google Play or the App Store. Each device can only be connected to one account. If others need control access, share your device via the app.
- Add Wi-Fi Low Voltage Transformer: Open the app and follow the instructions to add the Wi-Fi Low Voltage Transformer. Note that it only supports 2.4GHz networks.
- LED Status: The LED indicators on the transformer have different functions. A red LED on indicates power is on, while a red LED off indicates power is off. A rapidly blinking green LED indicates Bluetooth provisioning network status and a steady green LED indicates a successful internet connection.
- Connection Troubleshooting: If the automatic connection fails, try reconnecting or switching to a stronger Wi-Fi signal source. Keeping your phone closer to the device or following the manual connection mode may also help.
Please pay attention to the warning signs
Read the instructions with caution before operating
and keep it properly
WARNING:
READ ALL INSTRUCTIONS before using the Wi-Fi Low Voltage Transformer. Compatible with 2.4 GHz Wi-Fi networks. If you have multiple routers in your home, especially under the same modem and using dynamic IP address mode, please notice the routers with same LAN IP address may cause IP address conflict and make the routers involved cannot access internet. Which makes Wi-Fi Low Voltage Transformer cannot be discovered and controlled via internet (like user’s cellular data service).Important safety information to reduce risk of fire injury.
- 1. Do not install within 10 feet (3 m) of a pool, spa or fountain.
2. No serviceable parts inside the power supply unit. DO NOT DISASSEMBLE.
3. Do not repair or tamper with cord or plug.
4. Do not submerge transformer in water.
5. Do not mount the transformer onto combustible material.
6. Do not connect two or more transformers in parallel.
7. Do not use the transformer with a dimmer switch.
8. Plug the power supply unit directly into a GFCI outlet in wet location.
9. For low voltage outdoor landscape lighting system use only
10. The maximum output of this transformer is 60 watts. Do not overload the transformer. Be sure that the total cumulative wattage of all 12 volt fixtures connected to the transformer be equal to or less than 60 watts.
CAUTION:This landscape light system must be installed in accordance with all local codes and ordinances. If you encounter problems, contact a qualified electrician.
CALCULATE LIGHTING CAPACITY:
The 60 Watt transformer has 60 watt circuits which will power up to 60 watts of light. To make sure the maximum number of fixtures can be safely connected to this transformer, add up the individual wattage of all the fixtures. The total wattage of your fixtures must not exceed output capacity of the 60 Watt transformer.
Installation Instructions:
IMPORTANT:Please refer to INSTALLATION INSTRUCTION before proceeding with Wi-Fi router connection. Wi-Fi Low Voltage Transformer must be installed before connecting to Wi-Fi router.
- Status Indicator
BInking Llgh: Roady to connect to Wi-Fi router.
Light continuously ON:Connection to W-Fi routar is complete and W-Fi Low Voltage Transformer is rsady for use via the app.
Light OFF: Check your intenet cannection or review the app FAQ.
Power Indicator
Power Button
Press thIs button to manually override the WI-FI Low Voltage Transformer and turn the unit ON/OFF.
INSTRUCTIONS:
1.Prepare the Cable
Be careful when splitting the landscape cable. Do NOT expose the copper cable. Remove 1/2 inch of insulation from both cables and twist the ends.
2.Connect the cable to the Transformer
Lay the transformer on a flat, stable surface and use screwdriver to connect the stripped ends of the cable under the terminal clamping plate.
Note: Gently pull on the landscape cable to verify if the connection is strong.
3.Place Your Fixtures and Route the cable
Lay your fixtures (not included) to your desired location. Be sure they do not exceed the 60-watt rating of the transformer. Coil the rest of the cable after connecting the last fixture.
INSTRUCTIONS:
STEP 1: Software Installation
Download the “dewenwils” App: Scan QR Code or search “dewenwils” in Google Play or the App Store to download and install the app.
Note: All pictures shown are for illustration purpose only, the APP will be updated continuously, please refer to the latest APP interface to operate.
STEP 2: Log in or Sign up
Note: Each device can only be connected to one account. If anyone else needs to control it, please share your device via the app.
STEP 3: Add the Wi-Fi Low Voltage transformer
Note:The Wi-Fi Low Voltage transformer only support 2.4GHz network.
- • Please press and hold the power button until the WiFi signal indicator flashes, then release the buttons. Then add the device.
• The Wi-Fi Low Voltage transformer only work with 2.4GHz network. If your router broadcasts both 2.4GHz and 5GHz, please select the 2.4GHz network with the app. If connection still fails, we recommend you call your ISP and had them completely shut off the 5GHz network on the router. You are free to change the network to 5GHz again after connecting.
• Please try to make the Wi-Fi Low Voltage transformer and router as close as possible.
Auto Add Mode (Bluetooth Mode)
- • Turn on Bluetooth on the smartphone.
• Open the “dewenwils” APP （Figure 1）and click the “+” at the top right list, it will find the Wi-Fi Low Voltage transformer automatically. （Figure 2）Tap “Go to add”, the interface in Figure 3 will appear, click the button to switch to the appropriate WiFi signal source, then type in WiFi password and click “next” to enter the interface in Figure 4. At this time the device is connecting to your home WiFi automatically. The prompt in Figure 5 will appear after connecting successfully.
• If the Wi-Fi Low Voltage transformer is not automatically discovered, select “Auto Scan” to automatically search for the Wi-Fi Low Voltage transformer.（Figure 6）After clicking “next”, Figure 3 will appear, then type in correct password and click “next”, Figure 7 and Figure 8 will appear in sequence to remind you that the connection is successful.
Note: Automatic connection time of devices varies depending on the strength of WiFi signal, so please do not operate the phone. If the connection fails, please reconnect, or switch to other stronger WiFi signal sources, or keep your phone closer to the device, or connect it by following the Manually Mode below.
1.Add Manually Mode
- • Click the “+” icon at the right corner and then choose the ” Wi-Fi Low Voltage transformer”. (Figure 9)
• Please check the mode on the left side of at the top right corner, if it is not “EZ Mode”, please switch to “EZ Mode”. In step ②, please press and hold the RESET button on the transformer for more than 5 seconds, and release the button when the indicator flashes. In step③, click “Confirm the indicator is blinking rapidly”, and click “Next”). As shown in Figure 10 to 12.
• Select 2.4GHz Wi-Fi Network and enter password, then click ”NEXT”. Wait for the connection to complete. (Figure 13)
• Wi-Fi Low Voltage transformer has been added successfully. (Figure 14)
STEP 4:Set the Function You Need 1.Interface Introduction
- Change Device Name ON/OFF button
Timer Setting Button Current time setting display
2.Timer Function Introduction
Tap “Timer”, the interface of Timer Schedule will appear.(Figure 16)
3.Countdown
Tap “Countdown” to set the hours and minutes, and then tap the “ ” button. The Wi-Fi Low Voltage transformer will maintain the current state on or off until the end of the countdown. It will exit countdown mode automatically if you turn on/off manually. (Figure 17, 18)
4.Schedule
Tap “Schedule” to enter the interface as shown in Figure 19. You can set the Start/End time in a 7-day period with a 1 minute interval according to needs. Every program set before repeats weekly.(Figure 20, 21) Tap
“Save” to return and review the overall schedule, (Figure 21)5.
Circulate
You can set the duration of each ON and OFF, Start and End time accord-ing to your needs. The ON/OFF schedule will repeat between the Start and End time. For example: Set a period from 9:00 AM to 3:00 PM on Monday through Friday, turn on your light for 1 hour , and off for 30 minutes. The outlet will repeat ON/OFF from 9:00 AM to 3:00 PM. (Figure 23, 24)
6.Random Either +/-30 minutes than setting ON/OFF time, randomly control device when you are away from home.
7.Astronomical
The controlled device will turn on or off at (before or after) sunset or sunrise.
Work with Amazon Alexa Link dewenwils account to Alexa
1. Open your Alexa app, tap “Skills” in the menu, and then search “Smart Life” , select “Smart Life ” and tap “Enable” to enable the Smart Life skills.
2. You will be directed to the account link page. Type in your “dewenwils “account and password, don’t forget to select your country/ region where your account belongs to. And then tap “Link Now” to link your dewenwils account.
Control your smart devices
Discover devices: Echo needs to discover your smart devices before controlling them.You say “Alexa. discover devices” to Echo. Echo will discover devices that have already been added in “dewenwils “app.You can also tap “discover devices” to discover the smart devices.
Discovered devices will be shown in the list.
Note: Every time you change the device’s name on the dewenwils app, Echo must re-discover before you control them.
Work with Google Home
Preparation
- 1. Make sure the smart device has been added to the dewenwils App and the device is online.
2. Make sure the Google Home App is installed.
Start
- 1. Click Me in the bottom right corner, click Google Assistant, click Link with Google Assistant.
2. The App will pull up the Google Home App, click Link.
3. Click agree Link.
4. Wait for it to finish loading, your smart devices will be synced to Google Assistant or Google Home App that can control them. Next, you can assign rooms to your devices in the Google Home App.
Other Functions
CABLE SELECTION CHART
AWG1 Not recommended for Halogen Landscape.
NOTE: This data is provided as a general guideline.Actual
performance aill depend on the installation layout,the fixtures,
and the condition of the cable. If the wire diameter you use is
thinner than the wire diameter recommended in the table, it
may cause the flickering of the end lamps.
Specifications:
- Model: TLA-60-12DW Wi-Fi
- Input Voltage: 120VAC, 60Hz
- Output: 12VDC
- Max Power Rating: 60W
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth
for an uncontrolled environment.
This equipment should be installed and operated with
minimum distance 20cm between the radiator& your body.
This device complies with Part 15 of the FCC rules. Operation is subject to
the following two conditions:
1) this device may not cause harmful interference, and 2) this device must
accept any interference received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved by the party responsible
for compliance could void your authority to operate the equipment.
Note:This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy, if
not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
● Reorient or relocate the receiving antenna.
● Increase the separation between the equipment and receiver.
● Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
● Consult the dealer or an experienced radio/TV technician for help.
FCC STATEMENT:
One Year Limited Warranty
Supported by our professional R&D team and QC team, we provide One
Year Warranty for materials and workmanship from the purchase date.
Please note that the warranty does not cover damage caused by personal
misuse or improper installation.
Please attach your Order ID and Name so that our dedicated customer
service team can help you better.
