230-B2L Hef-T-Bracket Wall Bracket
Product Information
| Item code | Wall-bar length | Arm length | Load capacity |
|---|---|---|---|
| 230-B2L | 880 mm / 34.65 in. | 550 mm / 21.65 in. | 140 kg / 310 lbs |
DiversiTech Corporation
3039 Premiere Pkwy, Suite 600
Duluth, GA 30097
Product Usage Instructions
Hef-T-Bracket Installation – 230-B2L
To install the Hef-T-Bracket 230-B2L, follow the steps
below:
- Identify a suitable brick wall or wooden strut to mount the
bracket onto. - Ensure that the external unit is properly positioned and
aligned with the desired location for installation. - Hold the bracket against the wall or wooden strut at the
desired height. - Use a suitable tool to screwlessly hook the bracket onto the
wall or wooden strut. - Once hooked, lift the bracket up to unlock and regulate its
position if necessary. - Verify that the bracket is securely attached and properly
aligned. - Proceed with attaching the load or equipment to the
bracket.
Note: The Hef-T-Bracket 230-B2L has a load capacity of 140 kg /
310 lbs. Ensure that the load being attached does not exceed this
limit.
Hef-T-Bracket Installation – 230-B2L
Screwless hooking
WOODEN STRUT
406 406
Wooden wall from 0° to 15°
Li up to unlock and regulate
from 0° to 15°
Brick wall
EXTERNAL UNIT
Item code Wall-bar length
Arm length
Load capacity
230-B2L 880 mm / 34,65 in. 550 mm / 21,65 in. 140 kg / 310 lbs
DOCXXXXXX DiversiTech Corporation 3039 Premiere Pkwy, Suite 600 Duluth, GA 30097
