589539 Double Sided LED Mirror and Wireless Charger
Product Information
The Double Sided LED Mirror & Wireless Charger is a
versatile product that combines a makeup mirror with a wireless
charging function. It features a 90 mm size and offers convenient
makeup application and charging capabilities in one device. The
mirror has a fill light switch for enhanced visibility during
makeup application. The wireless charging area supports Qi
compatible devices and has a Type-C input for power.
The product comes with a 10X magnification makeup mirror, a
base, instructions, and a Type-C charging cable. It has a rated
power of 10W and operates with a Type-C input of 5V 2A or 9V 2A.
The wireless output for charging is 5V 1A or 9V 1.1A.
Item No.: 25169 589539
Product Usage Instructions
- Connect the Type-C charging cable to the charging port of the
mirror. - Place your Qi compatible device on top of the wireless charger,
ensuring that it is face up and centrally positioned. - When the wireless charging is working correctly, a white light
will turn on. - To adjust the light color, touch the switch once. There are 3
color options available.
Note: If your phone has a protective case, you may need to
remove it for a successful connection when using the wireless
charger.
Warnings
- Avoid placing any metal objects between the charger and the
mobile device during the charging process to prevent risks. - Do not use mobile devices with a metal case when using the
wireless charger. - Keep the product out of reach of children.
FCC Statement
This device complies with Part 15 of the FCC Rules. It does not
cause harmful interference and accepts any interference received,
including interference that may cause undesired operation.
The product is a Class B digital device that meets the limits
set by Part 15 of the FCC Rules. These limits provide reasonable
protection against harmful interference in residential
installations. Improper installation and use may result in harmful
interference to radio communications.
Any changes or modifications not approved by the responsible
party may void the user’s authority to operate the equipment.
Maintain a distance of at least 20cm between the user and the
product.
Product dimensions: 110 mm
90 mm
Double Sided LED Mirror & Wireless Charger
It is recommended to read this user manual carefully and keep it for future reference.
90 mm
90 mm
90 mm
Product Overview Makeup Mirror Fill light switch Wireless charging area TYPE-C Input
10 X Makeup mirror 6 Base 7 Instructions 8 TYPE-C Charging cable
1
2 4
3
5 7
6
8
Specifications
Type-C Input: 5V 2A,9V 2A Wireless Output: 5V 1A, 9V 1.1A, Rated Power: 10W Item No.:25169 589539
Operation:
1. Connect the cable to the charging port 2. Put your Qi compatible device on top of the wireless charger, ensuring that it is
face up and centrally positioned. 3. When the wireless charge is working correctly a white light will turn on. 4. Touch the switch once, the light color will change. There are 3 color options.
Note: If your phone has a protective case you may need to remove it for a successful connection when using the wireless charger.
Warnings:
1. Do not expose this product to rain or damp conditions. 2. Prevent this ítem from falling as it could cause serious damage. 3. Do not dismantle, repair or modify this product by yourself, contact an authorized specialist. 4. In order to avoid any risk, do not dispose of this product inappropriately or throw it into the fire. 5. Clean it with a dry cloth. 6. Do not place this ítem near sources of heat or expose to direct sunlight. 7. Do not insert any metal objects into this device as there is a risk of causing a short circuit in
the unit. 8. To avoid risk, do not place any metal objects between the charger and the mobile device
during the charging process. 9. Do not use mobile devices with a metal case. 10. Keep out of reach of children.
FCC statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation
This device has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This device generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this device does cause harmful interference to radio or television reception, which can be determined by turning the device off and on, the user is encouraged to try to correct the interference by one or more of the following measures: –Reorient or relocate the receiving antenna. –Increase the separation between the device and receiver. –Connect the device into an outlet on a circuit different from that to which the receiver is connected. –Consult the dealer or an experienced radio/TV technician for help
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment The distance between user and products should be no less 20cm
110 mm
