FP-100 Attachable Biometric Detecting Device

Attachable Biometric Detecting Device

Product Name, Design, Structure and Dimensions

The electronic ear-tag device is attached to the cow’s ear and
detects the estrus period by measuring the temperature and its
activity. The measured data is transferred to the server through
the wireless Bluetooth network and analyzes the estrus period,
disease and delivery period. The server sends these collective data
to the farm owners through their smartphone.

Product Name

• Part Name: Attachable Biometric Detecting Device
• Rated: 2nd grade
• Type: FP-100

Design and Structure

(1) Main Body

• Front
• Backside Cap (Locker)
• Back Side

(2) Spare Parts

Dimension and Volume

(1) Body

• Net Weight(g): 23

(3) Characteristic Parameter Performance

Raw Material / Ingredient and Quantity

Performance and Purpose of Use

– Collects data of body temperature and number of activities
from cow’s ear.

Purpose of use:

• Device designed to detect and alarm the estrus and signs of
  livestock activity with the body temperature and amount of activity
  data collected from the ear.
• Supporting APP (application) and related software for detecting
  estrus and managing disease.

How to Operate / How to Use

Warnings before use:

1. Before use, sanitize the penetrating area and device pin.
2. Power on the inner battery by removing the magnet attached in
   front of the main body of the device.
3. Run a second set of sanitizations on the penetrating area after
   embedding the device.

Attach the ear-tag:

1. Prepare the applicator, main body, and cap as shown in the user
   manual.
2. Sanitize the cow’s ear and the device pin.
3. Hold the applicator and insert the device pin into the cow’s
   ear.
4. Push the main body into the applicator to embed it into the
   ear.
5. Remove the applicator and check if the device is properly
   attached to the cow’s ear.

How to use:

1. Pair the device with your smartphone through wireless Bluetooth
   network.
2. The device will automatically collect and transfer data to the
   server through Bluetooth network.
3. The server will analyze the collected data and send the results
   to your smartphone through the supporting APP.

How to Store and Validity

Store the device in a cool, dry place away from direct sunlight
and moisture. The validity of the device is based on the
manufacturer’s recommendation and usage instructions.

Test Regulation/Specification

The device complies with the manufacturer’s test regulation and
specification. Please refer to the user manual for more
information.

Matters of Statement and Others

Please refer to the user manual for any other matters of
statement and instructions.

Technical document of Attachable Biometric
Detecting Device

Contents 1) Product Name, Design, Structure, and Dimensions 2) Raw material / ingredient and quantity 3) Manufacturing method 4) Performance and purpose of use 5) How to operate / How to use 6) How to store and validity 7) Test regulation/specification 8) Matters of statement and others

1) Product Name, Design, Structure and Dimensions
Definition The electronic ear-tag device is attached to the cow’s ear and detects the estrus period by measuring the temperature and its activity. The measured data is transferred to the server through the wireless Bluetooth network and analyzes the estrus period, disease and delivery period. The server sends these collective data to the farm owners through their smartphone.
Product Name – Part Name: Attachable Biometric Detecting Device – Rated: 2nd grade – Type: FP-100
Outline – This product is used as a principle to detect the time of estrus of cattle, by using the phenomenon that their sign of estrus is detected when their body temperature continuously rises to about 1°C from their average temperature and their amount of activity also increases to 4~10 times than norms. By embedding a temperature sensor inside the penetrating part of their ear, it minimized the possibility of being affected by the external temperature. With the three-axis acceleration sensor embedded inside, it detects the amount of activity with the number of changes made in the x, y, and z axes. The measured data is analyzed through the server’s algorithm and transmitted to the farm owner through their smartphone. In addition, through the analyzed data of changes in body temperature and activity, it provides the identified disease and delivery period.

Design and Structure
(1) Main Body Front
Backside Cap (Locker)

Back Side

(2) Spare Parts

No.

Name

1

Body

2

Pin

Function Collects activity data through the three-axis acceleration sensor. Sends the collected data
to the server through wireless LoRa network.
Collects temperature data through the embedded temperature sensor.

3

Cap (Locker)

Main Body Cap

Dimension and Volume
(1) Body

Net Weight(g)

23

Characteristic (Example) (1) Product’s composition – This device is made for measuring cow’s body temperature and activity, composed of penetrating pin, main body and cap. (2) How it works – The device is powered by an inner battery. Every 10minute, it collects data from the temperature sensor and activity sensor located inside the penetrating pin and stores them inside the memory chip. Once every hour, the collected data is sent to the server using the wireless Bluetooth network. The transferred data is analyzed through server’s algorithm and their results are serviced to the farm owner’s smartphone.

(3) Characteristic

Parameter

Performance

Rated voltage

DC 3V 540mA (CR2450 Coin Battery Cell)

Current

Active

10mA(When sent via wireless BLE)

Consumption

Sleep

3uA

Measurement range

Temperature

Accuracy

Sensor

Resolution

-40 ~ 125 ± 0.1 @(20 ~ 60 )
0.01

Activity Sensor

Measurement range

± 2g, ± 4g, ± 8g, ± 16g

Operating temperature range

-10 ~ 40

Protection type and protection Internal powered supply device, B-

capacity against electric shock

type mounting portion

Electrostatic Discharge

6KVContact, 8KV aerial discharge
–

Note

– 2) Raw material or ingredient and quantity

– Raw material or ingredient and quantity

Serial Spare Parts No. Name

Spare Parts Part No. / Raw Material
No.

Dimension

1

Body

PC-1100

Size(mm) : 33x44x15 Net Weight(g) : 23g Rating : 3VDC

2

Cap

PC-1100

Size(mm): 27×18(H) Net Weight(g) : 3g

3 Firmware

SN-003

Android Ver. 4.0 and over IOS ver. 7.0 and over

Q’ty Memo

1

1

–

App. 1 operation
Ver.

3) Manufacturing Method Depended upon the manufacturer’s manufacturing method

4) Performance and Purpose of use

Performance

– Collects data of body temperature and number of activities from

cow’s ear

Category

Description

Range

Note

Measures body temperature

Temperature Measurement
Range

-40 ~ 125

Accuracy ± 0.1 @(20 ~ 60 )

Resolution

0.01

Measures

g : Gravitational

amount of activity

Measuring Range

± 2g

acceleration unit [9.8m/sec2]

Purpose of use – Device designed to detect and alarm the estrus and signs of
livestock activity with the body temperature and amount of activity data collected from the ear. – Supporting APP(application) and related software for detecting estrus and managing disease.

5) How to operate / How to use

Warnings before use 1) Before use, sanitize the penetrating area and device pin.

2) Power on the inner battery by removing the magnet attached in front of the main body of the device.
3) Run a second set of sanitizations on the penetrating area after embedding the device. Attach the ear-tag 1) Prepare the applicator, main body and cap as shown in the
picture below.

2) Place the main body (pushed far in as possible) on the bottom

of the applicator with the penetrating pin facing upwards. Place

the cap on top of the applicator as shown in the picture below.

3) Before use, check if the penetrating pin is centered with the hole of the cap by slightly clenching on the applicator.

4) Place the screw on the embedding area, clench the applicator as fast as possible to apply the device.
How to install App (application) 1) Type in `FarmPro’ in the Play
Store or Apple Store and click button to install.
App UI and How to use 1) Run the `FarmPro-Heat’ on your
smartphone. When the log-in screen appears, input the ID and password given, change the password after. After the log-in, follow the below direction. 2) Main screen

Above main screen will appear after your first log in. On it, displays a list of four alarms showing: signs of estrus, signs of delivery, body temperature change, and caution.
Icons shown in the upper left-hand corner. 1. Home icon: Displays the main screen. 2. Bell icon: Displays a screen where you can check the list of notifications. 3. Tag icon: Displays a screen where you can check all objects.
3) Notifications list screen
This screen shows you the list of notifications you have received. You can check the Cattle ID, the time of the notification received, and the status of your cattle.

Click the “Today” button to see the notifications received today. Click the “Search” button to search for the cattle’s ID, the time of the notifications received, and the status of your cattle. Please include space bars, hyphen `­ `, colon `: `depending on your object of search.
3-1) To recheck the notifications list
Select the notification you want to see again and proceed to the next page. You can review the previous activity and its occurred date. You can also check the analysis table by scrolling down the graph.

4) List of Cattle
This screen allows you to check the history number, device number, farm management number, and device communication status. This screen also shows the total number of cattle that are registered/using the device. – If the cattle’s device has a poor network, the screen will show ‘communication bad’ in red text. – You can also use the search engine on the screen that shows the list of cattle. – You can search history number, device number, and farm management number (please be noted of using the space bars).
5) Cattle’s detail screen You can move to the detail information page of your selected cattle by clicking their cattle ID from the Cattle’s detail screen. On this screen, you can check graphs, analysis tables, and detailed information.

5-1) Select date
You can choose the date of your selection. Left angle bracket: You can move to a day before information from the current viewing date. Right angle bracket: You can move to a next day information from the current viewing date. 5-2) View graphs
Click on the graph you want to view.

All the graphs have the full screen function. If you touch the side of the graph and scroll down, you can check the graph, analysis table, and detailed information.
5-3) Analysis table Click on the analysis table you want to view 6) Detailed Information
You may view the detailed information of your cattle.
Caution – This product is used as an assistant device for detecting estrus.
If you receive a message that requires a checkup on the signs of estrus and disease, please contact your veterinarian for accurate diagnosis and follow according to their instruction. – Other cautionary procedures If there is a change of livestock, the farm owner must record this change of information on the web to receive accurate information.

6) Device storage precaution and validity
Store – Temperature : -20 ~ 55 – Humidity : 20 ~ 90% – Atmospheric Pressure : 700 ~ 1060hPa
Validity – None required
7) Test Specification Electrical, Mechanical and Electromagnetic Safety – Test on electrical, mechanical safety shall be conducted in accordance with the standards for medical devices for animals: Shall follow the common standards for electrical and mechanical safety for medical devices for animals. – Test on electromagnetic safety shall be conducted in accordance with the standards for medical devices for animals: Common standards for electromagnetic safety for medical devices for animals. Biological safety – Standards for Animal Medical Devices: shall follow the common standards for biological safety of animal medical devices.

Performance

Testing No.
Items

Testing Standards

Testing Method

Coupling of the

front and back Checks the smoothness of the front and back

1

body of the

coupling of the device.

device

Visual checkup

Checks the temperature

Testing the accuracy of the temperature

Temperature

of the thermometer

2

sensor microchip located inside the

Sensor

compared to the

penetrating pin.

commercial temperature.

Bluetooth 3 Transmission
Output

Must be within 0 ~ 8dBm

Compare the RSSI values sent to the server.

4 Battery Voltage

Nominal Voltage must be 3.0V

Measure with the voltmeter.

8) Matters to be stated Information Details

Part Name (Product Name)

Attachable Biometric Detecting Device[2](FarmkingEarTag)

Manufacturer and Address

Farmpro Corporation 824, 28 Digital-ro 30-gil. Guro-gu, Seoul, Republic of Korea TEL. 02-838-1108 FAX. 02-838-1109

Manufacturing License Number
Manufacturing Product Approval Number Serial No. and Production Date
Expiration Date

286 286-001 Shall be stated after production Not applicable

Packing Unit Performance and Instruction Manual Precaution for use

Followed by the manufacturer’s packing unit Measure the activity and temperature of the
individual cattle with the attached device Refer to the instruction manual

This product is an animal medical device.

For a Class B digital device or peripheral, the instructions furnished the user shall include the following or similar statement, placed in a prominent location in the text of the manual: NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: – Reorient or relocate the receiving antenna. – Increase the separation between the equipment and receiver. – Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. – Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
FCC CAUTION: Any changes or modifications in construction of this device which are not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
FCC NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment.
