ACC-LDR04-003 3 Step Trampoline Ladder

Product Information: 3 Step Trampoline Ladder

The 3 Step Trampoline Ladder is designed to provide easy access
to the trampoline for users. The ladder has three steps and two
handlebars for support, making it easier to climb up and down the
trampoline. The ladder is made of durable materials that can
withstand a maximum user weight of 330Lbs. The ladder comes with
elastic ropes that are used to attach the ladder to the trampoline
frame, ensuring stability and safety during use. The ladder is not
suitable for children under the age of 6 and should be removed when
the trampoline is not in use.

Product Usage Instructions

Ensure that the trampoline ladder is only used by individuals
aged 6 years and above.
Attach the ladder to the trampoline frame using the elastic
ropes provided. To do this:
- Insert the elastic rope (Part J) through the opening of the top
  part of the handlebar (Part B) hook.
- Loop the elastic rope around the frame of the trampoline.
- Wrap the end of the elastic rope around the ball.
Ensure that the SkyBound logo on the ladder is facing front
while the handlebars are facing back.
Climb up and down the ladder carefully, using the handlebars
for support.
Do not use the ladder if it appears damaged or unstable.
Remove the ladder from the trampoline when it is not in
use.

If you have any questions or concerns regarding the product,
please contact customer service at 888-891-4689 Monday through
Friday 8:00 am to 5:00 pm PST or visit www.SkyBoundUSA.com
[email protected]

View Fullscreen

3 step trampoline ladder

USER MANUAL
ASSEMBLY, INSTALLATION, AND USER INSTRUCTIONS

WARNING
1.Do not use trampoline ladder if children are under 6 years of age. 2.Remove trampoline ladder when trampoline is not in use 3.Max user weight:330Lbs.

For customer service, please contact: 888-891-4689 Monday through Friday 8:00 am to 5:00 pm PST or visit www.SkyBoundUSA.com [email protected]

ASSEMBLY PARTS
KEEP THIS MANUAL FOR FUTURE REFERENCE

A LADDER STEPX3

B LADDER HANDLE BARX2

C LADDER BASEX2 UPPER C D LADDER BASEX2 LOWER D

E
M6NUT 2PCS

F M6X40 6PCS

G M6X30 4PCS

M6NUT M6NUT

6PCS 4PCS

J ELASTIC ROPE 2PCS

K ALLEN KEY 1PC

F X1

G X1

EXTRA PARTS

I X1

3-STEP LADDER ASSEMBLY

DIAGRAM 1
Reference Diagram 1 to proceed with the installation: 1. Install the Ladder Step Part (A) to the corresponding position of the Handlebar Part (B) and connect with bolt Part (F) and hexagon nut Part (H) and tighten with Allen Key Part (K). 2.Insert the Handlebar Part (B) into the Upper Ladder Base Part (C) on both sides and connect with Bolt Part (G) and Cap Nut Part (I) (aligned with the hole position) and tighten with Allen Key (K). 3.Install the Ladder Step Part (A) to the corresponding position of the Upper Base Part (C) and connect with bolt Part (F) and hexagon nut Part (H) and tighten with Allen Key Part (K). 4.Insert the Upper Ladder Base Part (C) into the Lower Ladder Base (D) on both sides and connect with Bolt Part (G) and Cap Nut Part (I) (aligned with the hole position) and tighten with Allen Key (K). 5.Install the Ladder Step Part (A) to the corresponding position of the Lower Base Part (D) and connect with bolt Part (F) and hexagon nut Part (H) and tighten with Allen Key Part (K). 6.Install both Nuts Part (E) into the Lower Ladder Base Part (D) and tighten.
DIAGRAM 2

J K

Reference Diagram 2 to proceed with the installation: 1.Insert Elastic Rope Part (J) through the opening of the top Part (B) (On the Hook of the ladder handlebar). 2.Loop the elastic rope around the frame of the trampoline. 3.End of the elastic rope must be wrapped around the ball.
Make sure that the SkyBound logo is facing front while the handle bars are facing back
