ON WALL 300
User Manual
 |  |
 |  |
 | |
Specifications
| ON WALL 301 | ON WALL 302 | |
| Type | Enceinte 2 voies | Enceinte 2 voies et demie |
| Haut-parleurs | 2 x Medium grave Flax 100 mm 1 x Tweeter TNF 25 mm | 4 x Medium grave Flax 100 mm 1 x Tweeter TNF 25 mm |
| Sensibilité (2,83V/1m) | 87 dB | 91 dB |
| Bande Passante (±3 dB) | 53 Hz – 28 kHz | 50 Hz – 28 kHz |
| Coupure basse (-6 dB) | 44 Hz | 40 Hz |
| Impédance nominale | 8 Ω | 8 Ω |
| Impédance minimale | 5,5 Ω | 5 Ω |
| Puissance ampli recommandée | 25 – 130 W | 40 – 180 W |
| Fréquence de filtrage | 2 500 Hz | 1 100 Hz – 2 500 Hz |
| Dimensions enceinte (H x L x P) | 80 x 15,5 x 9 cm | 125 x 15,5 x 9 cm |
| Poids net (avec porte tissu) | 5,9 kg | 9,4 kg |
| Dimensions carton (H x L x P) | 91 x 30 x 23 cm | 138 x 30 x 21 cm |
| Poids net (avec carton) | 7,7 kg | 12 kg |
| ON WALL 301 | ON WALL 302 | |
| Type | 2-way loudspeaker | 2.5-way loudspeaker |
| Drivers | 2×4″ (100mm) Flax MidBass 1×1″ (25mm) Tweeter TNF | 4×4″ (100mm) Flax MidBass 1×1″ (25mm) Tweeter TNF |
| Sensitivity (2,83V/1m) | 87dB | 91dB |
| Frequency response (±3dB) | 53Hz – 28kHz | 50Hz – 28kHz |
| Low-frequency point (-6dB) | 44Hz | 40Hz |
| Nominal impedance | 8Ω | 8Ω |
| Minimum impedance | 5.5Ω | 5Ω |
| Recommended amplifier power | 25 – 130W | 40 – 180W |
| Crossover frequency | 2,500Hz | 1,100Hz – 2,500Hz |
| Dimensions (HxWxD) | 31 1/2 x6 1/8 x3 9/16 ” (80×15.5x9cm) | 49 3/16x 6 1/8 x3 9/16 ” (125×15.5x9cm) |
| Net weight (unit with grille) | 13lbs (5.9kg) | 20.72lbs (9.4kg) |
| Packaging dimensions (HxWxD) | 35 13/16 x11 13/16 x9 1/16 ” (91x30x23cm) | 54 5/16x 11 13/16 x8 1/4 ” (138x30x21cm) |
| Net weight (with packaging) | 16.97lbs (7.7kg) | 26.45lbs (12kg) |
Correct elimination of this product.
This marking indicates that within the EU this product should not be disposed of with other household wastes. To prevent any risk to the environment or human health, please recycle them responsibly to encourage the reuse of material resources. To return your used device, please use the return and collection systems available, or contact the retailer where you purchased the product. They can recycle this product safely.
Focal-JMlab ® – BP 374 – 108, rue de l’Avenir – 42353 La Talaudière cedex – France – www.focal.com
Tel. (+33) 04 77 43 57 00 – Fax (+33) 04 77 43 57 04 – SCBC – 10/06/2020 – SCCG – 31/05/2021 – v3 – CODO1648
