H44HAW 18Gbps 4×4 Seamless UHD Matrix
Product Information:
The 18Gbps 4×4 Seamless UHD Matrix, iMatrix H44HAW, is a
high-performance device that allows you to connect 4 HDMI sources
to 4 HDMI displays. It supports video resolutions up to 4K60 4:4:4
and is HDMI 2.0 and HDCP 2.2 compliant. The product features IR
matrix routing, audio matrix support, CEC management, and strong
video wall processing. It also supports seamless switching and has
a video wall function. With its EDID management capability and
various control options like front panel, RS232, and TCP/IP, it
provides convenient control and customization options.
Product Usage Instructions:
- Before connecting, operating, or adjusting the product, please
read the instructions carefully and keep the manual for future
reference. - For optimum performance and safety, it is recommended to use a
surge protection device to protect the sensitive electrical
components from electrical spikes, surges, electric shock,
lightning strikes, etc. - Package Contents: [List of package contents not provided in the
text] - To connect your HDMI sources and displays, follow these steps:
- Ensure that the product is powered off and all devices are
properly connected. - Connect the HDMI sources to the HDMI input ports on the
product. - Connect the HDMI displays to the HDMI output ports on the
product. - Power on the product and the connected devices.
- Ensure that the product is powered off and all devices are
- To control and configure the product:
- Use the front panel controls to select the desired output and
input sources. - Use the LCD panel to view the current video selections and
power status. - Utilize the various control options like RS232, TCP/IP, or the
front panel to manage the product settings. - Refer to the user manual for detailed instructions on using the
control options.
- Use the front panel controls to select the desired output and
- For specific video wall configurations, refer to the user
manual section “Video Wall Context Menu” and “Layout
Save/Load”. - The product supports CEC management. Please refer to the user
manual section “CEC Control Page” for instructions on utilizing
this feature. - Control via Web: The product can be controlled and configured
via a web interface. Please refer to the user manual section
“Control via Web” for instructions on accessing and using the web
interface.
For any further assistance or troubleshooting, please refer to
the complete user manual available at www.infobitav.com.
18Gbps 4×4 Seamless UHD Matrix
iMatrix H44HAW
VER 2.1 www.infobitav.com
Thank you for purchasing this product
For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference.
Surge protection device recommended
This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lighting strikes, etc. Use of surge protection systems is highly recommended in order to protect and extend the life of your equipment.
Table of Contents
1. Introduction……………………………………………………………………………………………………… 1 2. Features…………………………………………………………………………………………………………… 1 3. Package Contents………………………………………………………………………………………….. 1 4. Specifications…………………………………………………………………………………………………. 2 5. Operation Controls and Functions…………………………………………………………………… 3 6. RS232/LAN Control Connection……………………………………………………………………….. 6
6.1 RS232 Connector Connection…………………………………………………………………….. 6 6.2 Network Control Connection………………………………………………………………………..6 7. PC Tool User Guide…………………………………………………………………………………………. 6 7.1 Account’s Authentication…………………………………………………………………………..6 7.2 Connect with PC Tool…………………………………………………………………………………. 6 7.3 Matrix Switch Page…………………………………………………………………………………….7 7.4 Advanced Switch Page……………………………………………………………………………… 8 7.5 Signal Setting Page…………………………………………………………………………………… 9 7.6 FineTune Page…………………………………………………………………………………………… 9 7.7 Video Wall Page……………………………………………………………………………………….. 9
7.7.1 Video Wall Context Menu…………………………………………………………………. 11 7.7.2 Layout Save/Load……………………………………………………………………………… 12 7.8 CEC Control Page……………………………………………………………………………………… 13 8. Control via Web…………………………………………………………………………………………….. 13
1. Introduction
The 18Gbps 4×4 seamless UHD Matrix can connect 4 HDMI sources to 4 HDMI displays. Supported video resolution is up to 4K60 4:4:4. The product supports IR matrix and Audio matrix. IR matrix routing follows the video routing. Audio extract and insert are supported. The product supports CEC management and strong video wall processing.
2. Features
HDMI 2.0 and HDCP 2.2 compliant Support 18 Gbps video bandwidth Support video resolution up to 4K60 4:4:4 Color space: RGB, YCbCr 4:4:4, YCbCr 4:2:2 Support seamless switching, video wall function Support CEC management Support audio matrix and IR matrix function Support external L/R audio insert on HDMI stream Support EDID management Support front panel, RS232, TCP/IP (LAN 10M/100M) control
3. Package Contents
1 x 4×4 seamless UHD Matrix 1 x AC Power Cord 1 x Matrix IR Remote 4 x IR Receiver cable (1.5 meters) 4 x IR Blaster cable (1.5 meters) 1 x 3-pin Phoenix Connector 1× CAT6 cable 1× USB to RS232 Cable 1× User Manual
– 1 / 14 –
4. Specifications
Technical HDMI Compliance HDCP Compliance Video Bandwidth Video Resolution Color Space HDMI Amplitude
HDMI 2.0 HDCP 2.2 18Gbps Up to 4K60 4:4:4 RGB, YCbCr 4:4:4/4:2:2 T.M.D.S +/- 0.4Vpp
Differential Impedance ESD Protection
100±15ohm Human-body Model: ±8kV (Air-gap discharge) , ±4kV (Contact discharge)
RS232/Ethernet Control Baud rate9600, data bit8
Baud rate and Protocol Stop bit1, no parity checking
Ethernet
IE10.0+,HTML5
Mechanical
Housing
Metal Enclosure
Color Dimensions
Black 430mm (W)×220mm (D)×44mm (H)
Weight Power Supply
5Kg AC 110 – 240V
Power Consumption 60W (Max)
Operating Temperature 0°C ~ 40°C / 32°F ~ 104°F
Storage Temperature -20°C ~ 70°C / -4°F ~ 158°F
Relative Humidity
10%~50% RH (non-condensing)
– 2 / 14 –
5. Operation Controls and Functions
Front Panel
Item LCD Panel COM LOCK OUTPUT INPUT ALL RES EDID NEXT SAVE RECALL CLEAR ENTER
Description Displays the current video selections Power LED (also indicates control commands) Front panel lock/unlock Output selection buttons 1~4 Input selection buttons 1~4 Set all outputs to the next input selection Set the output scaler resolution Set the EDID options for the next input selection Select the next available option Save the current matrix setting as a preset Set the matrix setting from a saved preset Cancel the current command function Set the displayed option
· Press buttons ALL + INPUT m + TAKE by sequence, to switch input m to all the outputs. · Press buttons SAVE + OUTPUT n to save current routing/video wall scene as scene n. Up
to 8 scenes can be saved. · Press buttons RECALL + OUTPUT n to recall routing scene n as the current routing. · Press buttons RES + OUTPUT n + NEXT + TAKE, to change the output resolution of
OUTPUT n. Resolution options:
Number 1 2 3 4 5 6 7 8
Output Resolution Setting 3840x2160p 60Hz 3840x2160p 50Hz 3840x2160p 30Hz 3840x2160p 25Hz 1920×1200 60Hz 1920x1080p 60Hz 1920x1080p 50Hz 1600×1200 60Hz
Number 9 10 11 12 13 14 15 16
Output Resolution Setting 1440×1050 60Hz 1366×768 60Hz 1360×768 60Hz 1280×1024 60Hz 1280×768 60Hz 1280x720p 60Hz 1280x720p 50Hz 1024×768 60Hz
– 3 / 14 –
· Press buttons EDID + INPUT m + NEXT + TAKE, change the EDID mode of port INPUT m EDID options:
Number 1 2 3 4
Output Resolution Setting Manual 3840×2160 60Hz 3840×2160 30Hz 1920×1200 60z
Manual EDID is loaded by PC Tool
Number 5 6 7 8
Output Resolution Setting 1920×1080 60Hz 1280×1024 60Hz 1280x720p 60H 1024×768 60Hz
· Front Lock button The front panel control buttons can be locked to prevent accidental use or operation by unauthorized persons. Press and hold the LOCK button for two seconds to lock or unlock the front panel. When the panel is locked, all buttons (except the LOCK button) will not function until the front panel is unlocked. The LOCKED/UNLOCKED state is shown on the LCD panel and by the LED above the LOCK button, which is lit when the front panel is fully LOCKED. When the unit is UNLOCKED, press and hold the LOCK button for six seconds – The LCD panel will show the following (any exiting numbers indicates that those buttons are already locked): Output: ——-Input: ——-Pressing any of the numbered Output or Input buttons will toggle the lock status of that button. The button will become locked when the respective button number is shown on the LCD panel. When all selection are done, press the ENTER button to set the new LOCK/UNLOCK states of those buttons. Whenever a locked Output or Input button is activated, the LCD panel will show that the button is locked. In this mode, the LOCK LED is not lit. To unlock those buttons, repeat the above steps to remove the button numbers from the LCD panel before pressing ENTER to accept the changes.
– 4 / 14 –
Rear Panel
· LAN(10M/100M), RS232 are for PC control. · Analog Audio IN/OUT ports bind to corresponding HDMI ports.
For example: If HDMI 1 audio source is selected with External LR, then analog AUDIO IN LR1 (with phoenix connector) will be selected to replace the embedded audio of the HDMI input 1 data stream. If HDMI 1 audio source is selected with AUTO by PC TOOL or command, then the original embedded audio of input HDMI 1 will be used as its audio data stream. If the input is DVI signal, no matter how it is set up, system will get external analog audio input. Analog AUDIO OUT n will always output the same audio content with HDMI OUTPUT n. · IR IN and IR OUT IR IN/OUT routing follows the video matrix routing, no need to separately control IR matrix.
IR extender connectors (not as accessories)
· Audio Input 4 3-pin Phoenix connectors to input external analog LR audio, user can select this audio to replace the corresponding embedded HDMI audio.
· Audio Output 4 5-pin Phoenix connectors to output balanced LR audio, and 4 mini Toslink jackets to output analog LR audio and digital Spdif audio. The 4 sets of Audio output (LR and Toslink) channels can be independent of video and switched by PC Tool or commands.
– 5 / 14 –
6. RS232/LAN Control Connection
6.1 RS232 Control Connection
The product supports RS232 control. Connect the RS232 port of the product to a PC via a serial cable, as shown in the following figure:
TX Ground
RX
3-pin Phoenix Connector
RS-232
RS-232 to USB cable PC
6.2 Network Control Connection The product also supports Network control. Connect the LAN port of the product to a PC via an UTP cable
as shown in the following figure:
NoteFactory default network setting
LAN
LAN
PC
7. PC Tool User Guide
7.1 Account’s Authentication Before running the PC tool, the password is needed for authentication. Default password of Administrator access to all features111111 Default password of User access to all features, except OSD function
000000 7.2 Connect with PC Tool 1. The default PC tool’s UI style is as below.
– 6 / 14 –
2. You can select UART (with RS-232 cable) or Network to connect, baud rate is 9600 bps. 3. Default IP address: 192.168.0.247. 7.3 Matrix Switch Page
1. There is a shortcut button to switch one input port to all output ports, that is Allset, For example, switch input 1 to all outputs, user can select
2. Recall modeRecall a input/output routing scene which already be saved before. The device supports maximum 8 scenes.
3. Save modeSave the current input/output routing in one index. Maximum 8 modes supported. Note: Save/Recall button here works the same with front panel save/recall control and also the same with Save/Load function on video wall page. – 7 / 14 –
4. System reset: The PC tool supports reset system to recover to factory configuration. 5. Audio Switch mode: Follow Video mode or Manual mode
When selecting Manual mode, user can separately switch L/R(Phoenix interface) and Toslink output. User also can select to use HDMI embedded or corresponding external LR audio. 6. EDID Control: Click the “EDID” button on Matrix Switch page, there will be a pop-up EDID control window. User can do following operations: a) Read EDID of one output port b) Open one existing EDID file c) Write EDID to one input port
7.4 Advanced Switch Page
The Advanced Switch page will repeatedly send a batch of matrix selection commands at the interval specified in the value box after Send cmd periodly at text. 1. Select one or more outputs. 2. Select one input. 3. Use the arrow button “–>” to assign that input to the selected output or outputs. 4. After completing all required selections, click the “Start” button to run the commands. The available options are: All outputs send combined Combine all outputs that have the same input number as a single command. Wait others finished the start next loop Wait for all commands in the previous pass to complete before sending the next batch of commands. Send cmd only one loop Only send a single batch of commands. Select all outputs Select all outputs when the option is checked. Start Begin the command cycles. Stop Stop the command cycles.
– 8 / 14 –
7.5 Signal Setting Page
1. Audio Select There are two options for input Audio Select. a) Auto: If the input source is HDMI signal, system will get the embedded audio; if the input source is DVI signal, the system will get the corresponding analog audio. b) External: System will get the corresponding analog audio.
2. Output Type There are four options for input Output Type: UHD-HDMI (HDCP OFF), UHD-DVI, UHD-HDCP-1.4, UHD-HDCP-2.2.
3. Output Resolution: The same as the description on Front Panel page. 7.6 FineTune Page You can read and set the Brightness/Contrast/Saturation/Sharpness of each output.
Note: Do not change the default settings without special conditions; If there is a problem after changing, click “Reset” to return to the factory settings.
7.7 Video Wall Page This page is used to configure a group of outputs to function as a video wall.
– 9 / 14 –
1. Use the Video Wall Setting controls to change how the displays are arranged on the Video Wall page: a. Adjust the Rows and Columns sliders to change the displayed screen arrangement to permit proper Drag-and-Select of the desired screens for the video wall. b. Change the Available slider to set how many outputs will be used for the Video Wall. c. Click the “Set” button to change the Screen configuration.
2. Use the left mouse button to drag-select the screens that will be set for video wall mode. The selected screens will be shown as bright blue.
3. Use the right mouse button to open a menu. 4. Select “Screen Stitching” from the menu to program the video wall mode. The selected
screens will now be shown as bright green. 5. To change the displayed image: right-click to open the pop-up menu and select the desired
input from the “Input Select” menu option. 6. Repeating steps 2 ~ 5 above with a different set of outputs allows the creation of a second
video wall. However, changing the Rows, Columns and Available sliders will automatically delete the current video wall set up when the “Set” button is clicked. The following example shows a more unusual video wall set-up of two video walls with two 2×1 configurations:
– 10 / 14 –
7.7.1 Video Wall Context Menu Right clicking on any of the screen icons will display the following context menu:
Screen Stitching This option connects the selected screens into a video wall configuration. Cancel Stitching Return the Video Wall configuration to normal outputs.
Remove the single screen x from the video wall to allow the displaying another full frame image within the video wall configuration, as shown in this example:
Screen x Cancel Stitching
Input Select Output Select Output Type
Output Format
Mirror Test Pattern
Use the sub-menu to select the input to display on the video wall or the secondary input image shown in the above example.
This option is only available for any screen that is not assigned to a video wall mode.
This option is only available for any screen that is not assigned to a video wall mode.
This option is only available for any screen that is not assigned to a video wall mode. It allows setting of the output resolution for the selected screen output.
Two sub options : OFF ( default ), ON ( H+V Mirror) When select “ON”, you can make 180º rotation with the selected screen. When Test Pattern is enabled, the output will display Color Bar pattern
– 11 / 14 –
Bezel Setting The Bezel Setting section allows the entry of values to compensate for the display bezel thickness. These values may be entered either as pixels (Type A) or as milli metre (Type B). Type A Bezel Settings The image size will be adjusted to allow for the number of pixels entered in each of the entry boxes. Click the “Set” button to view the effect of the new values. Type B Bezel Settings The image size will be adjusted to allow for the Inner and Outer display dimensions as entered in each of the entry boxes. Click the “Set” button to view the effect of the new values. Bezel Compensation
The following images demonstrate the effect of not having bezel compensation and what a correctly configured bezel compensation settings should produce:
No Bezel Compensation
Correct Bezel Compensation
7.7.2 Layout Save/Load The Save Scene/Layout and Load Scene/Layout buttons allow a video wall configuration to be saved or recalled at any time. Up to 10 configurations, each with their own name can be saved or recalled. When saving, each Scene can optionally be given a name to identify that video wall scene setup.
– 12 / 14 –
7.8 CEC Control Page
If Auto Power On is enabled, every time when the product is turned on, it will turn on all the sources and displayers which are connected to it. The product supports CEC function, including Power on/off, Volume+/-, Mute/Unmute.
8. Control via Web
The built-in Web GUI interface provides only basic control of the matrix switcher and access to the network settings. The following will be displayed when the web interface is access each time:
The default User Name is: admin The default Password is: admin After entering the User Name and Password, an interface similar to the following will be displayed:
– 13 / 14 –
IP Config
The IP Config tab is used to change the IP settings of the matrix switcher. Enter any necessary changes and click “Save” to program the switcher to the new settings, or click “Cancel” to reject the changes.
– 14 / 14 –
