Driven Drwc7cm 7 Inch Hd Digital Color Wireless Monitor With Wireless Camera System Owner's Manual

DRWC7CM 7 Inch HD Digital Color Wireless Monitor with Wireless Camera System

Product Information

The product is a monitor and camera system designed for use in
vehicles. The monitor is equipped with a suction cup base for easy
installation on the dashboard or window screen. It comes with a
cigarette lighter plug that can be inserted into the vehicle’s
cigarette lighter socket. The camera is also included and needs to
be wired to the monitor for proper usage. The system can be paired
for seamless operation.

Product Usage Instructions

1. Familiarize yourself with the instructions before starting the
   installation.
2. Monitor Installation:
   1. Find a suitable location on the dashboard or window screen for
      the monitor, ensuring it is easily viewable and does not disturb
      your vision of the road while driving.
   2. Clean the chosen location using alcohol wipes to ensure it is
      dust and grease-free.
   3. Mount the monitor base using the supplied suction cup.
3. The monitor is equipped with a cigarette lighter plug that can
   be easily inserted into the vehicle’s cigarette lighter
   socket.
4. Standard Operation:
   1. After successful installation and pairing (if required), turn
      the ignition key on, ensuring the RED power button on the monitor
      cigarette plug is switched on.
   2. View the camera image on the monitor. If no image is visible,
      check all wiring connections are securely fastened.
   3. If the image displays properly, follow the instructions below
      to adjust your screen settings.
5. Camera Installation:
   1. Wire the camera to the monitor.
6. Camera Wiring Connection:
   1. Follow the wiring instructions to connect the camera to the
      monitor.
7. Monitor and Camera Pairing:
   1. Typically, both units will already be paired before shipping
      from the factory. If not, power on the monitor then hold the pair
      button for about 2 to 3 seconds to enter pairing mode.
   2. While in pairing mode, power on the camera.

2

Please familiarize yourself with these instructions before starting your installation.
MONITOR INSTALLATION
1) Find a suitable location on your dashboard or window screen for your monitor. Please ensure it is in a location where it is easily viewable and does not disturb your vision of the road while driving. 2) Clean the location that you have decided to place the monitor to ensure that it is dust and grease free ( it is recommended to use alcohol wipes to do this) 3) Mount the monitor base using the supplied suction cup.
The Monitor is equipped with a cigarette lighter plug that can be easily inserted into the cigarette lighter socket in the vehicle.
STANDARD OPERATION
After the monitor and camera have been successfully installed and paired (if required), turn the ignition key on ensuring the RED power button on the monitor cigarette plug is switched on, View the image from the camera on the monitor. If no image is visible, check all wiring connections are securely fastened. If the image displays properly, please follow the instructions below to adjust your screen settings:
3

CAMERA INSTALLATION
Proper installation of the Camera is critical to the overall view you will be able to see from your in-cab DRIVEN DRWC7CM wireless monitor. In most cases the rear-view camera mount on an RVs is mounted just below the rear top clearance lights. If your clearance lights are too low, this shouldn’t be a problem, simply plan to for installation of the camera at the highest point of the rear outer panel of your RV. Most modern-day RVs are prewired with a 12v DC power supply cable that hidden behind a camera mount cover. If this is the case, simply remove the 4 mounting screws off the pre-mounted base, connect the simple 2 wire red and black cables to the new harness and replace the complete mount and base with the DRIVEN DRWC7CM camera by screwing it down securely with the previously removed screws. In the event that your RV or trailer does not come prewired with a 12v DC power supply at the desired location, you will have to carefully run a power supply cable to the location on your RV were you wish to mount your camera system. Plan your wire route for under the RV trailer. Be sure to avoid areas that could be affected by heat or abrasion. Make sure to properly fuse the power supply cable at its origin. Once the camera is powered up, follow the pairing instructions provided with the DRIVEN DRWC7CM wireless monitor. Align the camera and test the angle of the view. Make sure to adjust the angle several times to check your options. Once you have chosen the specific angle for the camera you are good to go. Camera Wiring Connection
CAMERA WIRING CONNECTION
4

FOR MONITOR AND CAMERA PAIRING:
Typically, both units will already be paird before shipping from the factory. If not, power on the monitor then hold the pair button for about 2 to 3 seconds to enter pairing mode. While in pairing mode, power on the camera.
