CMT580 PC Case
Product Information
The CMT580 is a mid-tower PC case that supports E-ATX, ATX,
Micro ATX, and Mini-ITX motherboards. It has an ultra-simplified
and beauty exterior design and comes in black color. The case is
made of 0.8mm SPCC material and weighs 7.9KG. The dimensions of the
case are 450x220x408mm.
The case is optimized for cooling with support for up to six
fans and 2 x 360mm radiators. It also has a lighting transmission
I/O port with a built-in USB 3.2 Gen 2 Type-C for faster data
transfer. The case has an easy cable management design with
built-in multiple holes for cables and exclusive space for hard
drives.
The CMT580 has a tools-free panel design that allows for easy
panel changes in just 5 seconds. The left and right side panels can
easily be exchanged at any time. It also has a maximum CPU cooler
height of 160mm and a VGA card length of 335mm. The case has seven
expansion slots and supports bottom and back fan & water cooler
support.
Product Usage Instructions
1. To install the motherboard, remove the left side panel by
removing the top screw and pulling the panel up.
2. Install the motherboard onto the standoffs inside the case,
aligning the I/O shield with the corresponding opening in the
case.
3. Connect the power supply to the motherboard and install any
additional components such as CPU, RAM, and graphics card.
4. Install the storage drives into the drive bays located at the
bottom of the case. The case supports both 3.5″ HDD and 2.5″ SSD
drives.
5. Install the pre-installed fans onto the case, with one fan
located at the bottom back and three fans located at the top. The
case also supports additional fans or a water cooler on the bottom
and back.
6. Connect the external I/O ports, including two USB 3.0 ports,
one USB Type-C port, and an HD Audio port.
7. Replace the side panel and secure it with the top screw.
8. Power on the system and enjoy your new PC build!
PC Case
CMT580
RGB
Addressable
Introduction
CMT580 is E-ATX mid tower with ultra simplified and beauty exterior design. It comes with pre-installed 120mm x 4 fans and lighting transmission I/O port which is built in USB 3.2 Gen 2 Type C. Also with easy cable management design could support both vertical and horizontal installation. With high flexibility to system upgrade, CMT580 is definitely an ideal choice for you.
Features
Optimized for Cooling
With support for 2 x 360mm radiator and up to six fans.
Tools free panel design
Easy changed panels in just 5 seconds
FREE
USB Type-C Design Type-C One USB Type-C and two USB3.0
High Speed
for faster data transfer
· Support E-ATX, ATX, Micro ATX, Mini-ITX motherboard · Support VGA Height 335mm · Pre-installed 120mm x 4 fans · Lighting speed Type-C Gen2 · Easy cable management design
© 2023 FSP Group. All Rights Reserved. All trademarks are registered to their respective owners.
PC Case
CMT580
Product Overview
Ultra simplified & beauty Beauty without reducing heat dissipation
220mm
450mm
Lighting transmission I/O port Built in USB 3.2 Gen 2 Type – C
390mm
Power Reset
USB 3.0
Type-C (USB 3.2 Gen2)
© 2023 FSP Group. All Rights Reserved. All trademarks are registered to their respective owners.
E-ATX
PC Case
CMT580
Product Overview
More space to upgrade at anytime Support E-ATX, ATX, Micro ATX, Mini-ITX motherboard
ITX M-ATX
ATX
CPU VGA
© 2023 FSP Group. All Rights Reserved. All trademarks are registered to their respective owners.
PC Case
CMT580
Product Overview
Easy cable management design Built-in multiple holes for cable
Exclusive space for hard drives
© 2023 FSP Group. All Rights Reserved. All trademarks are registered to their respective owners.
PC Case
CMT580
Product Overview
Tools free panel design Easy changed panels in just 5 seconds. Remove the top screw, pull up to disassemble panels
The left and right side panels can easily be exchanged at anytime.
© 2023 FSP Group. All Rights Reserved. All trademarks are registered to their respective owners.
PC Case
CMT580
Product Overview
Pre-installed 120mm x 4 cooling fans · Quieter but powerful · Support maxinum 360mm radiator
120mm fans x 1
360mm radiator 120mm fans
x 1
360mm radiator
140mm fans x 2
120mm fans x 1
120mm fans x 3
120mm fans x 1
140mm fans x 2
120mm fans x 3
© 2023 FSP Group. All Rights Reserved. All trademarks are registered to their respective owners.
PC Case
CMT580
Specifications
Model
Type
Color
Materials
Weights
Dimensions (D x W x H)
Motherboard Support
External I/O port
Maximum CPU Cooler Height
VGA Card Length
Expansion Slots
Dust Filters
Power Supply Type
Drive Bay
3.5″ HDD 2.5″ SSD
Preinstall Fan
Bottom Back
Fan&Water
Cooler Support
Bottom Back
Max Radiator
Top
Support
Bottom
CMT580B / CMT580W E-ATX Black
0.8mm SPCC 7.9KG
450x220x408mm E-ATX, ATX, Micro ATX, Mini-ITX USB3.0 x 2, Type-C , HD Audio (2 in 1)
160mm 335mm
7 Top/Side/Bottom
170mm ATX 2 2
120mm x 3 (3 in 1) 120mm x 1
120mm x 3 or 140mm x 2 120mm x 3 (Pre-installed) or 140mm x 2
120mm x 1 (Pre-installed) 280/360mm 280/360mm
