ATU-500 HF Antenna Tuning Unit

ATU-500 Assembly Instructions Run 1 – 2021

Manufactured by HobbyPCB, LLC, the ATU-500 HF Antenna Tuning
Unit is designed to be installed on the Hardrock-500 amplifier
support package. It covers 160, 80, 60, 40, 30, 20, 17, 15, 12, and
10 meter Amateur Radio Bands. The ATU-500 has a tuning range of 6:1
maximum and requires a DC power of 12V nominal and a maximum of 2A.
The size of the ATU-500 is 7 X 4.63 X 2 (178mm by 118mm by
51mm).

General Assembly Instructions

The ATU-500 PCB comes with most components pre-installed. The
builder needs to install six toroidal tuning inductors and
transformers for the directional coupler. After that, the ATU PCB
is installed in the Hardrock-500 amplifier using two coax jumpers
and a small ribbon cable.

ATU-500 Inventory

Toroids

In this section, we will install the pre-wound toroids onto the
ATU-500 PCB:

1. Insert the toroid into the PCB at the marked location, solder,
   and trim excess leads.
2. Insert the inductor into the PCB at the marked location,
   solder, and trim excess leads.
3. Insert the inductor into the PCB at the marked location,
   solder, and trim excess leads.
4. Insert the toroid into the PCB at the marked location, solder,
   and trim excess leads.
5. Insert the toroid into the PCB at the marked location, solder,
   and trim excess leads.
6. Insert the toroid into the PCB at the marked location, solder,
   and trim excess leads.

Integration

In this section, we will integrate the ATU-500 with the
Hardrock-500 amplifier.

1. Install the ATU-500 in a safe location and connect all
   necessary connections, including AC power, RF connections, and data
   interfaces.
2. Remove four #4-40 hex nuts from the Hardrock-500 amplifier,
   place the ATU-500 next to the control board with the IN and OUT
   terminal blocks toward the back of the amplifier, and connect the
   10-pin header.
3. Strip the dielectric from 0.5 (12 mm) of the center conductor
   for each end of the RG58/U coaxial cable (four places). Be careful
   not to melt the dielectric. Bend the shield wires and center
   conductors as shown.
4. Locate the ATU-IN (RF) and ATU-OUT (RF) terminal blocks on the
   rear panel PCB, remove and discard the short jumper wire between
   them, and tighten the terminals. Ensure that the center conductor
   is in the RF terminal and the shield is in the GND terminal.
   Connect the other end to the IN terminal block on the ATU-500
   board.
5. Locate the OUT terminal block on the ATU-500 board, tighten the
   terminals, ensure that the center conductor is in the RF terminal
   and the shield is in the GND terminal, and connect the other end to
   the OUT terminal block on the Hardrock-500 amplifier.

ATU-500 Assembly Instructions Run 1 – 2021
Jim Veatch WA2EUJ 12 January 2021

TABLE OF CONTENTS
2. GENERAL ASSEMBLY INSTRUCTIONS………………………………………………………………………………………………………… 1 3. ATU-500 INVENTORY …………………………………………………………………………………………………………………………….. 2 4. TOROIDS ……………………………………………………………………………………………………………………………………………… 3 5. INTEGRATION ………………………………………………………………………………………………………………………………………. 6 6. OPERATION………………………………………………………………………………………………………………………………………….10 APPENDIX A ­ SCHEMATICS …………………………………………………………………………………………………………………………..13

1. INTRODUCTION
This assembly manual covers the ATU-500 HF Antenna Tuning Unit manufactured by HobbyPCB, LLC
The ATU-500 is automatic antenna tuner capable of matching RF loads with VSWRs of 6:1 or less in the 3 ­ 30 MHz band at power levels up to 500W and 3:1 or less at 1.8 MHz
The ATU 500 is designed to be installed on the Hardrock-500 amplifier support package.

ITEM Manufacturer Model Number Tuning Bands DC Power Inductor Capacitor Tuning Network Tuning Range Size

SPECIFICATION HobbyPCB, LLC. ATU-500 160, 80, 60, 40, 30, 20, 17, 15, 12, 10 meter Amateur Radio Bands 12V DC Nominal, 2A Maximum 63 steps 50 nH to 3.2 uH 127 steps 22pF to 2800pF L network with capacitor in input or output 6:1 Maximum 7″ X 4.63″ X 2″ (178mm by 118mm by 51mm)

2. General Assembly Instructions
The ATU-500 PCB is supplied with the majority of the components already installed on the board. The builder needs to install the six toroidal tuning inductors and the transformers for the directional coupler. Then the ATU PCB is installed in the Hardrock-500 amplifier using two coax jumpers and a small ribbon cable.

3. ATU-500 INVENTORY
DESCRIPTION
M-F STAND-OFF #4-40 X 1-1/4″
T130-0 TOROID TAN
2 TURNS
T130-6 TOROID YELLOW 2 TURNS, 5 TURNS
T130-2 TOROID RED
7 TURNS, 11 TURNS 16 TURNS FT50-43 TOROID
BLACK 10 TURNS
#22 TEFLON WIRE (color may vary)
RG58/U COAX CABLE


RIBBON CABLE – 8CM (2″) 2X5 PIN 0.1″

QUANTITY
4
1 2
3
2 3″ 2′
1

4. Toroids
In this section we will install the pre-wound toroids onto the ATU-500 PCB:
Step 1: L1 ­ 2 turns of #18 enameled wire on a T130-0 (tan) toroid core. Insert to inductor
into the PCB at the marked location, solder and trim excess leads.
Step 2: L2 ­ 2 turns of #18 enameled wire on a T130-6 (yellow) toroid core. Insert to
inductor into the PCB at the marked location, solder and trim excess leads.
Step 3: L3 ­ 5 turns of #18 enameled wire on a T130-6 (yellow) toroid core. Insert to
inductor into the PCB at the marked location, solder and trim excess leads.
Step 4: L4 ­ 7 turns of #18 enameled wire on a T130-2 (red) toroid core. Insert to inductor
into the PCB at the marked location, solder and trim excess leads.
Step 5: L5 ­ 11 turns of #18 enameled wire on a T130-2 (red) toroid core. Insert to inductor
into the PCB at the marked location, solder and trim excess leads.
Step 6: L6 ­ 16 turns of #18 enameled wire on a T130-26 (red) toroid core. Insert to inductor
into the PCB at the marked location, solder and trim excess leads.
[3]

Step 7: T1,T2 ­ 10 turns of #26 enameled wire on a FT50-43 (gray) toroid core. Insert to
transformers into the PCB at the marked location, solder and trim excess leads. Be sure to insert the #26 wire in the small holes on either side of the transformer, the larger holes are for #22 wire in the next step. This drawing shows whereL1 ­ L6, T1 and T2 are located on the ATU-500 PCB:
[4]

Step 8: T1,T2 ­ 1 turn windings ­ Cut two equal length pieces from the #22 Teflon wire, the
actual length is about 1.5″ (4 cm). strip the ends of the wires so that ½” (13mm) of insulation remains. Tin the ends of the wires.
Step 9: T1,T2 ­ 1 turn windings ­ pass one end of each wire through the center of T1 and T2
and insert the end into the hole in the PCB. Solder the wires into the holes and trim any excess with diagonal cutters.
Step 10: T1,T2 ­ 1 turn windings ­ insert the free end of the wires into the holes on the
opposite side of T1 and T2 cores. Solder the wires into the holes and trim any excess with diagonal cutters.
[5]

5. Integration
In the section we will integrate the ATU-500 with the Hardrock-500 amplifier.
Step 1: Prepare the Hardrock-500 ­ Disconnect the Hardrock -500 from all external
connections including AC power, RF connections and data interfaces.
Step 2: Remove the top cover ­ Remove the 6 screws the hold the top cover and place them
in a safe location.
Step 3: ATU Standoffs ­ Remove the four #4-40 hex nuts that hold the LPF board in the
amplifier and place them in a safe location. Install four #4-40X1 ¼” M-F spacers in place of the hex nuts.
Step 4: ATU PCB ­ Place the ATU-500 PCB on the four #4-40 standoffs and secure with the
four #4-40 hex nuts removed in step 3. The IN and OUT terminal blocks are toward the back of the amp, the 10-pin header should be next to the control board.
[6]

Step 5: COAX Prep ­ Cut two 10″ (25.5 cm) pieces of RG58 coax and remove ¾” (19mm)
of the outer jacket. Be careful not to nick any of the shield wires. PRO TIP ­ Cut the supplied wire in half, prepare one end of each wire then cut the wire to length so you’ll have a little extra in case you don’t get it right the first time.
Step 6: COAX Prep ­ Carefully un-braid the shield wires and gather them on one side of the
cable. Strip the dielectric from 0.5″ (12 mm) of the center conductor for each end of the cables (four places).
Step 7: COAX Prep ­ Tin the exposed braid without getting too close to the jacket ot
dielectric to avoid melting either one. Bend the shield wires and the center conductors as shown.
[7]

Step 8: Remove Jumper ­ Loosen all four screw terminals in the ATU-IN and ATU-OUT
terminal blocks on the rear panel PCB. The remove and discard the short jumper wire going between ATU-IN (RF) and ATU-OUT(RF).
Step 9: ATU-IN jumper ­ Insert one of the coax jumpers into the ATU-IN terminal block
and tighten the terminals. Be certain that the center conductor is in the RF terminal and the shield is in the GND terminal. Connect the other end to the IN terminal block on the ATU-500 boards.
Step 10: ATU-OUT jumper ­ Insert the other coax jumper into the ATU-OUT terminal
block and tighten the terminals. Be certain that the center conductor is in the RF terminal and the shield is in the GND terminal. Connect the other end to the OUT terminal block on the ATU-500 board, again observing RF and GND connections.
The red line shows the ATU-IN; the green line shows ATU-OUT [8]

Route the coax runs from the rear panel board to the side of the AN-1819 amplifier deck, not directly over the top of the amplifier.
Step 11: Ribbon Cable ­ Connect one end of the short ribbon cable to the 10 pin connector
on the front panel board labeled ATU. Connect the other end to the CTRL-BRD connector on the ATU.
Step 12: Replace the top cover ­ Replace the top cover and secure with the six top cover
screws removed in step 2.
[9]

6. Operation
In the section covers operation of the ATU-500 with the Hardrock-500 amplifier. When you turn the Hardrock-500 on, if the ATU-500 is installed and connected correctly, the right hand LCD will contain controls for the ATU.
The two controls for the ATU are TUNE and ATU. The ATU control selects whether the ATU is bypassed (BYP) or actively applying a tuning solution (ON). Tuning solutions are stored in EEPROM for each band and each antenna so if the ATU had been tuned on the selected band/antenna combination the previous tuning solution will be applied. The ATU can be used with or without the 500W amplifier as can the antenna selection. You must apply RF to the input of the Hardrock-500 so the ATU can tune the antenna. If your radio does not have a TUNE mode you’ll need to select a mode that causes the radio to create a RF signal like AM, FM, CW, RTTY. Keying the radio in SSB does not produce enough RF for the ATU to complete a tuning cycle. The TUNE control is used to initiate an auto-tune cycle. The ATU will only tune when the TUNE button is pressed, it does not tune based on high SWR or any other external factors. If you want it to tune, press the TUNE button and apply RF energy. Pressing the TUNE button again, while the ATU is tuning immediately stops the tuning cycle.
[10]

Tuning the ATU ­ When you press the TUNE button if the ATU is on BYP (bypass) it will switch to `ON’. The status window will display `Tuning” and the ATU will wait for RF to be applied.

The tuning action is different depending on the state of the amp:

Hardrock-500 Operating Conditions MODE = `OFF’
MODE = `PTT’ Amp is not keyed
PTT = `ON’ Amp is keyed
PTT = `ON’ Amp has tripped the high SWR condition

ATU Action The ATU waits for RF and starts tuning when RF is present. If tuning is successful the tuning solution is applied and can be used with the amp on or off. The ATU waits for RF and starts tuning when RF is present, the amp is not brought on-line while the ATU is tuning. If tuning is successful the tuning solution is applied and next time the amp is keyed the amp is brought on-line with the ATU. The amp is taken off-line and the ATU tunes when RF is present. If tuning is successful the tuning solution is applied and next time the amp is keyed the amp is brought on-line with the ATU. The amp is taken off-line and the ATU tunes when RF is present. If tuning is successful the tuning solution is applied and next time the amp is keyed the amp is brought on-line with the ATU and the error condition will be cleared.

When Tuning is initiated and RF is applied, the amp first checks the current tune state of the amplifier. If the VSWR is better than 1.2:1 a tuning is not performed and the ATU status is `Tuned’. The ATU then checks the bypass path and if the SWR is better than 1.3:1 a tuning is not performed and the ATU status is `Tuned’. If the SWR is higher than 6:1 a tuning is not performed and the ATU status is `Hi SWR’, indicating that the current antenna cannot be used at this frequency without additional matching. If the load SWR is higher than 1.3:1 and lower than 6:1 the ATU starts a tuning cycle. If the RF power drops below 00.5W for more than a second, the ATU discontinues tuning and the status is `Lo Power’. If the ATU completed tuning and the final SWR is greater than 2:1 the ATU status is `Failed’ indicating that a suitable tuning solution could not be found. If the tuning cycle completes and the final SWR is less than 2:1 the tuning solution is applied and the ATU status is `Tuned’.
[12]

Appendix A ­ Schematics
[13] [14]
