INSTRUCTIONS
FOR USE
orginal revision1.0
ADR-215B
USB-A <> USB-B
ACTIVE USB 2.0
CONNECTING CABLE 15m
ADR-215B Active USB 2.0 Connecting Cable 15m
Turn on computer.
Connect the cable to your computer’s USB port.
An automatic installation will be performed.
No need to install any external drivers.
The USB connecting cable is ready.
CHARGING
- Power via computer’s USB port is sufficient for most connected USB devices.
- For connecting of an external hard drive, itis usually necessaryto use additional power supply.
- When connecting multiple active U bles behind each other,
- supply voltage is reduced. and it i better to use additional power supply of the last active cable ina row.
- The supplied power cord allows additional power from a tegular mobile hone Charger with min. 1A USB-A output.
PRODUCT SUPPORT LINK
http://axagon.eu/produkty/adr-215b#supportLinkGoal
Active USB 2.0 connecting cable
TECHNICAL SPECIFICATIONS
INPUT INTERFACE
USB 2.0- USB 1.1
USB-A (M) male connector
OUTPUT INTERFACE
USB 2.0+ USB 1.1
480 + 12+ 1.5 Mbit/s (High + Full « Low Speed)
USB-B (M) male connector
POWER SUPPLY
USB bus power & self power
3.5 mm connector for additional power
OTHER FEATURES
Plug and Play « Hot Plug
Automatic Installation
OS SUPPORTED
Windows + macOS « Linux
Chrome OS « Android
TECHNICAL SUPPORT: More information, FAQs, manuals and drivers can be found on the product page in the PRODUCT SUPPORT tab at www.axagon.eu.
Nothing helped? Write to our technical support: [email protected].
At the end of its service life, do not throw the product into household waste; take it to a collection point for electrical equipment recycling. For information about collection and recycling programmes in your country, contact your local authorities or the retailer who sold you the product.
EU declaration of conformity: The device complies with the harmonisation legislation of the European Union 2014/30/EU (EMC) and 2011/65/EU (RoHS).
The complete EU declaration of conformity is available from the manufacturer.
Before using the product, the user is obliged to read the user instructions. The manufacturer disclaims any liability for damage that may occur due to improper use of the product or failure to follow the instructions contained herein. Product use other than specified must be consulted with the manufacturer.
Do not use the product in humid or explosive environments and near flammable substances.
www.axagon.eu
© 2023 AXAGON
Vyrobce / Manufacturer: RealQ s.r.o. – Zelezna 5, 619 00 Brno, Czech Republic
All rights reserved. All text and pictorial materials contained in this document are protected by Copyright Act.
All marks indicated here are the registered trademarks of their appropriate owners.
Specifications are subject to change without prior notice.
Made in CHINA for Axagon.
