EATON CE0500E4DCE Cutler Hammer Instructions
Eaton, type MTE, industrial control transformer, ce marked, pv:
380/400/415v, taps: none, sv: 110/120v, 55°c, 500 va
General specifications
| Product Name | Eaton Type MTE industrial control transformer |
| Catalog Number | CE0500E4DCE |
| Product Length/Depth | 5.984 in |
| Product Height | 4.764 in |
| Product Width | 5.236 in |
| Product Weight | 21 lb |
| Warranty | Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first. |
| Compliances | |
| Certifications | UL Listed CSA Certified cUL Certified IEC 61558-2 |
| Catalog Notes | Epoxy encapsulated, Laminations of high quality silicon steel to minimize core losses and optimize performance, 50/60Hz operation, 130°C insulation system standard, Molded-in terminals, Non-short circuit-proof |
Physical Attributes
| Coil material | Copper windings |
| Design | MTE |
| Tap size | None |
Performance Ratings
| Primary voltage | 380/400/415 V |
| Temperature rating | 55°C |
| Volt ampere rating | 500 VA |
| Secondary voltage | 110/120 V |
