B-FLCM-FLN-01 Basic Flowline with 180 Degree Rotation
Product Information
The Flycam Basic Flowline Camera Support Rig is a camera
stabilization system that helps to reduce camera shake and provide
smoother, more stable footage. It consists of a support jacket,
support bar, side support bars, and various knobs for
adjustments.
The rig is designed to distribute the weight of the camera setup
across your shoulders and hips, allowing for comfortable use over
extended periods of time. It also includes buckles for adjusting
the fit at the waist and chest.
The support bar can be adjusted in height by loosening the knobs
on the back of the support jacket. The side support bars can also
be adjusted to shift weight to different areas of the body.
The rig features a hook for attaching the camera securely. The
tension of the hook can be adjusted using the provided adjustment
knob.
Please note that the accessories shown in images are optional
and may not be included in the package.
Product Usage Instructions
- Inspect the contents of the package to ensure you have received
everything listed. - Assembly:
- Connect Section-1 of Support Jacket with Section-2 of Support
Bar using the push-fit technique. - Remove the side knobs of Section-2 and join Section-3 with
Section-2. Tighten the knobs back.
- Connect Section-1 of Support Jacket with Section-2 of Support
- Adjustment:
- Tighten the buckles provided at both the waist and chest until
you find a comfortable fit. - Loosen the knob on the hook and attach the camera. Tighten the
knob securely. - Slightly loosen all four knobs on the back of the Support
Jacket to adjust the height of the Support Bar. Use the side
support bars to shift weight to your shoulders and hips. - Use the Adjustment Knob to adjust the tension in an
anti-clockwise direction based on the weight of your setup. - If needed, loosen the knob at the Support Bar and adjust the
position of the camera according to your eye-level.
- Tighten the buckles provided at both the waist and chest until
1
Basic Flowline with 180° Rotation (B-FLCM-FLN-01)
Assembly Manual
What’s In The Box
Please inspect the contents of your shipped package to ensure you have received everything that is listed below.
Flycam Basic Flowline Camera Support Rig
Bag Packing
All rights reserved. No part of this document may be reproduced, stored in a retrieval system, or transmitted by any form or by any means, electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permitted by the applicable copyright
statutes or in writing by the Publisher.
Flowline Rig Setup
Connect Section-1 of Support Jacket with Section-2 of Support Bar by simple push-fit technique.
Remove side knobs of Section-2. Join Section-3 with Section-2 and tighten the knobs back.
Side knob of Section-2
Section-3
Adjust & tighten the buckles provided at both waist & chest, as shown in image, until you find it comfortable.
2
Section-2 Section-1
The Top Bar with 180° Rotation allows easy camera movements to capture different angles.
Loosen the knob on hook and attach camera with it. Tighten the knob back to ensure slipfree connection.
Slightly loosen all the four knobs provided on back of Support Jacket to adjust the height of Support Bar. By adjusting side Support Bars, weight can be easily shifted to your shoulders and hips.
Side support bar
3 Through Adjustment Knob you can adjust
the tension in anti-clockwise direction, according to the weight of your setup. Loosen knob at Support Bar and adjust the position of camera according to your eye-level, if required.
YOUR FLYCAM BASIC FLOWLINE WITH 180° ROTATION ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)
Warranty: We offer one year warranty for our products from date of purchase. Within this period of time, we will repair it without charge for labor or parts. Warranty doesn’t cover transportation costs nor does it cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspection and evaluation by us. Liability: We are not liable for damage caused by products that we do not supply or from mishandling in transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company. Contact Us: In case of any kind of dissatisfaction, please Contact us immediately and we promise our utmost support and care until you use our product.
