Numatic Mm-4 Trolley Instruction Manual

MM-4 Trolley

Product Information: MM-4 Trolley Assembly

The MM-4 Trolley Assembly is a cleaning trolley designed to
assist in the cleaning process. The trolley comes with a variety of
components that include a Reflo Base, Left Hand Upright, Right Hand
Upright, Handle Frame, Bag Securing Lid, 5 Litre Bucket, Red
Handle, Blue Handle, Versaclean Hook, T Slot 22mm, Mid Mop Clamp,
Clean Water Bucket – Blue Handle, Dirty Water Bucket – Red Handle,
Mid Mop Press, Mop Press Handle, C Clip and 70-Litre Grey Waste
Bags (Roll of 10).

Product Usage Instructions:

1. Start by unpacking all components of the MM-4 Trolley
   Assembly.
2. Attach the Reflo Base to the Left Hand Upright and Right Hand
   Upright using the provided M8 25mm Socket Bolt x2.
3. Attach the Handle Frame to the Left Hand Upright and Right Hand
   Upright using the provided M8 X 25mm Socket Bolt x2.
4. Attach the Bag Securing Lid to the Handle Frame using the
   provided M8 X 25mm Socket Bolt x2.
5. Attach the 5 Litre Bucket to the trolley using the Red Handle
   and Blue Handle.
6. Attach the Versaclean Hook to the T Slot 22mm and attach the
   Mid Mop Clamp to it.
7. Attach the Clean Water Bucket to the trolley using the Blue
   Handle.
8. Attach the Dirty Water Bucket to the trolley using the Red
   Handle.
9. Attach the Mid Mop Press to the trolley.
10. Attach the Mop Press Handle to the Mid Mop Press using the
    provided C Clip.
11. Attach the 70-Litre Grey Waste Bags (Roll of 10) to the
    trolley.
12. Once all components are attached, the MM-4 Trolley Assembly is
    ready to be used for cleaning purposes.

MM-4 Trolley Assembly
914824 MM-4 Trolley Assembly Instructions A03 07/2022

0.15 HR

8 9
7 17
16 2
18 12
13

4

5 3

6
15 14

10 11

1

1

Item 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19

Description Reflo Base
Left Hand Upright Right Hand Upright
Handle Frame Bag Securing Lid 5 Litre Bucket Red Handle Blue Handle
Versaclean Hook T Slot 22mm Mid Mop Clamp
Clean Water Bucket – Blue Handle
Dirty Water Bucket – Red Handle Mid Mop Press
Mop Press Handle C Clip
70-Litre Grey Waste Bags (Roll of 10)

Quantity 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 0.1

2

3

4

x4

x2

5

M8 25mm Socket Bolt x2
x2 6

7

M8 X 25mm Socket Bolt x2
x2
8

9

10

11

12

13

14

914824 MM-4 Trolley Assembly Instructions A03 07/2022 15
