FreeSpace FS2C Ceiling Passive Loudspeaker
Product Information: FreeSpace FS2C & FS4CE Adjustable Tile
Bridge
The FreeSpace FS2C & FS4CE Adjustable Tile Bridge is a
product designed for professional installers to securely mount
loudspeakers onto ceiling grids or hard ceilings. The package
contents include the tile bridge pack, and the product dimensions
vary depending on the model.
- FreeSpace FS2C: 0.72 kg (1.59 lb), 162 mm x 265 mm x 644
mm - FreeSpace FS4CE: 0.86 kg (1.90 lb), 249 mm x 365 mm x 644
mm
The product comes with safety instructions and warnings, and it
is recommended that professional installers read and follow these
guidelines before attempting installation. Bose also recommends
using a safety wire as a secondary securing mechanism in compliance
with regional construction codes and regulations.
This product is covered by a limited warranty, and for more
details on the warranty, visit PRO.BOSE.COM.
Product Usage: Installing the Tile Bridge
The following instructions are provided for installing the tile
bridge onto an acoustic ceiling tile or hard ceiling.
Installing a Tile Bridge in Acoustic Ceiling Tile
Note: Ensure that you have read and followed all safety
instructions and guidelines before attempting to install the tile
bridge.
Cutting the Ceiling Tile
- Remove the tile and use the template included with your
loudspeaker to trace a loudspeaker hole onto the tile. To center
the template on the tile, draw an X by connecting the corners
diagonally and center the template using the crossing point. - Cut a hole into the tile.
Installing the Tile Bridge
- Place the assembled tile bridge across the ceiling grid. If
necessary, adjust the tile bridge so the rails rest on the ceiling
grid. - Replace the tile in the ceiling.
Note: For instructions on loudspeaker installation, refer to
the Mounting the Loudspeaker section in the appropriate loudspeaker
installation guide.
Installing a Tile Bridge in Hard Ceiling (Existing
Construction)
Note: Ensure that you have read and followed all safety
instructions and guidelines before attempting to install the tile
bridge.
Cutting the Ceiling
- Use the template to trace a hole onto the ceiling.
- Cut a hole into the ceiling.
Installing the Tile Bridge
- Align the rails and insert the tabs into the slots.
- Pull the rails outward to secure them together.
- Note: If you are installing in a hard ceiling, assemble the
tile bridge after inserting the rails and ring through the hole
cutout. - Align the rails parallel to each other and press the tile
bridge ring down to secure the ring to the rails.
FreeSpace FS2C & FS4CE
Adjustable Tile Bridge
Installation Guide . . . . . . . . . . . . . . . . . . . . . . . 2 Guía de instalación . . . . . . . . . . . . . . . . . . . . . 4 Notice d’installation . . . . . . . . . . . . . . . . . . . . 6 Installationsanleitung . . . . . . . . . . . . . . . . . . . 8 Guida all’installazione . . . . . . . . . . . . . . . . . . 10 Installatiehandleiding . . . . . . . . . . . . . . . . . . .12
Monteringsveiledning . . . . . . . . . . . . . . . . . . 14
Instrukcja montau . . . . . . . . . . . . . . . . . . . . 16
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
24
Overview
Important Safety Instructions
Please read and keep all safety and use instructions. This product is intended for installation by professional installers only! This document is intended to provide professional installers with basic installation and safety guidelines for this product in typical fixed-installation systems. Please read this document and all safety warnings before attempting installation.
WARNINGS/CAUTIONS:
All Bose products must be installed in accordance with local, state, federal and industry regulations. It is the installer’s responsibility to ensure installation of the loudspeakers and mounting system is performed in accordance with all applicable codes, including local building codes and regulations. Consult the local authority having jurisdiction before installing this product. Unsafe mounting or overhead suspension of any heavy load can result in serious injury or death, and property damage. It is the installer’s responsibility to evaluate the reliability of any mounting method used for their application. Only professional installers with the knowledge of proper hardware and safe mounting techniques should attempt to install any loudspeaker overhead. Do not mount on surfaces that are not sturdy, or that have hazards concealed behind them, such as electrical wiring or plumbing. Ensure the bracket is installed by a qualified professional installer and in accordance with local building codes.
Regulatory Information
Date of Manufacture: The eighth digit in the serial number indicates the year of manufacture; “7” is 2007 or 2017. China Importer: Bose Electronics (Shanghai) Company Limited, Part C, Plant 9, No. 353 North Riying Road, China (Shanghai) Pilot Free Trade Zone EU Importer: Bose Products B.V., Gorslaan 60, 1441 RG Purmerend, The Netherlands Mexico Importer: Bose de México, S. de R.L. de C.V. , Paseo de las Palmas 405-204, Lomas de Chapultepec, 11000 México, D.F. For importer & service information: +5255 (5202) 3545 Taiwan Importer: Bose Taiwan Branch, 9F-A1, No. 10, Section 3, Minsheng East Road, Taipei City 104, Taiwan. Phone Number: +886-2-2514 7676 Bose Corporation Headquarters: 1-877-230-5639 Bose and FreeSpace are trademarks of Bose Corporation. ©2020 Bose Corporation. No part of this work may be reproduced, modified, distributed or otherwise used without prior written permission.
Warranty Information This product is covered by a limited warranty. For warranty details, visit PRO.BOSE.COM.
Using a Safety Cable
Some regional construction codes require the use of a secondary method of securing loudspeakers to support structures to provide additional safety . Choose a mounting position, method, and hardware consistent with local building codes and regulations .
Bose recommends using (1) a safety wire as a secondary securing mechanism . See the diagram below for safety attachment points .
Follow the manufacturer’s instructions for any secondary securing mechanism implemented .
q
PRO.BOSE.COM
Package Contents
FreeSpace FS2C Tile Bridge Pack
×6
×12
FreeSpace FS4CE Tile Bridge Pack
×6
×12
Product Dimensions
FreeSpace FS2C 0 .72 kg (1 .59 lb)
162 mm 6 .38 in
265 mm 10 .43 in
644 mm 25 .35 in
FreeSpace FS4CE 0 .86 kg (1 .90 lb)
249 mm 9 .80 in
365 mm 14 .37 in
2 · English
644 mm 25 .35 in
FreeSpace Adjustable Tile Bridge · Installation Guide
PRO.BOSE.COM
Installation
Assembling the Tile Bridge
1 . Align the rails and insert the tabs into the slots . 2 . Pull the rails outward to secure them together .
Note: If you are installing in a hard ceiling, assemble the tile bridge after inserting the rails and ring through the hole cutout. 3 . Align the rails parallel to each other and press the tile bridge ring down to secure the ring to the rails .
q
w
e
Installing a Tile Bridge in Acoustic Ceiling Tile
Cutting the Ceiling Tile
q
w
1 . Remove the tile and use the template included
with your loudspeaker to trace a loudspeaker
hole onto the tile . To center the template on
the tile, draw an X by connecting the corners
diagonally and center the template using the
crossing point .
2 . Cut a hole into the tile .
Installing the Tile Bridge
q
w
1 . Place the assembled tile bridge across the
ceiling grid . If necessary, adjust the tile bridge
so the rails rest on the ceiling grid .
2 . Replace the tile in the ceiling .
For instructions on loudspeaker installation, see the Mounting the Loudspeaker section in the appropriate loudspeaker installation guide .
Installing a Tile Bridge in Hard Ceiling (Existing Construction)
Cutting the Ceiling
q
w
1 . Use the template to trace a hole onto the
ceiling .
2 . Cut a hole into the ceiling .
Installing the Tile Bridge
1 . Insert the tile bridge rails and ring through
q the hole and place the rails parallel to each
other across the ceiling grid or ceiling
w
furring .
2 . Assemble the tile bridge .
For instructions on loudspeaker installation, see the Mounting the Loudspeaker section in the appropriate loudspeaker installation guide .
Installation Guide · FreeSpace Adjustable Tile Bridge
English · 3
©2020 Bose Corporation, All rights reserved . Framingham, MA 01701-9168 USA PRO .BOSE .COM AM850711 Rev . 00 January 2020
