62-84 Brushed Nickel Tube Mini Pendant Light
Product Information:
The product being referred to in the manual is item#62-84, which
was released on September 17th, 2019. The manual provides
instructions for the installation of the fixture and also includes
a cautionary message to shut off power at the fuse box or circuit
breaker box before proceeding with the installation. The manual
also includes two figures, Fig. 1 and Fig. 2, which illustrate the
preparation and wire connection process respectively. The fixture
comes with mounting hardware, a crossbar, a ground screw, two
mounting screws, and a rod.
Product Usage Instructions:
- Before starting with the installation process, ensure that the
power supply to the outlet box is switched off at the fuse box or
circuit breaker box. - Remove the old fixture, including the mounting hardware,
carefully from the outlet box. - Unpack the new fixture and lay out all the components.
- Attach the crossbar to the outlet box using the two mounting
screws provided. - Connect the ground wire of the fixture to the ground screw on
the crossbar using a screwdriver. - Connect the black or smooth wire of the fixture to the black or
hot wire of the house using wire connectors. - Connect the white or ribbed wire of the fixture to the white or
neutral wire of the house using wire connectors. - Connect the bare copper wire of the fixture to the green or
ground wire of the house using wire connectors. - Carefully tuck all wires into the outlet box and attach the
fixture to the crossbar using screws provided. - Turn on power at the fuse box or circuit breaker box and test
the fixture to ensure that it is working correctly.
Note: The illustration provided in Fig. 1 is for installation
purposes only and may not be identical to the fixture
purchased.
INSTALLATION INSTRUCTIONS
Item#62-84 (New. 09/17/2019) READ AND SAVE THESE INSTRUCTIONS
W AR NI N G ! S HU T P O WE R O F F AT F U S E O R CI R C UI T B R E AK E R .
AVERTISSEMENT! COUPER LE COURANT AU NIVEAU DES FUSIBLES OU DU DISJONCTEUR.
PREPARATION (Fig. 1) 1. Shut off power at the fuse box or circuit breaker box and
remove the old fixture including the mounting hardware. 2. Carefully unpack your new fixture and lay out all the
parts in a clean area. Take care not to misplace any small parts necessary for installation. ASSEMBLING THE FIXTURE (Fig. 1) 3. Determine the desired hanging height and thread rods (F1, F2 and F3) to nipple of holder (G). Attach canopy (D) by screwing onto rod (F1). Carefully pass the wires through each rod during assembly. Note: remove the nipple if installing with one 6″ rod only. 4. Thread screws (A) into the pre-drilled holes in the crossbar (B) spaced the same distance apart as the holes in the canopy (D). 5. Attach the crossbar (B) to the outlet box using mounting screws (C) (Size: #8-32N*L0.5″). The side of the crossbar marked “GND” must face out.
CONNECTING THE WIRES (Fig. 2) 6. At this point, connect the electrical wires as shown in
figure 2, making sure that all wire connectors are secured. If your outlet has a ground wire (green or bare copper), connect the fixture’s ground wire to it. Otherwise, connect the fixture’s ground wire directly to the crossbar using the green screw provided. 7. Tuck the wire connectors neatly into the ceiling outlet box and raise the canopy all the way to the ceiling. COMPLETING THE INSTALLATION (Fig. 1) 8. Thread screws (A) into canopy (D), and secure with knurled knobs (E). 9. Install (1) one medium base bulb (J) up to 60 watts or CFL or LED equivalent (not included) in accordance with the fixture specification — DO NOT EXCEED THE MAXIMUM WATTAGE RATING! (NE PAS DEPASSER LA PUISSANCE NOMINALE MAXIMALE! 10. Insert the glass shade (I) into the holder (G) and secure the shade assembly by adjusting each screw (H) in the holder.
Your installation is now complete. Return power to the outlet box and test the fixture.
Note: Illustration (Fig. 1) on this manual is for installation purposes only. It may or may not be identical to the fixture purchased.
Fig. 1
Fig. 2
FIXTURE WIRES Black or Smooth
A B Set# A-010 C -Crossbar*1 D -Ground screw*1
-Mounting Screw*2 E F1
Rod# W30-1-84*1(F1) W30-1-84*2(F2)
F2 W30-H-84*1(F3)
F3
H
G
I
J
FIXTURE WIRES White or Ribbed
FIXTURE WIRES Bare Copper (Ground)
HOUSE WIRES Black (Hot)
HOUSE WIRES White (Neutral)
HOUSE WIRES Green (Ground)
Page: 1/1
LA-3148E
