P5401-718-L LED Pendant
Product Information: LED Pendant Light Fixture
(P5401-718-L)
The LED Pendant Light Fixture (P5401-718-L) is a modern and
stylish lighting solution for your home or office. It comes with a
mounting plate, ground screw, and mounting screws for easy
installation. The fixture is dimmable with ELV and/or LED
compatible wall dimmer switches.
Installation Instructions:
WARNING: Before installing the fixture, shut
off power at the fuse box or circuit breaker.
- Remove the old fixture, including the mounting hardware.
- Carefully remove the fixture from the carton and check that all
parts are included as shown in Figure 1. - Unscrew screws (G) to remove mounting plate (A) from canopy
(F). - Position mounting plate (A) on the ceiling and attach it to the
junction box (not included) using the mounting screws (B, size
8#-32N 1). The side of the mounting plate marked GND must face out
as shown in Fig.1. - Connect the electrical wire as shown in Fig 2, making sure that
all wire connectors are secured. If your junction box has a ground
wire (green or bare copper), connect the ground wire from the
fixture to it. Otherwise, connect fixture ground wire directly to
the mounting plate (A) using the green screw (D) provided. Tuck the
wire connections neatly into the ceiling junction box. - Slide canopy (F) over mounting plate (A) and secure it with
screws (G). - Unscrew finial (J). Slide glass shade (E), acrylic diffuser
(H), and gold decorative piece (I) to the lamp body (L) and secure
it with finial (J). - Finally, tear off the protective film at the bottom of canopy
(F).
CAUTION: When handling the fixture, do not
apply pressure to the LEDs. Hold the fixture by the frame only.
IMPORTANT: Fixtures should be installed by a
qualified electrician to ensure proper wiring and installation.
INSTALLATION INSTRUCTIONS FOR P5401-718-L
For LED Pendant
WARNINGR!SEHAUDTAPNODWSEARVEOFTFHEASTEFIUNSSETROURCCTIIROCNUSIT BREAKER AVERTISSEMENT!COUPER LE COURANT AU NIVEAU DES FUSIBLES OU DO DISJONCTEU
ASSEMBLING THE FIXTURE (Fig.1) 1. Shut off power at the fuse box or circuit breaker. Remove the old fixture
Fig 1
including the mounting hardware.
2. Carefully remove the fixture from the carton and check that all parts are
included as show in Figure 1.
3. Unscrew screws (G) to remove mounting plate (A) from canopy (F).
Position mounting plate (A) on the ceiling and attached to the junction box (not
included) using the mounting screws (B, size 8#-32N 1″). The side of the
mounting plate marked “GND” must face out as shown in Fig.1.
4. The length of the power cord can be adjusted by loosening the set screw
(S), then tighten the set screw (S).
CONNECTING THE WIRES (Fig. 2) 5. Connect the electrical wire as shown in Fig 2. Making sure that all wire connectors and secured. If your junction box has a ground wire (green or bare copper), connect the ground wire from the fixture to it. Otherwise connect fixture ground wire directly to the mounting plate (A) using the green screw (D) provided. Tuck the wire connections neatly into the ceiling junction box.
FINISHING THE INSTALLATION (Fig.1) 6. Slide canopy (F) over mounting plate (A) and secure with screws (G). 7. Unscrew finial (J). Slide glass shade (E), acrylic diffuser (H), and gold decorative piece (I) to the lamp body (L) and secure with finial (J). 8. Finally, tear off the protective film at the bottom of canopy (F).
Your installation is now complete. Return power to the junction box and test the fixture.
CAUTION/ATTENTION: When handling the fixture, do not apply pressure to the LEDs. Hold the fixture by the frame only.
IMPORTANT: Fixtures should be installed by a qualified electrician to ensure proper wiring and installation.
Dimmable with ELV and/or LED compatible wall dimmer switches.
Set# A-020-115 -mounting plate -Ground Screw -Mounting Screw*2
Fig 2
