1GWIUXD Weatherproof In-Use Cover
Product Information
The Extra Duty Plastic In-Use Covers are listed under File No.
E362580. They come in three different variations: 1-Gang Extra Duty
In-Use Cover 18 in 1, 2-Gang Extra Duty In-Use Cover 45 in 1, and
Superflex Item No. 1GWIUXD. The 1-Gang Extra Duty In-Use Cover 18
in 1 can be mounted horizontally or vertically and fits a full-size
padlock. The 2-Gang Extra Duty In-Use Cover 45 in 1 comes with
various configurations of GFCI Duplex Switch Rounds. All covers
must be marked Extra-Duty if installed in a wet location using a 15
or 20 amp receptacle.
The covers come in three different colors: Gray, White, and
Clear/Gray. The 1-Gang Extra Duty In-Use Cover 18 in 1 comes in
Gray or White and is available in a package of 10. The Superflex
Item No. 1GWIUXD comes in Clear/Gray and is available in a package
of 6.
According to the National Electrical Code 2014 Edition, all 15-
and 20-ampere, 125- and 250-volt nonlocking-type receptacles
installed in a wet location shall be listed weather-resistant type.
An outlet box hood installed for this purpose shall be listed and
shall be identified as extra-duty.
Product Usage Instructions
The Extra Duty Plastic In-Use Covers are designed to protect
electrical outlets from moisture when used in damp or wet
locations. Follow these steps to use the covers:
- Choose the appropriate cover based on the number of gangs
required and the configuration of GFCI Duplex Switch Rounds. - Ensure that the cover is marked Extra-Duty if it will be
installed in a wet location using a 15 or 20 amp receptacle. - Mount the cover horizontally or vertically using the
appropriate mounting hardware. - If using a padlock, ensure that it fits the full-size padlock
opening on the cover. - Insert the electrical outlet and attach the cover to the outlet
box using the provided screws. - Ensure that the cover is securely attached to the outlet box
and that there are no gaps between the cover and the box.
If you have any questions or concerns about using the Extra Duty
Plastic In-Use Covers, contact the manufacturer at (800) 394-3665
or refer to the product user manual.
EXTRA DUTY PLASTIC IN-USE COVERS
· UL Extra Duty Compliant · Patented Multi-Configuration Design · 1 Gang can be used Horizontally or Vertically · Durable Polycarbonate Construction · Lockable
· Easy to Install
· 3-1/4″ Deept
· Includes Gasket and Mounting Hardware
·
Listed File No. E362580
· NEC Compliant
18in1
45in1
1 Gang Mounts Horizontally
or Vertically
1GWIUXD
Fits Full Size Padlock
2GWIUXD
GFCI Duplex Switch 6 Rounds:
1-1/4″ 1-3/8″ 1-9/16″ 1-5/8″ 1-11/16″ 2-1/8″
Various Configurations of:
GFCI Duplex Switch Rounds:
1-1/4″ 1-3/8″ 1-9/16″ 1-5/8″ 1-11/16″ 2-1/8″ 2-1/4″ 2-7/16″
Superflex Item No. 1GWIUXD
Description 1-Gang Extra Duty In-Use Cover 18 in 1
Color Clear/Gray
Pkg Qty 10
1GWIUXDGY 1GWIUXDWH 2GWIUXD
1-Gang Extra Duty In-Use Cover 18 in 1 1-Gang Extra Duty In-Use Cover 18 in 1 2-Gang Extra Duty In-Use Cover 45 in 1
Gray
10
White
10
Clear/Gray
6
NATIONAL ELECTRICAL CODE 2014 EDITION 406.9 Receptacles in Damp or Wet Locations
(B) Wet Locations. (1) Receptacles of 15 and 20 Amperes in a Wet Location. 15- and 20-ampere, 125- and 250-volt receptacles installed in a wet location shall have an enclosure that is weatherproof whether or not the attachment plug cap is inserted.
An outlet box hood installed for this purpose shall be listed and shall be identified as “extra-duty.” All 15- and 20- ampere, 125- and 250-volt nonlocking-type receptacles shall be listed weather resistant type.
All While In Use Covers installed in a Wet Location using a 15 or 20 amp receptacle must be marked “Extra-Duty”
1
®
Tel: (800) 394-3665 Fax: (718) 768-5065
