Neutrik Nl2frx Speakon Spx Series Lockable Loudspeaker Connector Instruction Manual

NL2FRX speakON SPX Series Lockable Loudspeaker Connector

Product Information

The NL2FX/NL2FRX is a speakON connector used for audio
applications. It has an electrical rating of USR: 40A/250V and CNR:
25A/250V according to UL and CSA standards. The connector is not
designed for interrupting current and should not be used as an AC
mains or power supply connector. The connector can accommodate
cables with an outer diameter of 6.0 – 10.0 mm and wire sizes of
1.5 – 4 mm2 (AWG 12). The stripping length of the cable should be
25 mm and 12 mm.

Product Usage Instructions

Assembly of the Connector:

1. Place the bushing and chuck over the cable.
2. Prepare the cable by stripping it to a length of 25 mm and 12
   mm.
3. Push the chuck up to the housing, aligning the chuck by
   positioning the nose into the recess.
4. Finish the installation by turning the bushing onto the
   connector.

Assembly of the Conversion Kit LRX:

1. Open the bushing and slide it and the chuck back.
2. Bend the cable as shown.
3. Position the two conversion shells to fit on the connector
   thread.
4. Press them together and fix with a screw.
5. Slide the chuck onto the housing and fasten the bushing,
   aligning the chuck by positioning the nose into the recess.

Note: Do not use a Philips screw driver (BDA 348) for
installation.

For more information, visit www.neutrik.com or contact NEUTRIK
AG, NEUTRIK USA Inc., NEUTRIK (UK) Ltd., NEUTRIK Vertriebs GmbH,
NEUTRIK France, NEUTRIK Tokyo Ltd., NEUTRIK Hong Kong Ltd., or
NEUTRIK India Pvt. Ltd.

R ASSEMBLY INSTRUCTION
NL2FX / NL2FRX
speakON® SPX Series Lockable Loudspeaker Connector

IMPORTANT SAFETY INSTRUCTION

Electrical Rating acc. UL & CSA: USR: 40A/250V, CNR: 25A/250V

“CAUTION: NOT FOR INTERRUPTING CURRENT” “ATTENTION: NE PAS UTILISER POUR COUPER LE COURANT”

Attention:

speakON is not to be used as an AC mains or power supply connector!

A

2.

1.

B Cable O.D. 6.0 – 10.0 mm

25 mm [1.0″]

Wire size 1.5 – 4 mm2
(AWG 12)

12 mm [0.5″]

C
1-

1- 1+
1+

Assembly of the Connector:
A Place bushing and chuck over cable. B Prepare cable as shown.
Important is the stripping length of 25 mm and 12 mm.
C Insert wires into terminals and secure clamp terminals with screw driver (POZIDRIV® # 1) at max. torque 0.8 Nm. For 6 mm2 (AWG 10) remove screws, clamping sheet and solder.
D Push chuck up to housing . Important: Align the chuck by positioning the nose into the recess.
E Finish installation by turning the bushing onto the connector.
INFO to the screw driver:
X

D E

POZIDRIV® # 1

DO NOT USE! Philips

BDA 348

E
ð
Page 1

ASSEMBLY INSTRUCTION I speakON NL2FX / NL2FRX

A
B 2.
1.

Assembly of the Conversion Kit LRX:
A Open the bushing. B Slide the bushing and the chuck back.
C Bend the cable as shown.
D Position the two conversion shells to fit on the connector thread.
E Press together and fix by screw.
F Slide the chuck onto the housing and fasten the bushing.
Important: Align the chuck by positioning the nose into the recess.

C D E
F
F

Find more details of speakCON on www.neutrik.com.

NEUTRIK AG
NEUTRIK USA Inc. NEUTRIK (UK) Ltd.
NEUTRIK Vertriebs GmbH

LI USA UK DE / NL / AT/DK

T: +423 / 237 24 24 T: +1 704 / 972 3050 T: +44 1983 / 811 441 T: +49 8131 / 280 890

F: +423 / 232 53 93 F: +1 704 / 438 9202 F: +44 1983 / 811 439 F: +49 8131 / 280 830

NEUTRIK France

FR T: +33 1 / 4131 6750 F: +33 1 / 4131 0511

NEUTRIK Tokyo Ltd.

JP T: +81 3 / 3663 4733 F: +81 3 / 3663 4796

NEUTRIK Hong Kong Ltd. HK T: +852 / 2687 6055 F: +852 / 2687 6052

NEUTRIK India Pvt. Ltd. IND T: +91 / 982 05 43 424 F: +91 / 22 26163 540

I I Draft. Nr.: BDA 348

Update: 22.11.2016

Data subject to change without prior notice. ©2016 NEUTRIK® . ALL RIGHTS RESERVED. NEUTRIK® is a registered trademark.
