ESYTWIN Docking Station
Instruction Manual
ESYTWIN Docking Station
| Index | Q.ty | Description |
| 9 | 2 | THREAD GUARD PLUG D.1 1/4 |
| 8 | 2 | FCT EXTERNAL FITTING |
| 7 | 2 | PLUG 3/8 BLACK CROSS -PA66+30GF |
| 6 | 8 | CLIP – SQUARE SECT.4 – SPAN 41,5 |
| 5 | 2 | CAP 1″ BLACK WRAS |
| 4 | 2 | FCT RETAINER DEVICE |
| 3 | 4 | FCT LOGO PLATE STOPPER |
| 2 | 2 | FCT LOGO PLATE |
| 11 | 11 | BASE AND SUPPORT BASE TWIN E.SYBOX |
| 18 | 2 | FCT MANIFOLD |
| 17 | 1 | KIT SCREWS |
| 16 | 1 | KIT O-RING TWIN |
| 15 | 1 | KIT O-RING FCT |
| 14 | 4 | FCT INTERNAL FITTING |
| 13 | 2 | FCT COVER |
| 12 | 2 | CONNECTION CUP FITTING FCT |
| 11 | 4 | O-RING 28.17X3.53 FKM70 GREEN |
| 10 | 4 | PLUG FOR PIPE 1 |
