Product Information
- Product Name: 3.5 m & 3.0m Premium Free Arm Parasol
- Model Number: PL35 & PLS30
- Assembly Time: 30 minutes
- Persons Required for Assembly: 1
- Parts Included:
- Parasol
- Base Lever
- Solar Panel
- Protective Cover Including 3-Part Support Rod
- Allen Key & Spanner
- Adjusting Lever
- USB Cable
- Wireless Speaker
- Bolt with washer M10x20mm
- Removable Battery Pack
- Inverted Base Stem
- Base Shell
- Base Lid
- Plate Bolts M8x23
- Inverted Plate
- UV Protection: UV50+
Product Usage Instructions
Assembly Instructions
Before you begin assembling the product, please read through the
instructions carefully. Keep all the parts and fixings in the
packaging until you have checked that you have all the parts.
- Assemble the three parts of the Fibreglass supporting rod in
sequence and put it into the slit in the fabric at the bottom of
the zip. - Place the cover on the parasol and metal frame, and zip it
down. - Fill each segment completely with kiln-dried sand and then add
water. Do not allow sand to spill into the base stem channels as it
will impede further installation. - Carefully remove the inverted base stem from the base
shell. - Remove bolts and then remove the Base Lever D.
- Place part A (canopy) on part D and reattach bolts.
- Assemble the parasol on a soft surface.
- To ensure easier assembly, finger-tighten all fittings during
initial assembly. Fully tighten all fixing points only upon
completion of the assembly. - Keep all fittings out of children’s reach and only use the
recommended tools to build the product. - Do not use substitute parts. Use only additional or replacement
parts supplied by Kettler. - If you have missing or damaged parts, please visit our website
www.kettler.co.uk.
Operating Instructions
The parasol comes with a Wireless Speaker with LED Light, Power
Base, and a Removable Battery Pack. The power base and battery pack
are connected by magnet.
- Power Indicator Light Switch
- Power Base
- Light Switch
- USB Port
- Power Indicator Light
- Removable Battery Pack
- USB Output
Protective Cover Assembly
The parasol should be closed and the night cover fitted in windy
conditions. Failure to do this may result in damage to the
parasol.
UV Protection
This parasol has UV50+ protection, which means that it reduces
your skin’s UV radiation exposure by 50 times (98% UV block).
Assembly Instructions
3.5 m & 3.0m Premium Free Arm Parasol
PL35 & PLS30
IMPORTANT PLEASE KEEP THIS BOOKLET FOR FUTURE REFERENCE. THIS IS IMPORTANT INFORMATION REGARDING THE
USE AND CARE OF YOUR GARDEN FURNITURE.
March 2023
30
MINUTES
ASSEMBLY TIME
PERSONS REQUIRED
1
Parts List
A Parasol D Base Lever
B Solar Panel
C Protective Cover Including 3-Part Support Rod
x1
I Allen Key & Spanner
x1
F Adjusting Lever
P USB Cable
x1
x1
x1
x1
x1
Q Wireless Speaker
R Bolt with washer
M10x20mm
S Removable Battery Pack
x1
J Inverted Base Stem K Base Shell
x1
L Base Lid
x4
x1
M Inverted Base Stem
x1
x1
x1
x1
H Plate Bolts M8x23
N Allen Key
O Inverted Plate
x4
x1
x1
Do not discard any of the packaging until you have checked that you have all the parts and the pack of fixings.
2
Assembly
Helpful advice before you begin:
1. We suggest you spend a short time reading through this leaflet and then follow the simple step by step instructions.
2. Do not discard any of the packaging until you have checked that you have all the parts and the pack of fittings.
3. Assemble this product on a soft surface.
4. To ensure an easier assembly, we strongly advise that all fittings are only finger tightened during initial assembly. Only upon completion of the assembly should all fixing points be fully tightened.
5. Keep fittings out of children’s reach.
6. Do not use any other tools other than those recommended to build this product.
7. Please do not use substitute parts. Use only additional or replacement parts supplied by Kettler.
8. In the unlikely event that this product has missing or damaged parts, please visit our website www.kettler.co.uk
Assembly
1
O
2
M J
3
Assembly
3
L
4
5 Fill each segment completely with kiln dried sand and then add water. Do not allow sand to spill into the base stem channels as it will impede further installation.
Water
Sand
6
Carefully remove inverted base
stem from base shell.
J
7
M
8
N
J
L
H
K
4
Assembly
9
B
10
Remove bolts and then remove the Base Lever D
D
11
D
R R
5
Assembly
12
A
Place part A (canopy) on part D and reattach bolts.
D
13
A
2 1
F F
3
6
Operating Instructions
7
Operating Instructions
8
Operating Instructions
Power Indicator Light Switch
Power Base
Light Switch
USB Port
Power Indicator Light
Removable Battery Pack
USB Output
The power base and battery pack are connected by
magnet.
Changing an LED light strip
USB Cable
6
Protective cover assembly:
Fibreglass supporting rod
1. Assemble the
three part of
Fibreglass rods in
Sequence and
Put it into the slit in fabric at bottom of zip.
The parasol should be closed and the night cover fitted in windy conditions. Failure to do this may result in damage to the parasol.
2. Place cover
on the Parasol and metal frame and zip down.
9
Parasol Wireless Speaker with LED Light
1
2
Functions
3
1. Bluetooth Switch
2. LED Light Power Switch
4
3. Unlock Button
4. LED Light
5. Charging Port
5
1
2
3
4
Unscrew and pull down middle section and attach the Wireless speaker here.
Charging:
· Charge for 2-4 hours for the 1st charge. · Plug the adapter in the charging port and
plug into the power supply (100-240V). · We recommended 1.2amp maximum
output. Anything over this continuous use could result in reduced life span of the battery. · When charging the red light will light up and go off when fully charged. · Always charge in a dry environment.
User guide:
· To turn on, hold down the wireless switch for 3 seconds.
· Turn on your device’s Wireless function and search for “Kettler”.
· The run time is approx. 6-10 hours. · To turn the light on/off press the “LIGHT”
button.
10
Warning:
· Wireless connectivity will turn off when not used for 15 minutes.
· The sound quality will be reduced when the battery is low.
· Use wirelessly for upto 8-10metre range. Any more than this will affect the sound quality.
· Only one device can be connected at any one time.
· Do not allow the speaker unit to get wet. · Store in a dry place when not in use.
UV
This parasol has UV50+ protection. What does that mean?
For example, a fabric with a UPF rating of 50 only allows 1/50th of the sun’s UV radiation to pass through it. This means that this fabric will reduce your skin’s UV radiation exposure by 50 times (98% UV block).
Hand wash canopy
The canopy can be carefully removed and washed via hand only. We advise putting back onto the frame to dry naturally.
11
For Your Safety
· This product may only be used for its intended purpose as furniture for residential properties. · Check all components regularly for correct function, damage and loose connections especially
at the start of the season and at 1-2 month intervals dependent on use. · Damaged components may endanger your safety or shorten the life of the product. Replace all
damaged parts immediately. Use only spare parts manufactured by Kettler. Should you wish to purchase spare parts, they can be ordered directly from: www.kettler.co.uk/shop · Kettler will not be responsible for damaged caused by improper use.
Attention
· Whilst assembling this product keep out of the reach of children. (Choking hazard contains small parts)
· Ensure that your working area is free of possible sources of danger, for example don’t leave any tools lying around.
· Always dispose of packaging material in such a way that it may not cause any danger. There is always a risk of suffocation if children play with plastic bags!
· We reserve the right to make changes for technical reasons.
www.kettler.co.uk
The symbol indicates that the product should not be discarded as unsorted waste but must be sent to separate collection facilities for recovery and recycling.
12
Month
Warranty
Warranty For Home Use
KETTLER parasols are covered by a 12 MONTH WARRANTY.
The warranty applies to domestic use only. The warranty does not cover accidental
damage (including wind damage) or mis-use. To validate your warranty, register at
www.kettler.co.uk and quote the product code from the front of this booklet.
12
