TG70P3573D01 Oregonian Slim-7.5-LED Color Changing

Product Information

The product is a Christmas tree that comes with a Dual Color
Light Controller. The tree is highly compressed for shipping and
requires proper shaping for a full, realistic look. It has
well-spaced lights and is available in tall sizes. The product
comes with detailed assembly instructions.

Assembly Instructions

1. Insert the Red Label Plugs into the Red Labeled Extension
   Cord.
2. Insert the Yellow Label Plugs into the Yellow Labeled Extension
   Cord.
3. Insert the Adapter into the Wall Outlet.
4. Align the Flange and Stand holes and screw in the Eye
   Bolt.
5. If you have purchased a tall tree, shape the top section before
   inserting it into Section 2.

Note: Do not step on the tree stand legs during setup, as this
may deform the tree stand and result in an unbalanced tree.

Dual Color Light Controller Usage Instructions

To use the Dual Color Light Controller, follow these steps:

1. Press the Selector Button on the Dual Color Light Controller to
   select among the following options:
   1. CLEAR-MULTI: FADING
   2. CLEAR: FADING
   3. CLEAR-MULTI: ALTERNATING
   4. CLEAR: STEADY
   5. CLEAR-MULTI: SLOW FADING
   6. MULTI: STEADY
   7. MULTI: FADING
   8. COMBINATION
2. Check the Electrical Range for the Tree, which is as follows:
   • Input: AC 120V, 60Hz, 0.38A
   • Output: DC 29V, 0.621A
   • Controller: 0.621A
3. If your entire tree does not light up, refer to the warning and
   caution statements in the manual for troubleshooting.

The product can only be used with the included controller and
remote controller, if applicable.

ASSEMBLY INSTRUCTIONS
‘Z
· efore you start to assemble your tree, choose a locaon that pro ides enough space for the width of your tree. or pre-lit trees, choose a locaon near an electrical outlet.
· nwrap the plasc wrap from around all the secons and notate the idenfying tag on each secon. All secons are labeled for ease of assembly for e ample, a three secon tree will be comprised of Secons 1, 2 and 3. Secon 1 is the bo om secon . eep the es holding the branches fastened unl the secon has been either inserted into its corresponding secon or tree stand.
· Idenfy and safely store the included e tra bulbs, hinge pins pro ided, so you can nd them easily if bulbs or hinges need to be replaced o er the years.
Assembly

A1

A2

B

C1

C2

C3

· Assemble the tree stand by pulling apart the legs of the stand so that they are X-shaped. Match the hole of the plasc flange with the pre-drilled hole in the stand. Screw the eyebolt through the hole in the stand, making sure it does not protrude into the center of the stand so that the tree trunk can be inserted easily into the stand. (See Fig. A1 and A2)

Helpful Tip: he eye bolt should easily screw into the stand. If you are ha ing di culty inserng the eye bolt, realign the flange and stand holes to a oid stripping the eye bolt or cracking the flange.

· Locate the bo om secon of your tree -it should ha e a tag with the rst number printed on it. ully insert the bo om secon of your tree with branches sll ed into the stand. ighten the eyebolt s on your tree stand so that the secon is straight. (See Fig. B)

· ne the branches and allow branches to fall into place.

Helpful Tip: emember, the tree is highly-compressed for shipping and re uires proper shaping for a full, realisc look.

· or best results, shape each secon as you go working from bo om to top. Start with the branch ps closest to the trunk. he inner branches should be separated with each branch p poinng up toward the ceiling to create a full look and hide the trunk from iew. or the outer branch ps, separate them so that they point up and out to create your desired silhoue e. (See Fig. C1 to C3) Insert the subse uent secons, untying and shaping one secon at a me, unl you ha e inserted and shaped all of the secons.

Helpful Tip: If you ha e purchased a tall tree, you may want to shape the top secon before inserng it into Secon 2.

· FOR PRELIT TREES: As you are assembling the tree, Connect the plug s securely to the e tension cord s as per the color labels indicated in Fig. D and plug the adaptor connected with green labeled e tension cord into the wall outlet. Your enre tree should now be lit. If some bulbs do not light or flicker, search for any loose plugs and or broken, loose or missing bulbs. eplace bulbs promptly in order to maintain the performance and life e pectancy of your pre-lit tree.

· A er shaping and lighng your whole tree, step back and take an o erall look at the tree. Shi branches to ll any gaps and ensure

lights are well-spaced. If your tree looks like the one in Fig. E, you did O properly shape the tree. Fig. E shows a tree that ust had

its outer ps mildly shaped, with no work done at the center and middle.
HOW TO USE THE DUAL COLOR LIGHT CONTROLLER:

Selector u on

Press the selector bu on on the Dual Color Light Controller to select among:

(1) CLEAR-MULTI: FADING (2) CLEAR: FADING (3) CLEAR-MULTI: ALTERNATING (4) CLEAR: STEADY

(5) CLEAR-MULTI: SLOW FADING (6) MULTI: STEADY (7) MULTI: FADING (8) COMBINATION

Light Controller

*Electrical Rang For The Tree

(For Indoor Use Only)

18 Was

Input: AC 120V, 60Hz, 0.38A

Output: DC 29V, 0.621A

Controller : 0.621A

3

D
Insert Red Label Plugs Into Red Labeled Extension Cord

2

Insert Yellow Label

Plugs Into Yellow

Labeled Extension Cord

1

Note: Do not step on the tree stand legs during the setup. This may deform the tree stand and may result in an unbalanced tree.

Control box

Adapter To Be Plugged
Into Wall Outlet

TZZZ

If your enre tree does not light:

E

· nsure all plugs are properly connected and adaptor is plugged into the wall outlet.

· nsure all power cords from the secons are properly plugged into the main secon.

If lights in certain areas of the tree are not lit: · nsure bulbs are securely fastened into bases. · Verify all wires are intact. · Please check for loose, broken or missing light bulbs and replace as needed.

If a branch has come detached from the tree · ind the hinge pin and plasc washer that are included with your tree. · Place the branch into the bracket a ached to the center pole with the branch fully seated in the bracket. · Insert the hinge pin through the bracket holes and limb and secure the opposite side with the washer.

d^Z
· nplug e tension cord with adaptor from the wall outlet and then disconnect light e tension cord between each secon of the tree.
· emo e all ornaments and decoraons. · nplug each secon of e tension cord, keeping pre-plugged strings of lights connected together. · ently li o the top and middle secons, and remo e the bo om secon from the tree stand. · Carefully replace the tree in its bo and tape it shut. Do not store tree in a damp area or in an area where the temperature e ceeds 100 .

WARNING
· se only power adapter supplied with this product, using a di erent adaptor will damage the lights and cause re, electrical shock hazards. · O I DOO S O LY.
CAUTION
1. o reduce the risk of re and electric shock: a se only the power supply that was pro ided with this product. sing a di erent adapter will damage the lights and may cause re, or electrical shock hazards. b Do not install on trees ha ing needles, lea es or branch co erings of metal or materials which look like metal. c Do not mount or support strings in a manner that can cut or damage wire insulaon.
2. he controller and remote controller if included can only be used with this product.

ITEM #: TG70P3573D01
