MEM6247 GTM Hammer Vario
Product Information:
- Product Name: GTM Hammer Vario
- Model Numbers: MEM6247, MEM6248
Assembly Instructions:
- Start by removing the wheels, sleeves, and nuts from the
product. - Next, assemble the plates according to the provided pictures.
For right side mounting, you will need the following parts:
| Item No. | Part Number | Qty | Description |
|---|---|---|---|
| 1 | 300128 | 1 | Bracket GTM |
| 2 | 405239 | 1 | Nordlock Washer M16 |
| 3 | HW063 | 1 | Sleeve |
| 4 | XOE-22294-BO | 1 | Right Bracket |
| 5 | XSM8X10 | 2 | Screw : Round – M8 X 10 |
| 6 | XOE-25383-00 | 1 | |
| 7 | 93440-120520 | 1 | Circlip |
Note: If you only ordered the mounting set, please be aware that
the axle, axle spacer, and the Circlip are not included. For
replacement, refer to the service manual.
Finally, assemble the under placed battery bag.
Tightening Torque Specifications:
| Bolt Size | Torque (Nm) |
|---|---|
| M3 | 1.2 Nm |
| M4 | 3 Nm |
| M5 | 6 Nm |
| M6 | 10 Nm |
| M8 | 25 Nm |
| M10 | 50 Nm |
| M12 | 85 Nm |
| M16x1 M18x1 | 30 Nm 40 Nm |
Date: 2022-12-05
Assembly instructions for GTM Hammer Vario MEM6247 and MEM6248
1. Remove wheels, sleeves and nuts. Remove
6 7
2. Check the correct placement for the eMove, and that it is axle Ø12,0 x 51 with Part Number: XOE-2530E-BO and Spacer with Part Number: XOE-25383-00. 2022-12-05
3. Assembly the plates according to pictures. Parts for right side mounting:
Item No. Part Number
Qty
Description
1
300128
1
Bracket GTM
2
405239
1
Nordlock Washer M16
3
HW063
1
Sleeve
4
XOE-22294-BO
1
Right Bracket
5
XSM8X10
2
Screw : Round – M8 X 10
6
XOE-25383-00
1
Spacer Ø12,0
7
93440-120520
1
Circlip
Note! If you only order the mounting set, the axle, axle spacer and the Circlip are not included, for replacement see the service manual.
4. Assemble the under placed battery bag.
2022-12-05
M3
1,2 Nm
M4
3 Nm
M5
6 Nm
M6
10 Nm
M8
25 Nm
M10
50 Nm
M12
85 Nm
M16x1 M18x1
30 Nm 40 Nm
2022-12-05
