HT-AIM-70 4K 60Hz 4:2:0 HDBT Extender
Product Information
The HT-AIM-70 is a slimline HDBaseT extender pair that can
transmit HDMI signals of up to 4K 60Hz (4:2:0 8-bit) along 70m of
category cabling. It comes with a transmitter unit and a receiver
unit, along with a power adapter, IR emitter cable, IR receiver
cable, 3.5mm 3-pin Phoenix connector, and mounting brackets. The
extender pair also features bi-directional PoC two-way IR and RS232
pass-through.
Features
- Transmits up to 4K@60Hz 4:2:0 8-bit and HDCP2.2 over a single
category cable - Uses Cat6a/7 cable to extend 4K@60Hz 4:2:0 8-bit up to
40m/130ft and 1080P up to 70m/230ft - Uses Cat5e/6 cable to extend 4K@60Hz 4:2:0 8-bit up to
35m/115ft and 1080P up to 60m/200ft - Bi-directional PoC (Power over Cable) with one power adapter at
either end - Supports bi-directional IR and RS232 pass-through
Usage Instructions
Before using the HT-AIM-70, please read the important safety
instructions mentioned in the user manual carefully. Ensure that
the apparatus is not exposed to rain, moisture, dripping or
splashing, and is well ventilated. Do not obstruct its ventilation
openings, install it near any heat sources, or place sources of
naked flames on it. Clean the apparatus only with a dry cloth, and
unplug it during lightning storms or when unused for long periods
of time. Protect the power cord from being walked on or pinched
particularly at plugs, and only use attachments / accessories
specified by the manufacturer.
To use the extender pair, follow these steps:
- Connect the transmitter unit to the source device (e.g. Blu-ray
player) using an HDMI cable. - Connect the receiver unit to the display device (e.g. TV) using
an HDMI cable. - Connect the transmitter and receiver units using a category
cable (Cat6a/7 or Cat5e/6). - Connect the IR emitter and receiver cables to the transmitter
and receiver units respectively. - Connect the power adapter to either end of the extender pair,
ensuring that bi-directional PoC is enabled. - Turn on the source and display devices.
With the built-in control pass-through, users can control the
source from the display’s location or control the display from the
source’s location. The small form factor of the extenders makes
them easy to install in many locations.
Hall Technologies · 1234 Lakeshore Dr Suite #150 Coppell, TX 75019 · halltechav.com
HT-AIM-70
4K@60Hz 4:2:0 HDBT Extender
USER MANUAL
May 24, 2023
Hall Technologies May 24, 2023
Page 1 of 12
Important Safety Instructions
1. Do not expose this apparatus to rain, moisture, dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus.
2. Do not install or place this unit in a bookcase, built-in cabinet or in another confined space. Ensure the unit is well ventilated.
3. To prevent risk of electric shock or fire hazard due to overheating, do not obstruct the unit’s ventilation openings with newspapers, tablecloths, curtains, and similar items.
4. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
5. Do not place sources of naked flames, such as lighted candles, on the unit.
6. Clean this apparatus only with dry cloth.
7. Unplug this apparatus during lightning storms or when unused for long periods of time.
8. Protect the power cord from being walked on or pinched particularly at plugs.
9. Only use attachments / accessories specified by the manufacturer
Hall Technologies May 24, 2023
Page 2 of 12
Table of Contents
Introduction ……………………………………………………………………………………………………………………………… 4 Overview ……………………………………………………………………………………………………………………….. 4 Features…………………………………………………………………………………………………………………………. 4
Package Contents ………………………………………………………………………………………………………………………. 4 Connectors & Indicators……………………………………………………………………………………………………………… 5
HT-AIM-70 Front Panel…………………………………………………………………………………………………….. 5 HT-AIM-70 Rear Panel ……………………………………………………………………………………………………… 6 Product Wiring and Connection Diagram ……………………………………………………………………………………… 7 Applications………………………………………………………………………………………………………………………………. 8 Setup ……………………………………………………………………………………………………………………………………….. 9 Installation …………………………………………………………………………………………………………………….. 9 Troubleshooting ………………………………………………………………………………………………………………………. 10 Specifications ………………………………………………………………………………………………………………………….. 11
Hall Technologies May 24, 2023
Page 3 of 12
Introduction
OVERVIEW
The AIM-70 is a slimline HDBaseT extender pair that can transmit HDMI signals of up to 4K 60Hz (4:2:0 8-bit) along 70m of category cabling. CAT6 cable supports 4K 60Hz (4:2:0 8-Bit) up to 35m and 1080p 60Hz HDMI signals can also be extended up to 60m. CAT6A / 7 cabling offers increased distances of 40m for 4K 60Hz (4:2:0 8-Bit) resolutions and 70m for 1080p 60Hz. The AIM-70 also features bi-directional PoC two-way IR and RS232 pass-through.
With the built-in control pass-through, users can control the source from the display’s location or can control the display from the source’s location. And, with their small form factor, the extenders are easy to install in many locations.
FEATURES
Up to 4K@60Hz 4:2:0 8-bit and HDCP2.2 over a single category cable. Using a Cat6a/7 cable, extends 4K@60Hz 4:2:0 8-bit up to 40m/130ft and 1080P up to 70m/230ft. Over a Cat5e/6 cable, extends 4K@60Hz 4:2:0 8-bit up to 35m/115ft and 1080P up to 60m/200ft. Bi-directional PoC (Power over Cable) with one power adapter at either end. Supports bi-directional IR and RS232 pass-through.
Package Contents
HT-AIM-70
1x Transmitter Unit 1x Receiver Unit 1x Power Adapter (DC 18V 1A) 1x IR Emitter Cable 1x IR Receiver Cable 2x 3.5mm 3-Pin Phoenix Connector 4x Mounting Brackets (with screws)
Hall Technologies May 24, 2023
Page 4 of 12
Connectors & Indicators
HT-AIM-70 FRONT PANEL
No.
Name
1
POWER
2
STATUS
3
HDCP
4
LINK
Description · On: The device is powered on. · Off: The device is powered off.
· On: The device is working properly. · Off: The device is not working properly.
· On: HDCP protected content is being transmitted. · Blinking: Non-HDCP protected content is being transmitted. · Off: No content is being transmitted.
· On: HTBaseT link is normal. · Blinking/Off: No HDBaseT link or link error.
Hall Technologies May 24, 2023
Page 5 of 12
HT-AIM-70 REAR PANEL
No.
Name
1
POWER
2
HDBT IN
3
IR IN
4
IR OUT
5
RS232
6
HDMI OUT
7
HDBT OUT
8
HDMI IN
Description DC 18V power supply. (Only one side needs to be powered.) HDBaseT input, connected to the transmitter output via Cat5e/6/7 cable. Connect either unit to the IR Receiver Cable (Signal is sent to the other unit’s IR OUT). Connect either unit to the IR Emitter Cable (Signal is received from the other unit’s IR IN) For RS-232 pass-through. Connect to an HDMI display device. HDBaseT output, connected to the receiver input via Cat5e/6/7 cable. Connect to an HDMI source.
Hall Technologies May 24, 2023
Page 6 of 12
Product Wiring and Connection Diagram
Hall Technologies May 24, 2023
Page 7 of 12
Applications
A laptop, or other HDMI source, is connected to the HDMI input on the HT-AIM-70-TX and then transmitted over the category cable to the HT-AIM-70-RX, where a display, connected to the HDMI output, shows the HDMI source. Control via RS232 or IR is also passed through the category cable for display control.
Note: In this application the HT-AIM-70-RX is locally powered and providing power via PoC (Power over Cable) to the HT-AIM-70-TX. Only one side needs to be powered, meaning the local power supply could be moved to the HT-AIM-70-TX if that is more convenient for installation.
Hall Technologies May 24, 2023
Page 8 of 12
Setup
INSTALLATION
Note: Before installation, please ensure the devices are disconnected from the power source. To install the device on a surface:
1. Secure the included L-bracket mounts to each side of the transmitter/receiver using the included screws.
2. The bottom part of the L-bracket will slightly raise the transmitter/receiver and will create a small gap between the device and the mounting surface.
3. Using the appropriate hardware (not included), mount the bottom of the L-brackets to the desired surface.
Hall Technologies May 24, 2023
Page 9 of 12
Troubleshooting
Problem Type Video
Problem No video on display
Options Confirm the connectors are properly seated on each device Confirm at least one side (typically the receiver) has local power connected Test the category cable to confirm proper pinout and no shorts in the cable Confirm the distance between the transmitter and receiver does not exceed specifications (depending on the desired resolution) Confirm the HDMI input of the display is correctly selected Confirm the connected source is sending video to the HT-AIM (i.e. verify laptop is in duplicate or extend mode)
Hall Technologies May 24, 2023
Page 10 of 12
Specifications
Technical HDMI Compliance HDCP Compliance Video Bandwidth Video Resolution Color Depth HDMI Audio Formats
Resolution / Distance
General Operating Temperature Storage Temperature Humidity Power Consumption Power Dimensions Weight
HDMI 2.0
HDCP 2.2
10.2 Gbps
4K@60Hz (8-bit 4:2:0), 4K2K@30Hz, 1080p, 1080i, 720p 8/10/12-bit (4K@60Hz) 16-bit (1080p@60Hz) PCM 2.0/2.1/5.1/6.1/7.1, Dolby Atmos, Dolby TrueHD, DTS-ES, DTS HD Master, DTS-X 4K60: · Cat5e/6: 115ft (35m) · Cat6a/7: 130ft (40m) · HDMI: 33ft (10m) 1080p: · Cat5e/6: 200ft (60m) · Cat6a/7: 230ft (70m) · HDMI: 50ft (15m)
NOTE: Premium High Speed HDMI cable is highly recommended.
0°C to 40°C (32°F to 104°F)
-20°C to 60°C (-4°F to 140°F)
10% to 90%, non-condensing
8.88W (Pair, PoC)
1x DC 18V/1A (included) 108.8mm W x 15mm H x 64.2mm D (4.3″ W x 0.6″ H x 2.5″ D) 180g (0.4 lbs.)
Hall Technologies May 24, 2023
Page 11 of 12
© Copyright 2022. Hall Technologies All rights reserved.
1234 Lakeshore Drive, Coppell, TX 75019 halltechav.com / [email protected]
(714)641-6607
