S2 Fresnel Optical Screen
Product Information
The S2 Fresnel Optical Screen is a cutting-edge screen designed
for home cinema. It offers a sharper picture and incredible visuals
for a more immersive viewing experience. The screen uses a
drilling-free magnetic sticker for easy installation without
drilling. It is made of polymer resin materials that are
environmentally friendly and safe for the health of you and your
family. The screen has a view size of 2214 x 1245 mm, supports
2K/4K image resolution, has an ambient light rejection value of
85%, and weighs 7kg. It is suitable for use with UST projectors
(Ultra Short Throw Home Projector) with a throw ratio of 0.23 –
0.26.
Product Usage Instructions
Before using the product, please read the product instruction
manual carefully and keep it properly. The Company is not liable
for any accident resulting from the violation of the warnings in
this manual. After receiving the goods, please keep the product
packing box properly, ready for after-sale reuse!
To install the screen, first, check the material and space
suitability of the wall for installation. Determine the center line
and then move horizontally (1107mm to both right and left). Paste
the sling and pendant (for 100-inch screen display width) onto the
wall surface. Please note that the wall surface should be highly
even and leveled. For painted walls, the uneven surface needs to be
less than 1.5mm, and for other hard-surfaced walls, the uneven
surface needs to be less than 0.5mm.
When the life of the product is ended or the product is no
longer needed, please comply with the relevant national laws and
regulations on waste electrical and electronic products recycling,
and give them to the local manufacturer with national recognized
recycling qualification for recycling, and shall not handle them at
will.
USSE2RMMatAeNUAL
S2 FRESNEL OPTICAL SCREEN
U1LmTmRA SLIM
20
2IN020BUYESAINRESSS
88LAYERS
4 K
4KL+ERGEIST4IOMKLAUTTEION
MAXIMUMCONTRAST FRESNEL SCREEN
CONTENT
NOTICE —————————————————————————————- 1 WARNING ———————————————————————————— 1 INSTRUCTION ——————————————————————————- 2 PACKING LIST ——————————————————————————- 3 ENVIRONMENTAL PROTECTION STATEMENT ———————————– 4 INSTALLATION ——————————————————————————- 5 AFTER-SALES SERVICE PROCEDURE———————————————- 7 DISCLAIMER ——————————————————————————— 9 ALL RIGHT RESERVED —————————————————————— 9
NOTICE
Before using the product, please read the product instruction manual carefully and keep it properly. The Company is not liable for any accident resulting from the violation of the warnings in this manual. After receiving the goods, please keep the product packing box properly, ready for after-sale reuse!
WARNING
When installing this product, please confirm the bitmap and video. Please follow the instructions. Otherwise, it may cause serious damage to the product; This product is not recommended to install on: 3D wallpaper, wall cloth, diatom mud, brick wall and other wall with a powdery surface or with a laminate surface.Otherwise, the product may fall off; This product is not recommended to install in wet, watery or humid environment. Otherwise, it may cause the product to fall or seriously reduce the service life of the product; During the installation and handling of this product, two people shall operate in strict accordance with the methods in the installation video. Otherwise, it may cause damage the product; The frame of this product is 3D printed, and neutral detergent is required for screen cleaning and maintenance. Otherwise, it may cause the screen frame to fall off.
1
INSTRUCTION
Cutting edge Fresnel screen, specially designed for home cinema A sharper picture and incredible visuals for a more immersive viewing experience Drilling-free magnetic sticker, easy installation without drilling; Polymer resin materials, environmental protection and safety, care for the health of you and your family;
Screen Size View Size (mm)
Gain Resolution
2224*1255 2214*1245
2.5 support 2K/4K image
Ambient Light Rejection Value
85%
Weight
7kg
Install Position
The bottom edge of the screen is 630mm away from the floor
Suitability
UST projector (Ultra Short Throw
Home Projector)
Throw Ratio: 0.23 – 0.26
2
PACKAGING LIST
The label in this instruction manual is only a schematic diagram, please refer to the physical object, after opening
the packaging, please carefully check the physical number of accessories in the product list;
UNIT
QUANTITY
01
SCREEN
11
11000”0 2224
1255 510
610
02
MAGNETIC
STICKERS
10M0AGNET:IC8 STICKERS*8
(FOR 100” SCREEN)
03
ELBOW
JOINTS
22
04
SLING
11
05
PENDANT STICKER
22
FSCEEN IN SIGHT
06
GLOVES
22
/
07
NON-WOVEN CLOTH
11
/
08
MANUAL
11
/
3
ENVIRONMENTAL PROTECTION STATEMENT
This product meets the environmental protection requirements of the Administrative Measures for the Restricted
Use of Hazardous Substances in Electrical and Electronic Products:
In the process of use, there will be no harmful substances leakage, precipitation and other problems affecting the health of consumers, you can rest assured to use
When the life of the product is ended or the product is no longer needed, please comply with the relevant national laws and regulations on waste electrical and electronic products recycling, and give them to the local manufacturer with national recognized recycling qualification for recycling, and shall not handle them at will.
SCREEN ACCESSORY
TOXIC AND HARMFUL SUBSTANCES OR ELEMENTS
MERCURY (HG)
LEAD (PB)
CADMIUM (CD)
HEXAVALENT CHROMIUM (CR(VI))
POLYBROMINATED BIPHENYL (PBB)
PBDE
This form is prepared according to sJ/11364 o:It means that the content of the substance in all homogeneous materials of the component is below the specified limit requirements of GB / T26572 Limited Requirements for Restricted Substances in Electronic and Electrical Products. x: It means that the content of toxic and harmful substances in at least one of the homogeneous materials of the component exceeds the limit requirements stipulated in GB / T26572 Limit Requirements for Restricted Substances in Electronic and Electrical Products.
4
INSTA(LLATION)
11
FSCEEN IN SIGHT
FSCEEN IN SIGHT
FSCEEN IN SIGHT
A1
FSCEEN IN SIGHT
A2
FSCEEN IN SIGHT
A4
FSCEEN IN SIGHT
A3
O
JIGUANGDIANSHI
A1
A2
JIGUANGDIANSHI
2
1107mm2100
3635mmA1A2
1245mmA3A43100
FSCEEN IN SIGHT
FSCEEN IN SIGHT
JIGUANGDIANSHI
4,
4,
CHENGDU FSCREEN SCI-TECH CO ,LTD.
JIGUANGDIANSHI
585
JIGUANGDIANSHI
6
6() 5
5
INSTALLATION
JIGUANGDIANSHI
JIGUANGDIANSHI
JIGUANGDIANSHI
77
88
99
1. Check the material and space suitability of the wall for installation 2. Determine the centre line, then move horizontally (1107mm to both right and left); paste the sling and pendant
(100 inch screen display width)
11.5mm 3. Mark A1 and A2 at 635mm above the ground; mark A3 and A4 at 1245mm above A1 and A2 (100 inch screen display four points locations) 0.5mm 4. Switch on the projector, adjust the projection to ensure perfect match with the screen size 5. Secure the 8 pieces of magnetic stickers at the marked area 6. Remove the pendants and use it as the indicators for corners of the screen 7. Install the screen and ensure that the edges closely align with the pendants 8. Check the projection and ensure that the image matches the screen and function normally 9. Remove the pendants and the installation is completed
Please note: the wall surface is required to be highly even and levelled – For painted wall: uneven surface needs to be less than 1.5mm – For other hard surfaced wall: uneven surface needs to be less than 0.5mm
6 6
CHENGDU FSCREEN SCI-TECH CO ,LTD.
AFTER-SALES SERVICE PROCEDURE
1. Contact the manufacturer
Check the appearance immediately after receiving the product. If there is any problem, the client needs to keep the packaging and contact the manufacturer.
Please contact the manufacturer with the following information: · Client details · Product information including model description, serial number [product serial number printed at the back of the
product and outside the packaging box should be consistent] · Describe the issue to the customer service department · Customer service staff may require future explanations about the issues and require photos as proof · Contact email: [email protected]
2. Response from the manufacturer
1. Once the manufacturer received the inquiry from the client, verification on products will be done 2. If the client provides clear photos as proof, the manufacturer will be able to resolve the issue immediately
without further investigation 3. If the proof are unclear or problems are complicated, the manufacturer may require the client to return the
product back to the manufacturer in order to assess on the issue 4. Customer service staffs will inform the client regarding returning shipments and logistics
7
AFTER-SALES SERVICE PROCEDURE
3. Negotiation and resolution
Based on the assessment and evaluation, customer service staffs will negotiate with the client about the resolution procedures depending on the attribution of responsibility.
The following scenarios are not covered under the warranty: · Product with no serial number or the product serial number does not match the product model, or the serial
number has altered marks · Damage caused by human factors, including damage due to improper handling of the product or improper
usage that did not follow the instruction in normal working environment · Damages due to improper disassemble, repair, refit or any action carried out by users without professional
guidance · Using products under harsh environment or conditions such as ambient temperature, high humidity etc. · Products damaged by uncontrollable factors such as fire, flood, lightning strikes, traffic accidents etc. · Products purchased through informal channels such as second-hand products · Demos or on-sale products sold by the company, or products indicated `no after-sales service’, `only provide
maintenance’ and `no return or exchange’.
Product use and maintenance instructions: · This product does not require electricity · The main material of the product is polymer resin. The screen surface will be marked with sharp objects and
cannot be repaired · General cleaning method: gentle mopping using a soft cloth with a small amount of neutral detergent · Do not use in high temperature and high humidity environment. The appropriate conditions are indoor with
temperature of 25°C ± 10°C, humidity of 50 ± 20% RH · For the best outcome, please avoid outdoor use (sun exposure and rain will cause deformation or product
damage, which cannot be repaired)
8
DISCLAIMER
Winways Au Pty Ltd (Winways) does not make any express or implied representation or guarantee about the contents of this user manual. Winways reserves the right to revise this publication and make amendments to the contents of this document at any time without giving notice to any person. Screen model is subject to your order requirements.
ALL RIGHT RESERVED
No part of this document shall be reproduced in any form, transmitted or stored into the retrieval system or translated into any language or computer language without prior written permission from Winways Au Pty Ltd.
Manufacturer: Winways Au Pty Ltd Address114 Eldridge Rd, Condell Park NSW 2200 Email: [email protected]
9
