Ningbo Awa15 Bluetooth Speaker User Manual

NINGBO AWA15 Bluetooth Speaker

Product Information

The 90mm A15 Bluetooth Adapter comes with a USB cable and user manual. It supports Bluetooth 5.0 and has a frequency range of  2.402 GHz to 2.480 GHz. It supports HFP, A2DP, and AVRCP profiles. The effective range of the Bluetooth adapter is 20m in an open space, and it has a working time of up to 8 hours. The battery specification is 3.65V 2600mAh, and it takes 2 hours to charge. The adapter has 4 noise-cancelling microphones with an effective pickup range of 3m and a maximum background noise suppression of 18dB. The speaker rated output power is 4/3W, and the product dimensions are 166*105*38 mm. The operating ambient temperature is 0~40°C, and the net weight of the product is 329g.

Warnings

• Store the product in a cool and dry place, and do not use it in a humid environment.
• Avoid exposing the product to direct sunlight, open flame, and other high temperature conditions.
• Do not disassemble the product for maintenance or replacement of accessories without authorization.
• For repair service, consult the official sales support.
• Purchase only the attachments/accessories specified by the manufacturer.
• Clean the product with a dry cloth.
• Dispose of packaging materials, equipment, battery, and other electronic components properly to avoid damage to the environment.
• Avoid using the product at a high volume for a prolonged period of time to prevent hearing damage.
• Avoid using the product while walking, driving or riding to avoid traffic accidents.

Product Usage Instructions

1. Charge the adapter fully before use.
2. Turn on your device’s Bluetooth feature and search for available Bluetooth devices.
3. Select “A15 Bluetooth Adapter” from the list of available devices.
4. If prompted, enter the password “0000” to pair the device.
5. The LED indicator will turn solid blue when the device is paired successfully.
6. You can now use the Bluetooth adapter to stream audio or take calls.
7. To charge the adapter, connect it to a USB port using the included USB cable. The LED indicator will turn solid red while charging and turn off when fully charged.
8. If the LED indicator flashes red, the battery is low and needs to be charged.
9. To mute the microphone during a call, press and hold the multifunction button for 2 seconds. The LED indicator will turn solid red to indicate that the microphone is muted.
10. To unmute the microphone during a call, press and hold the multifunction button for 2 seconds again. The LED indicator will turn off to indicate that the microphone is unmuted.

USER MANUAL

Warnings

Please read the following safety instructions before using the product.

1. Do not expose the product to direct sunlight, open flame, and other high temperature conditions.
2. Do not disassemble the product for maintenance or replacement of accessories without authorization.
3. For the repair service, please consult the official sales support.
4. Please purchase the attachments accessories specified by the manufacturer.
5. Please clean the product with dry cloth.
6. Properly dispose of packaging materials, equipment, battery, and other electronic components to avoid damage to the environment.
7. Do not use the product at a high volume for a prolonged period of time to avoid hearing damage.
8. Do not use the product while walking, driving or riding to avoid traffic accidents.

Product Information
