Aukey Basix Plus Series 22.5w Pd Qc 3.0 20000mah Power Bank User Manual

Basix Plus Series

20000mAh Power Delivery Power Bank

User Manual

Product Diagram

(1) Lightning Input
(2) Micro-USB Input
(3) USB-C Input
(4) USB-A Output 1
(5) USB-A Output 2
(6) Power Button
(7) LED Indicators

Getting Started

Recharging the Power Bank

1. Fully charge the power bank before first use.
2. Connect the included USB-A to C cable to a USB power source.
3. Connect the other end to the USB-C port of the power bank.
4. Unplug the power bank when fully charged.

Charging Your Device

1. Connect the charging cable to your device’s charging port.
2. Connect the other end of the cable to an output port on the power bank.
3. Unplug your device when fully charged.
4. To check the remaining battery level, press the power button.

Low-Current Charging Mode

This mode is customized to charge low-current devices (below 60mA).
Try switching to this mode if a low-powered device (such as a fitness tracker or wireless headphones) isn’t charged in the standard charging mode.

Activation

Press and hold the power button for 5 seconds to enter the low-current charging mode. Once activated, the LED indicators will flash dynamically.

Deactivation

Press and hold the power button for 5 seconds to manually exit low-current charging. Also, the power bank will automatically switch back to standard charging mode after 2 hours of charging in this mode.

LED Status Indicator

LED Indicator
Battery Level	< 25%	25% | 50%	51% | 75%	76% | 99%	100%

On
Off
Blinking

Notes

Keep away from liquids and extreme heat.

Recharge the power bank at least once every 3 months.

Batteries should be disposed of according to local environmental law.

The low-current mode cannot be activated when recharging the power bank.

Specifications

Model: PB-N74S

AUKEY Technology Co., Ltd.
Room 102, Building P09, South China City
Electronics Trading Center, Longgang District,
Shenzhen, Guangdong, 518111, CN
