ES-AHV 02 ALU Master Bracket
Product Information
The ES-AHV 02 is a solar panel mounting system that comes with
adjustable lang brackets, short brackets, rubber pads, and M8
hexagonal screws (ST6,3 * 80). The dimensions of the system are not
specified in the user manual.
Product Usage Instructions
- Make sure you have all the necessary tools, including an Allen
key, a 10mm and 13mm open-end wrench for M6 and M8 screws, or a
cordless screwdriver. - Begin by assembling the frame of the solar panel.
- Next, attach the solar panel to the frame using the provided
brackets and screws. - Make sure to tighten all screws and bolts to secure the system
in place.
ES-AHV 02
EN
enjoysolar® ALU Master Bracket
5410002
ES-AHV 02
Dimension (mm)
Adjustable lang brackets
X2
Short brackets
X2
Rubber pads
X4
M8 Hexagonal Screws (ST6,3 * 80)
X8
Copyright© 2022 SolarV GmbH All rights reserved.
Prepare for assembly
Tools (not incl.)
Allen key
+
10mm and 13mm Open-end wrench for M6 and M8 screws
Or
Cordless screwdriver
Copyright© 2022 SolarV GmbH All rights reserved.
Assembly instructions
1
Mount the short Copyright© 2022 brackets to the SolarV GmbH All rights reserved. bottom
frame of the solar panel:
Copyright© 2022 SolarV GmbH All rights reserved.
2 Assemble the short brackets with the rubber pads on the surface with M8 screws Copyright© 2022 SolarV GmbH All rights reserved.
3
Mount the lang brackets to the top frame of the Copyright© 2022 SolarV GmbH All rights reserved.
solar panel:
Copyright© 2022 SolarV GmbH All rights reserved.
4 Assemble the lang brackets with the rubber pads on the surfaCocpyerigwht©i2t0h22 M8 screws SolarV GmbH All rights reserved. Copyright© 2022 SolarV GmbH All rights reserved.
5 Tighten all screws and bolts to secure the system
Copyright© 2022 SolarV GmbH All rights reserved.
