VinTEC Bottle Wine Stotage Cabinet User Manual
Product Details
FEATURES
- Adjustable wooden shelves
- Security lock
- LED internal lighting
- Triple glazed door, with anti-UV glass
- Reversible door
- Digital temperature display
BENEFITS
Stable Temperature Our wine cabinets maintain a stable temperature to keep your wine in perfect cellaring conditions. This is thanks to triple glazed glass, insulated side panels and interactions between a compressor and thermostat.
UV Protected Dark Storage Area UV rays negatively impact the quality of your wine. Our cabinets eliminate this treat by incorporating UV treated tinted glass doors, dark interiors and dimmed internal LED lights.
No Vibration To protect the storage life and quality of your wine, our cabinets have been designed to create a vibration proof environment by including an externally housed compressor, rubber shock absorbers and vibration absorbing wooden shelves.
Specifications
WINE CELLARS | |
| Domestic Warranty | 2 |
| Installation Type | Both |
| Finish | Borderless Black Glass |
| Door Type | Glass Door |
| Door Construction | Triple Glazed, UV treated |
| Handle | Recessed |
| Fridge door opening | Reversible |
| Refrigerant | R600a |
| Easy Capacity (Bottles) | 40 |
| Max Capacity (Bottles) | 50 |
| Main Function | Cellar Red & White |
| Alternate Function | Serve White or Red |
| No of Zones | 1 |
| Temperature Range Zone 1 (deg) | 6 – 18 Degrees C |
| Air space at sides (mm) | 10 |
| Air space above cabinet (mm) | 39 |
| Joinery cut out dimension minimum height mm) | 850 |
| Joinery cut out dimension minimum width (mm) | 615 |
| Joinery cut out dimension minimum depth (mm) | 600 |
| Plinth depth (mm) | 78 |
| Plinth Height (mm) | 85 |
| Weight Unloaded | 47 |
| Power Supply | 240V / 10AMP |
| Electricity Consumption (kWh/Day) | 1 |
| Ambient Temperature (deg) | 5-35 |
| Display Panel | LED Digital Display |
| Castors and Feet | 4 Adjustable Feet |
| Internal Heater | No |
| Lock | Yes |
| Alarm | Visual |
| Lighting | White LED |
| Number of Shelves | 5 |
| Shelving Material | Wood |
| Shelving Type | 4 Full,1 Half |
| Shipping Weight (Kg) | 51 |
| Pack Dimensions Height (mm) | 880 |
| Pack Dimension Width (mm) | 655 |
| Pack Dimension Depth (mm) | 665 |
| Type | Wine Cabinet |
| Function | Cellar |
| Dimension | |
| Height (mm) | 820 |
| Width (mm) | 595 |
| Depth (mm) | 563 |
| Number of rows (Total inc bottom & ½ shelves) | 5 |
| Number of columns | 1 |
| Max number of slots | 6 |
IMPORTANT:
This is a guide of product dimensions only. For complete installation instructions, refer to the manual provided with product.
