C1AXLeR5xGL Espresso Coffee Maker
Product Information: The coffee maker is equipped with
various indicators and components for convenient brewing. It has a
power indicator, single-cup indicator, double-cup indicator, and
steam indicator. The brewing filter is accompanied by a metal
funnel with a handle. The machine also includes a drip plate, drip
tray, tank cover, water tank, knob, steam handle, steam wand, and a
measuring spoon. Product Usage Instructions:
- First Use Preparation or Not in Use for a Long
Period:
- Pour water into the water tank, making sure not to exceed the
Max mark. - Place the filter into the funnel, tighten it, and align it with
the mark. - Plug in the power and press the button. The coffee maker will
beep. - The button lights flashing together indicate that the coffee
maker is warming up. Ensure that the steam knob points to . If it
points to , the machine will not work. - Turn the steam knob to for the steam nozzle to discharge hot
water. Then turn it back to . - When the indicator lights of and are always on, press the
button of to wash the coffee filter or cup with hot water.
- Insert the filter into the funnel and load ground coffee powder
into it. Compress the coffee powder with the rear of the coffee
spoon and clean any excess powder around the edge of the
funnel. - Insert the funnel into the machine and lock it tightly. Place a
cup under the funnel. - When the and lights are on, press the button or button to
discharge the desired amount of coffee. - Wait for the coffee to drip into the cup and it’s ready!
- Press the button and turn the steam knob to . The steam pipe
will start to discharge hot water. Turn the steam knob to to stop
the hot water. - Note: It is normal for the machine to make relatively large
vibration sound during the process of discharging hot water.
- Fill the jug with cold milk just below the bottom of the
spout. - Press the button until it stops flashing.
- Spin the steam knob to and hold it for 3 seconds to drain the
remaining water in the pipe. - Spin the steam knob to .
- Position Steam Wand:
- Insert the steam wand arm at 12 o’clock. Place the tip at 3
o’clock, keeping a finger width from the edge. Ensure that the
steam vent is just a little below the surface of the milk.
- Spin the steam knob to to start texturing milk. Texturing
should create a smooth hissing noise, indicating a whirlpool action
in the milk.
- As the milk level rises, lower the jug to keep the tip just
below the surface. - When the desired microfoam is achieved, immerse the steam wand
halfway into the milk. - The milk is ready when the base of the milk jug is too hot to
touch for 3 seconds. - Spin the steam knob to .
- Remove the jug from the steam wand.
- Clean the foam nozzle immediately after making steamed milk
foam. - Spin the steam knob to for 3 seconds and then turn it off.
IMPORTANT SAFEGUARDS
1. Before using, make sure that the voltage of wall outlet corresponds to coffee maker rating plate. Use original accessories only. 2. This coffee maker can be used by physically/mentally disabled people or people who are lack of experience and knowledge about the coffee maker if they are under close supervision and instruction by persons who take responsibility for their safety and when they are aware of possible risks and dangers. 3. Do not let children use, touch, clean or play with the coffee maker. 4. This coffee maker is for household coffee making only and can be stopped by pressing the ON/OFF button anytime during its operation. Unplug the coffee maker when not in use. 5. The coffee maker must be placed on a flat surface. Do not move the coffee maker or turn off the power while it is working. Do not move the coffee maker when there is still water in the water tank. 6. Before using the coffee maker for the first time, operate it twice with clean water to remove the odor. 7. Do not damage the cord or put the power cord and the plug into water or any other liquids; do not wash the coffee maker or power cord in water or other liquids. 8. Do not use the coffee maker in high temperature, high magnetic field and damp environment; do not use it when the plug is damaged or when the coffee maker is out of order. 9. For effective operation, it is recommended to descale the coffee maker every 2-3 months.
1
KNOW YOUR COFFEE MAKER
Power indicator Single-cup indicator Double-cup indicator Steam indicator
Brewing filter Metal funnel Funnel handle
Drip plate Drip tray
Tank cover Handle Water tank
Knob Steam handle Steam wand Measuring spoon
2
First Use Preparation or Not in Use for a Long Period
Before you use it for the very first time, clean the coffee maker twice based on the guidelines below.
1. Pour water into the water tank and do not exceed the “Max” mark in the tank.
2. Put the filter into the funnel, tighten and align it with the ” (see below pictures).
” mark
3. Plug in the power, press the ” ” button, the coffee maker beeps.
” ” and ”
” button lights flashing together indicates the coffee
maker starts to warm up (Make sure that the steam knob points to
” “. If it points to ” “, the four lights will flash together and the
machine will not work.).
4. Turn the steam knob to ” ” for the steam nozzle to discharge hot
water.Then turn the steam knob back to”
”
5. When the indicator lights of ” ” and ”
” are always on, press
the button of ”
” to wash the coffee filter or coffee cup with hot
water.
Espresso Coffee Making
1. Insert filter to the funnel, load ground coffee powder into the filter and compress it with the rear of the coffee spoon; meanwhile, clean the coffee powder at the edge of the funnel.
3
Note: When inserting the filter, please first align the small groove and then slightly rotate the filter to prevent it from falling. When removing the filter, please turn the filter back to the small groove position.
2. Insert the funnel and lock it tightly as shown by the indication sign, then place a cup under the funnel.
3. When the ” ” and ”
” lights are on, press the ” ” button
or ”
” button to discharge corresponding amount of coffee.
4. Wait for the coffee to drip into the cup, it’s done!
4
Hot Water Function
Press the ” ” button, turn the “steam knob” to ” “, and the steam
pipe will start to discharge hot water; Turn the “steam knob” to ”
”
to stop the hot water.
Note: it is normal for the machine to make relatively large vibration sound during the process of discharging hot water
How to Make the Perfect Latte
1.Prep Milk Jug 2.Before Texturing Milk 4¥
·3 Sec.
FILL MAX
Fill Jug with cold milk just below the bottom of the spout.
Press the button until the button stops flashing.
Spin the steam knob to and hold it for 3 secs to drain the remaining water in the pipe.
Spin the steam knob to .
5
3.Position Steam Wand
4.Start Texturing Milk
12
finger
width
3
Insert Steam Wand Arm at 12 o’clock. Tip at 3 o’clock. Keep Finger Width from edge and the steam vent is just a little below the surface of the milk.
Spin the steam knob to to start texturing milk. Texturing makes a smooth hissing noise. Milk is moving in a whirlpool action.
5.Milk Texturing
60¥-65¥
As milk level rises, lower Jug to keep Tip just below surface.
When desired microfoam achieved, immerse Steam Wand half way.
Milk ready when Milk Jug base is too hot to touch for 3 sec.
Spin the steam knob to .
Remove Jug from Steam Wand.
6.Purge Clean Steam Wand
·3 Sec.
IMPORTANT AND BASIC:
Clean the foam nozzle immediately after making steamed milk foam.
Spin the steam knob to the steam knob to .
on for 3 secs and then turns
Remove the stainless steel foaming nozzle Wipe the milk dirt at the steam port with a cloth.
6
5. After five minutes, press the “” button and repeat the Step 4 for 3 times.
6. Fill the water tank with water(No need to put in descaler). Press the “” button and repeat the Step 4 for 3 times.
7. To cancel the descaling reminder after cleaning, please press ” ” ” ” and ” “at the same time for 3 seconds to cancel the flashing light.
1. All 4 buttons 2 . Fill the water Flash 5 times and tank with water the coffee maker and descaler beeps for 5 times. to the MAX level.
3 . Press the “” 4 . Press the “” button and hot button to start to water flows into the drip tray. heat the water.
5 . Press the “” button to shut down and leave the descaling solution in the water pipe for 5 minutes.
6 . After five
7 . Fill the water
minutes,press the tank with water
“” button to (No need to put
start the machine in descaler).
and repeat the
Step 3 and the
Step 4 for 3 times.
8 . Press the “” button and repeat the Step 4 for 3 times.
9 . Press the “” button. Press “” “” and “” button at the same time for 3 seconds to cancel the flashing light.
8
9
Troubleshooting
Problem
Reason
Method
No water/steam
1. There is no water in the water tank.
2. The coffee maker is not preheated.
3. Steam pipe has clot.
4. Steam button and/or steam knob are not on or the preheating is not completed
1. Fill the tank with water and press the ON/OFF button and the ” ” and ” ” button.
2. The coffee maker needs to be preheated before the coffee can be produced. That is, the coffee maker will turn to normal light from the flickering state.
3. Use a small wire to poke around the steam hole.
4. Turn on the steam button and/or steam knob and wait for the preheating to complete before steam comes out.
10
No grease
1.The coffee grounds are too thick or the grounds are not pressed.
2. Coffee beans are not fresh enough.
1. Change to a finer ground coffee and use the back of the coffee scoop to flatten it horizontally.
2. Use fresh coffee beans/ground.
The milk does not foam well
1. Whether it is whole milk.
2. The steam is discharged too early.
1. Use whole milk.
2. Steam nozzle can only be started after the indicator light for steam button turns from flashing to constant light.
3. Please see “How to Make the Perfect Latte” section.
No coffee,
The temperature is too
coffee light flash high after steaming.
Please see “Cooling Function” section.
Water scale
The coffee maker has been used for a fairly long time.
Purified water is recommended. If the water quality in your area is poor, please perform a descaling operation every 2 months.
Please see “Descaling Reminder Function” section.
Coffee not hot enough
1. The coffee ground is too fine and too much, resulting in too little water output.
2. Ambient temperature or cup temperature is too low.
1. Adjust the grinding degree of freshly coffee ground.
2. Flush the filter and coffee cup with hot water.
11
Flash and Sound Explanation
Problem
Reason
Method
Flash altogether, steam knob points to
The steam knob points to the wrong place and the coffee maker will not operate.
Rotate the steam knob to .
Flash after use and the coffee maker becomes hot.
The coffee maker is hot.
Please see “Cooling Function” section.
Flash 5 times and the coffee maker beeps for 5 times.
The coffee maker needs to be descaled.
Please see “Descaling Reminder Function ” section.
12
Warranty
Every CMEP02 espresso machine comes with a 1-year limited warranty from the date of purchase. Please scan the QR code on our website to view the specific warranty policy. For more information, visit our website (www.laekerrt.com) or contact us directly.
Disclaimer
WE ARE NOT RESPONSIBLE FOR DAMAGES CAUSED BY THE FOLLOWINGS:
1. Misunderstanding and misuse of the instruction manual. 2. Instances other than coffee-making. 3. Modifying the coffee maker by consumers instead of technicians from authorized retailers or Laekerrt. 4. Usage of non-original gadgets.
13
Laekerrt
