How do I fix a blank display on my RTH6360 thermostat?
If the thermostat is battery powered, check/replace your batteries. If the device is common wired, try and power it up with batteires. If that fails to power up the thermostat, you may need to involve a technician. If batteries do power up your common wired thermostat, check your breakers, furnace power switch, furnace door kill switch to insure your system is powered. If your system is fine, and the thermostat only works on batteries, you may need to involve a technician.
How do I access the installer setup (ISU) on a RTH6360 thermostat?
- Press and hold Menu and + buttons for approximately 5 seconds to enter advanced menu.
- Press Select to enter System Setup (ISU) menu.
- Press Select to cycle through System Setup numbers.
- Press + or – to change values or select from available options.
- Press Select to save changes and advance to the next System Setup number.
- Once you have cycled through all of the System Setup numbers, “Done” is displayed. Press Select to save and exit. To save and exit early, press Home to return to the Home screen.
How do I adjust the screen brightness on my RTH6360 thermostat?
For the RTH6360
Pressing any button will cause the screen to light up for a period of time and will dim over time if no button is pressed.
How do I enable auto change over on the RTH6360?
- Press and hold Menu and + buttons for approximately 5 seconds to enter advanced menu.
- Press Select to enter System Setup (ISU) menu.
- Press Select to cycle through System Setup numbers.
- Press + or – to change values or select from available options.
- Press Select to save changes and advance to the next System Setup number.
- Once you have cycled through all of the System Setup numbers, “Done” is displayed. Press Select to save and exit. To save and exit early, press Home to return to the Home screen.
Setup Step 300 needs to be set to 1 for Auto System Change Over
Is the RTH6360 Heat pump compatible?
Yes. The RTH6360 will operate a heat pump, including a heat pump with backup heat.
Specifications
5-2 Day Programmable Thermostat With Backlight
| Thermostat Type | Programmable |
| Includes | Thermostat, Quick installation guide, Screws, Anchors, UWP mounting system |
| Program Modes | 5-2 Programmable |
| Display Type | LCD Screen |
| Product Height | 3.86 in |
| Product Length | 5.36 in |
| Product Width | 1.08 in |
| Warranty | 1 Year |
| Control Functions | Heating, Cooling |
| Alerts and Reminders | Filter Change 1, Battery Replacement, Memory Error, Unknown Time, Internal Sensor Failure |
